6. Press the upper edges of the touchpad module until the latches lock into place.
Figure 3-85. Touchpad Latches
7. Close the LCD panel and turn the computer over.
8. Place the cable into the upper case assembly (1). Connect the touchpad cable to the
touchpad board (2), then press the connector latch (3) until it locks into place.
Figure 3-86. Touchpad Cable Self Adhesive Tape
Machine Maintenance
3-53
