- Page 1 XENON TROUPER Follow Spotlight Type 48057 Issue 4/98 PRELIMINARY STRONG INTERNATIONAL a division of Ballantyne of Omaha, Inc. 4350 McKinley Street Omaha, Nebraska 68112 USA Tel 402/453-4444 • Fax 402/453-7238...
- Page 3 Strong Super Trouper II. Using a 700 watt xenon bulb as a light source, the Xenon Trouper meets or exceeds all professional requirements for short- to medium-throw follow spotlight applications. ONLY THE SPECIAL XENON POWER SUPPLIES manufactured by Strong International can be used with the xenon spotlight. For installation and operation of the power supply, see the manual furnished separately.
- Page 4 LAMPHOUSE - POWER SUPPLY Interconnection Diagram LAMPHOUSE (Connections Pre-wired) MS CONNECTOR Wire No, Grnd Remote - Auto Sustained 5 Amp. Lamphouse Dry Contact Cable Assembly (by Installer) Conduit XENON SYSTEM MUST BE GROUNDED POWER All wiring must conform to local SUPPLY codes;...
-
Page 5: Installation And Setup
INSTALLATION & SET-UP THE XENON TROUPER is shipped in sections which must be assembled. The Folding Base Stand Assembly 65838 is shipped collapsed, and requires only unfolding and securing the (4) base legs using the T-bolts supplied. WHEN INSTALLED in a permanent location, the leveling feet must be removed, and the clearance holes in the base leg brackets used for hardware (user supplied) to bolt the base to the floor or platform. -
Page 6: Safety Procedures
SAFETY PROCEDURES READ CAREFULLY BEFORE INSTALLING XENON BULB THE XENON BULB is highly pressurized. When ignited, the normal operating temperature of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accordance to the manufacturer’s operating instructions. - Page 7 Dispose of expired bulbs that are beyond warranty in the following manner: Wrap the bulb tightly in several layers of canvas or heavy cloth. Place it on a hard surface and shatter the envelope with a sharp hammer blow. DO NOT place an unshattered bulb in an ordinary refuse container. DO NOT PERMIT UNAUTHORIZED PERSONNEL TO PERFORM OR ATTEMPT ANY PHASE OF XENON BULB HANDLING OR SERVICE.
- Page 8 700 WATT XENON BULB INSTALLATION Type 48057 Trouper CAUTION: OBSERVE ALL SAFETY PROCEDURES. Put on the protective face mask. Wear clean cotton gloves to prevent marking the quartz envelope of the bulb with fingerprints. REMOVE THE TOP COVER of the lamphouse by removing the four Holt head (tamperproof) screws with the special screwdriver provided.
- Page 9 REMOVE THE PLASTIC COVER from the xenon bulb. Store the protective cover and the original bulb packing in a secure location. The spare anode adapter (65199) is for use with an OSRAM 700 watt bulb (XBO700W/HS OFR) should such a bulb be used as a replacement. SECURE THE LAMPHOUSE COVER with the (4) tamperproof screws using the special screwdriver provided.
-
Page 10: Operation
OPERATION PLACE THE MODE SWITCH (on units so equipped) in the “MAN.” position and energize the xenon power supply. The lamphouse blower will start and actuate the blower interlock switch to permit bulb ignition. This lamp blower will operate continuously until the xenon power supply is de-energized. PLACE THE LAMP SWITCH in the ON position and the xenon bulb will ignite. - Page 11 MOVE THE SPOT SIZE CONTROL HANDLE on the large lens carriage to the forwardmost position to project the smallest spot possible with the iris, choppers, and dimming controls in their full open positions. Project the spot to a wall or similar flat perpendicular surface opposite the spotlight. TURN THE CENTER FOCUS CONTROL counterclockwise until a small black spot is pro- jected on the wall.
- Page 12 HANDLING THE SPOTLIGHT GENERALLY THE BEST POSITION for the operator to stand is near the center of the spot- light, on the right hand side, although the angle of tilt and the size of the porthole may alter the position for the most convenient operation.
