Reinstalling the Small Fan
1. Place the small fan into the upper case assembly.
Figure 3-93. Small Fan
2. Secure the small fan to the upper case assembly using two screws.
Figure 3-94. Small Fan Screws
Table 3-94. Screws
Step
Small Fan Reassembly
3-58
Screw
M2 x L3
Quantity
Screw Type
2
Machine Maintenance
