INSTALLATION INSTRUCTION FOR HEAT RECOVERY VENTILATOR (HRV)
Shipping and Packing List
Package 1 of 1 contains:
1 - Assembled ventilator
1 - Bag assembly containing:
2 - Drain spout assemblies
4 - Hanging straps
1 - Installation manual
Required Tools
Installation Tools
• tin snips
• assorted screw drivers
• electric drill
• hammer
• wire strippers
• knife
• caulking gun
• smoke pencil
Balancing Tools
• Pitot Tube Balancing Kit [Case, 8 ft. vinyl tubing, Pitot
tube, magnehelic gauge (0 - 0.25"), and mounting plate]
• Pitot Tube with instructions and Digital Manometer (with
resolution of 0 - 0.25" - must read to 1/100ths of an
inch)
Optional Accessories
• 20 Minute Fan Timer
• Wall Mounted Dehumidistat
• Weather hood Kit
• Round Diffuser
4" (100mm)
6" (150mm)
8" (200mm)
• Kitchen Grille
- may be required by code for kitchen applications
- contains removable grease filter
MODELS RNC95/RNC10/RNC20
HEAT RECOVERY VENTILATOR
HEAT RECOVERY VENTILATOR
(HRV units only)
•
large zip ties
•
fabric flexible duct
- class I rated
•
mastic tape
•
alum. foil duct tape
•
zip ties
•
1/2" I.D. drain hose
Application
Heat Recovery Ventilators (HRV) are designed to provide
fresh air while exhausting an equal amount of stale air.
The HRV is equipped with an aluminum core. The device
uses the stale air that is being exhausted to condition the
fresh air as it is being brought in.
General
These instructions are intended as a general guide and do
not supersede local codes in any way. Consult authorities
who have jurisdiction before installation.
Table of Contents
Shipping and Packaging List ............................................1
Required Tools .................................................................1
Application ........................................................................1
General .............................................................................1
Engineering Data...........................................................2-4
RNC95 Specifications and Airflow ....................................5
Clearances & Requirements.............................................6
Installation .....................................................................6-9
Application Illustrations..............................................10-12
Electrical ........................................................................13
Remote Control Devices.................................................14
Wiring the Controls .........................................................15
Operation ........................................................................16
Wiring Diagrams .............................................................17
Interlocking HRV to Furnace...........................................18
Air Flow Balancing.....................................................20-21
Troubleshooting ..............................................................22
Maintenance ..................................................................23
* LEAVE FOR HOMEOWNER
NOTE: Due to ongoing research and product development, specifications,
ratings and dimensions are subject to change without notice.
TM
TW-01
0307
