3. Slide the battery pack into its slot in the upper case assembly.
Figure 3-112. Battery Cable
4. Secure the battery pack to the upper case using one screw.
Figure 3-113. Battery Pack Screw
Table 3-113. Screw
Step
Battery Pack Reassembly
3-68
Screw
M2 x L2
Quantity
Screw Type
1