-
Page 13: Exhaust System Installation
EXHAUST SYSTEM INSTALLATION IF THE SPOTLIGHT is installed in a closed booth, it is recommended to vent the lamphouse exhaust to outside atmosphere to remove the heat from the booth. THE EXHAUST STACK of the lamphouse is designed to fit a six inch diameter duct. The exhaust system must be designed and installed is a way to eliminate any possibility of a down draft or of rain dripping into the lamphouse. - Page 14 OPERATION OF OPTICAL SYSTEM THE IRIS CONTROL is the front lever which projects through the top of the optical system housing. When this lever is to the left (as viewed from the rear of the unit), the largest aperture is provided. Smaller apertures are obtained as the lever is moved to the right.
- Page 15 OPERATION OF COLOR BOOMERANG THE COLOR BOOMERANG is equipped with six color holders and an ultraviolet filter. Additional filter holders can be supplied by an authorized Strong International Dealer. TO OPERATE INDIVIDUAL COLOR FILTERS, lower the desired filter selector lever. A rocker catch located in the color disc housing holds the filter in position.
-
Page 16: Maintenance
MAINTENANCE THE STRONG XENON TROUPER SPOTLIGHT requires very little maintenance to keep it in good working order. THE REFLECTOR should be cleaned periodically with a soft, clean, lint-free cloth to remove dust from the reflecting surface. If excessively soiled, the reflector may be cleaned with Windex or an equiva- ®... -
Page 18: Parts List
PARTS LIST Wiring Diagram Ref, Desig. Part No. Description 62-98002 Blower, 115 V.AC, 50/60 Hz. C1,2 76132 Capacitor, .005 µf, 600 WVDC 76133 Capacitor, .01 µf, 400 WVDC C4A,B 80177 Capacitor, 1.0+1.0 µf, 600 WVDC 81947 Capacitor, .01 µf, 600 WVDC Xenon Bulb, 700 Watt 65891 Elapsed Time Meter, 60 Hz. -
Page 19: Trouble Chart
TROUBLE CHART NORMAL OPERATION WHEN THE SWITCH in the main AC supply line to the xenon power supply is in the ON position, and the 30 A. circuit breaker on the switching power supply is ON, the POWER light on the xenon power supply will glow. - Page 20 WITH THE “LAMP” SWITCH in the “ON” position, a distinct high voltage arc ping should be heard at the spark gap in the igniter, and the flash of the xenon bulb should be visible through the ammeter as a high RF voltage pulse is applied across the bulb electrodes. IF THE HIGH VOLTAGE PING or the flash at the ammeter is not apparent, check the “No Load”...
- Page 21 XENON TROUPER TROUBLESHOOTING Bulb fails to ignite. 1. MODE switch S3 set to “AUTO.” Place in “MAN.” position when not employing automated or remote lamphouse operation. 2. AC power not on to lamphouse. Turn switching power supply 30 A. circuit breaker ON. If 115 V.AC not read at 2 &...
- Page 22 Bulb goes out during operation (continued) 2. Xenon bulb depressurizing. Check for envelope discoloration; replace if defective. 3. Power supply brown-out protection actuated by voltage drop. See power supply manual. 4. Phase loss detected by power supply (3 phase units only). See power supply manual. Power supply does not energize when actuated.
- Page 23 Color gels burning or fading prematurely. 1. Bulb focused to “hot spot.” Refocus bulb to flat field with iris fully open and spot size control handle (“trombone”) fully forward. 2. Heat filter glass reversed or peeled. Check for coated surface toward bulb; replace if coating peeled. 3.
- Page 25 PARTS LIST Figure 1 Item Part No. Description 65114 Reflector Bulkhead Casting 00805 Tie Rod Lock Nut, 1/4-20 Hex 65164 Tie Rod, Bulkhead to Front Casting 65111 Lamphouse Front Casting 65865 Lamphouse Base Pan & Lower Side 65155 Inner Heat Shield, Left 65156 Inner Heat Shield, Right (not shown) 65117...
