INSTALLATION INSTRUCTION FOR HEAT RECOVERY VENTILATOR (HRV)
Shipping and Packing List
Package 1 of 1 contains:
1 - Assembled ventilator
1 - Bag assembly containing:
2 - Drain spout assemblies
4 - Hanging straps
1 - Installation manual
Required Tools
Installation Tools
•
tin snips
•
assorted screw drivers
•
electric drill
•
hammer
•
wire strippers
•
knife
•
caulking gun
•
smoke pencil
Balancing Tools
•
Pitot Tube Balancing Kit
[Case, 8 ft. vinyl tubing, Pitot tube,
magnehelic gauge (0 - 0.25"), and mounting plate]
•
Pitot Tube with instructions
and Digital Manometer (with resolution of
0 - 0.25" - must read to 1/100ths of an inch)
Optional Accessories
•
20 Minute Fan Timer
•
Wall Mounted Dehumidistat
•
Weather hood Kit
•
Round Diffuser
4" (100mm)
5" (125mm)
6" (150mm)
8" (200mm)
•
Kitchen Grille
- may be required by code for kitchen applications
- contains removable grease filter
MODELS RNC15/RNC25
HEAT RECOVERY VENTILATOR
HEAT RECOVERY VENTILATOR
(HRV units only)
•
large zip ties
•
fabric flexible duct
- class II rated
•
mastic tape
•
alum. foil duct tape
•
zip ties
•
1/2" I.D. drain hose
Application
Heat Recovery Ventilators (HRV) are designed to provide
fresh air while exhausting an equal amount of stale air.
The HRV is equipped with an aluminum core. The device
uses the stale air that is being exhausted to condition the
fresh air as it is being brought in.
General
These instructions are intended as a general guide and do
not supersede local codes in any way. Consult authorities
who have jurisdiction before installation.
Table of Contents
Shipping and Packaging List .................................................1
Required Tools ......................................................................1
Application .............................................................................1
General..................................................................................1
Engineering Data................................................................2-3
Clearances & Requirements..................................................4
Installation ..........................................................................4-7
Installation Diagrams .............................................................8
Electrical ...............................................................................9
Optional Controls.................................................................10
Operation.............................................................................11
Wiring Diagrams ..................................................................12
Interlocking HRV to Furnace ...............................................13
Air Flow Balancing..........................................................15-16
Troubleshooting...................................................................17
Maintenance .......................................................................18
* LEAVE FOR HOMEOWNER
NOTE: Due to ongoing research and product development, specifications,
ratings and dimensions are subject to change without notice.
TM
TW-25
1206
Advertisement
Table of Contents
Related Manuals for Tradewinds RNC15
Summary of Contents for Tradewinds RNC15
-
Page 1: Table Of Contents
MODELS RNC15/RNC25 HEAT RECOVERY VENTILATOR HEAT RECOVERY VENTILATOR INSTALLATION INSTRUCTION FOR HEAT RECOVERY VENTILATOR (HRV) Shipping and Packing List Application Package 1 of 1 contains: Heat Recovery Ventilators (HRV) are designed to provide fresh air while exhausting an equal amount of stale air. 1 - Assembled ventilator 1 - Bag assembly containing: The HRV is equipped with an aluminum core. -
Page 2: Engineering Data
Engineering Data - HRV RNC15 THERMALLY CONDUCTIVE, PATENTED ALUMINUM CORE Performance The cross-flow heat recovery core transfers heat between the two air streams. Net supply air flow in cfm (L/s) against external static pressure It is easily removed for cleaning or service. E.S.P RNC15 MOTORS AND BLOWERS... - Page 3 Engineering Data - HRV RNC25 THERMALLY CONDUCTIVE, PATENTED ALUMINUM CORE Performance The cross-flow heat recovery core transfers heat between the two air streams. Net supply air flow in cfm (L/s) against external static pressure It is easily removed for cleaning or service. E.S.P RNC25 MOTORS AND BLOWERS...
-
Page 4: Clearances & Requirements
Clearances and Requirements Connecting Appliances to the HRV WARNING The following appliances should not be connected to the HRV: Before installation, careful consideration must • clothes dryer be given to how this system will operate if connected to any other piece of mechanical •... - Page 5 Weatherhood Installation CAUTION COLLAR IS SUPPLIED TO ENSURE VAPOUR BARRIER SCREEN IS 100% SEALED TO (side view) WALL PLATE Unit must be installed level to ensure proper condensate drainage. Due to the broad range of installation operational conditions, consideration must be given for the possibility 12"...
