GE Spacemaker JVM1851BD Dimensions

GE Appliances
JVM1851BD/CD/WD - GE 1.8 Cu. Ft. Spacemaker Over-the-Range Microwave Oven

Dimensions (in inches)

21-3/4"
Door open
Specification Created 3/01
66" MIN.
Mounting
30" MIN.
height
width required
from floor
12"
MAX.
15
16-1/2
15-3/4
Note: Requires 120V grounded outlet. Electrical receptacle must be
Exhaust outlet
located in cabinet above Spacemaker microwave oven. No additional
connects to
wiring, venting or cabinet rebuilding necessary in many cases. Complete
3-1/4" X 10" duct
detailed, easy-to-follow installation instructions and convenient full-size
templates are packed with the Spacemaker microwave oven.
Important Information: When installing the Spacemaker
microwave oven over a range, allow minimum of 2" from bottom of
Spacemaker microwave oven to top of range backguard to allow
for removal of light covers.
Ventilation Options: The Spacemaker microwave ovens are designed for
adaptation to the following three types of ventilation:
• Outside exhaust (vertical—as shown)
• Outside exhaust (horizontal)
• Recirculating (non-vented ductless—see Filter Kit drawing)
Installation Information: This information is not intended to be used for
installing unit described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
For answers to your Monogram, ® GE Profile
GE appliance questions, visit our website at
WWW.GEAppliance.com or call
GE Answer Center ® service, 800.626.2000.
Listed by
Underwriters
Laboratories
R
™ or
