I/O address (hex)
00B0- 00B1
00B2- 00B3
00B4- 00B5
00B8- 00B9
00BC - 00BD
00C0- 00DF
00F0- 00F0
0400 - 0453
0454 - 0457
0458 - 047F
04D0 - 04D1
0500 - 057F
0680 - 069F
0D00 - FFFF
1000 - 100F
164E - 164F
2000 - 203F
2040 -205F
2060 - 207F
2080 - 2087
2088 - 208F
2090 - 2093
2094 - 2097
FFFF - FFFF
FFFF - FFFF
Hardware Specifications and Configurations
System Function (shipping configuration)
Programmable Interrupt Controller
Motherboard resources
Programmable Interrupt Controller
Programmable Interrupt Controller
Programmable Interrupt Controller
Direct Memory Access Controller
Numeric data processor
Motherboard resources
Motherboard resources
Motherboard resources
Programmable Interrupt Controller
Motherboard resources
Motherboard resources
PCI Express Root Complex
Motherboard resources
Motherboard resources
®
Intel HD Graphics 4000
®
Intel 7 Series/C216 Series Chipset Family SMBus Host
Controller -1E22
®
Intel 7 Series Chipset Family SATA RAID Controller
®
Intel 7 Series Chipset Family SATA RAID Controller
®
Intel 7 Series Chipset Family SATA RAID Controller
®
Intel 7 Series Chipset Family SATA RAID Controller
®
Intel 7 Series Chipset Family SATA RAID Controller
Motherboard resources
Motherboard resources
