Reinstalling the Hold Sensor Board

1. Connect the hold sensor cable to the hold sensor board (1), then press the connector latch
(2) until it locks into place.
Figure 3-100. Hold Sensor Cable
2. Place the hold sensor board into the upper case assembly.
Figure 3-101. Hold Sensor Board
3-62