- Page 6 Air Duct Design and Installation A well designed and installed ducting system will allow the WARNING HRV to operate at its maximum efficiency. Include a short length of fabric, flex duct or Always try to keep duct runs as short and straight as pos- other non-metallic connector in the “Fresh Air to sible.
- Page 7 Stale Air Exhaust System Drain Connection (HRV Only) The stale air exhaust system draws air from the points in During a defrost cycle, the HRV may produce some con- the house where the worst air quality problems occur. densation. This water should flow into a nearby drain, or Stale air ducts should be installed in the bathroom, be taken away by a condensate pump.
-
Page 8: Installation Diagrams
Installation Diagrams DIRECT CONNECTION of the SUPPLY AIR STREAM to the FURNACE COLD AIR RETURN EXHAUST AIR from various parts of Return Air home. (i.e. bathrooms, kitchens) 3’ min. recommended Outdoors Cool Air Return Forced Air Furnace NOTES: 1. Furnace blower is required to operate when HRV is ON to provide good air distribution. 2. -
Page 9: Electrical
Electrical The HRV unit should be plugged into a standard designat- WARNING ed (120VAC) electrical outlet with a ground. The outlet should be serviced by a separate 15 amp/120V circuit. An In order to prevent electric shock when cleaning extension cord should not be used with this appliance. A or servicing the HRV, it is extremely important to qualified service technician should make any required confirm the polarity of the power line that is... -
Page 10: Optional Controls
Optional Controls Optional Remote Control Devices Low Voltage DEHUMIDISTAT VENTILATION CONTROL (D.V.C.) * remove jumper on circuit board when using this control ** requires 3 wires • Designed for a central location • Ventilation control turns HRV system ON and OFF •... -
Page 11: Operation
Operation Self Test For most installations the HRV will normally be set to oper- ate continuously on low speed. To suit various lifestyles, The ventilator will automatically initiate a self test the HRV offers a selection of operating modes. sequence when power is applied. Fan motor is cycled and then damper motor is cycled. -
Page 12: Wiring Diagrams
Wiring Diagrams RNC3 WIRING DIAGRAM LEGEND HIGH VOLTAGE 12V LOW VOLTAGE AUTO FIELD INSTALLED TRANSFORMER INTERFACE 12V LOW VOLTAGE RELAY CONTACTS BLACK FAN MOTOR DETAILS 120V POWER WHITE SUPPLY GREEN MOTOR GREEN AUTO TRANS N/C COMMON N/O CAPACITOR NEUTRAL SPARE LINE FAN O/P GROUND... -
Page 13: Interlocking Hrv To Furnace
Interlocking HRV Operation to an Airhandler/Furnace Blower When using the Interface relay contacts to initiate blower operation on a fur- nace, certain thermostats will initiate the outdoor cooling condenser when R and G are closed. Use this wiring configuration to prevent the Interface relay contacts from initializing the condenser unit. - Page 14 Dehumidistat Operation (HRV only) The optional HRV remote controls include a dehumidistat The dehumidistat switches the ventilator to high speed which controls humidity levels during the heating season. when the moisture level in the building exceeds the The control has a selector knob with set points ranging desired setpoint.
-
Page 15: Air Flow Balancing
Air Flow Balancing It is necessary to have balanced air flow in an HRV. The vol- The first step is to operate all mechanical systems on high ume of air brought in from the outside must equal the volume speed, which have an influence on the ventilation system, i.e. of air exhausted by the unit. -
Page 16: Air Flow Balancing
Pitot Tube and Gauge Pitot Tube Air Flow Balancing Kit with magnehelic gauge, DUCT Pitot tube, hose and carry case. FLOW Pitot tube Magnehelic gauge High Pressure Side Low Pressure Side Placement of Pitot Tube HRV NOTE: Graphic is for illustrative purposes only. Duct connection ports may vary. -
Page 17: Troubleshooting
Troubleshooting Symptom Cause Solution Poor Air Flow • 1/4” (6mm) mesh on the outside hoods is plugged • clean exterior hoods or vents • filters plugged • remove and clean filter • core obstructed • remove and clean core • house grilles closed or blocked •... -
Page 18: Maintenance
Maintenance 1. Inspect Exterior Hoods at least once a month. 6. Clean Duct System if Required Make sure exhaust and fresh air supply hoods are not The duct system running to and from the HRV may accu- blocked or restricted by leaves, grass, or snow. In winter, it mulate dirt.