- Page 27 PARTS LIST Figure 2 Item Part No. Description 65142 Ammeter (M2) 81276 MODE Switch (S3), AUTO-MAN. 81275 LAMP Switch (S2), ON-OFF 65116 Casting, Bulb Positioning Control 65197 Fender Washer, Inner 37985 Thumb Screw 15010 Compression Spring 65150 Fender Washer. Outer 65112 Lamphouse Back Casting 65959...
- Page 29 PARTS LIST Figure 3 Item Part No. Description 80168 Top Cover Interlock Switch (S1) 01741 Lockwasher, 7/16" 65185 Switch Mounting Bracket 00254 Screw, 8-32 x 1/4" Fillister Head 00891A Lockwasher, #8 65876 Potentiometer (early models*) 79131 Ground Terminal 65960 Rear Bulb Support Collet 21-48027 Collet Retaining Ring M4361...
- Page 31 PARTS LIST Figure 4 Item Part No. Description 51875 Carriage Casting, Large Lens 51493 Lens Retaining Ring 51492 Rubber Lens Cushion 00217 Screw, 8-32 x 5/16" Round Head 00830 Flatwasher, #8 Brass 00866 Flatwasher, #10 51102 Large Lens 51133 Lens Focus Block 51489 Lens Focus Shaft 00866...
- Page 32 PARTS LIST, Figure 4 (continued) Item Part No. Description 44239A Projection Lens 83155 Retaining Clip, Projection Lens 51160 Pulley Stud 00830 Flatwasher, #8 Brass NOT SHOWN 48891 Base Rail, Lamphouse & Lens Mechanism 49342 Hand Rail 01346 Screw, 5/16-18 x 1/2" Hex Head 00877 Split Lockwasher, 5/16"...
- Page 34 PARTS LIST Figure 5 Item Part No. Description 10048A Knob, Red Plastic 48402 Iris Shaft 00179 Screw, 6-32 x 1/4" Fillister Head 00892 Lockwasher, #6 51978 Friction Spring & Pad (for 51979) 00184 Screw, 6-32 x 5/8" Fillister Head 00892 Lockwasher, #6 51979 Iris (as shown;...
- Page 35 PARTS LIST, Figure 5 (continued) Item Part No. Description 00853 Washer, 1/4" Steel, S.A.E. 51156 Friction Plate 51498 Chopper Pull Rod, Short 51155 Handle, Chopper Control 10048A Knob, Red Plastic 00254 Screw, 8-32 x 1/4" Fillister Head 00891 Lockwasher, #8 47170 Iris Stop Bracket 48406...
- Page 36 FIGURE 5A Part No. Description 01306 Screw, 6-32 x 5/16" 21-70029 Spring Washer 24369 Bell Crank 48402 24372 Adapter Ring 24374 Iris 25034 Iris Clamp 25035 Link with Pins 41-51252 Screw, 8-32 x 5/8" 24369 41-50325 Screw, 6-32 x 3/8" 01306 41-51530 Shoulder Bolt...
- Page 37 51850 BOOMERANG ASSEMBLY...
- Page 38 BOOMERANG PARTS LIST Part No. Description 51850 Boomerang Assembly 00180 Screw, 6-32 x 5/16" Fillister Head 00255 Screw, 8-32 x 5/16" Fillister Head 00793 Nut, 6-32, Steel 00829 Washer, #8 Brass, 3/8" O.D. 00831 Washer, #10 Brass, 7/16" O.D. 00837 Washer, 5/16"...
- Page 39 FOLDING BASE & STAND Assembly No. 65838...
- Page 40 PARTS LIST Folding Base & Stand Item Part No. Description 49120 Tilt Axis Bolt 02411 Washer, 1.25" O.D. x .640" I.D. 49121 Washer, Tilt Axis 41-35020 Hexnut, 3/8-16 00845 Flatwasher, 3/8" S.A.E. 49126 Clamping Plate 49125 Clamping Spring, Compression 49124 Clamp Bushing 49129 Shaft, Tilt Clamp...
