Specifications - Sony TRINITRON KV-27V40 Service Manual

KV-27V40 / 27V45 / 27V65 / 29VL40 / 29VL65A / 29VL65C / 29VL85 / 29VL95
Power requirements
Number of inputs/outputs
1)
Video
2)
S Video
3)
Audio
4)
Audio Out
Monitor Out
Speaker output (W)
Power Consumption (W)
In use (max.)
In standby
Dimensions (W/H/D)
(mm)
(in.)
(kg.)
Mass
(lbs.)
Television system
American TV standard (all models except KV-29VL65A)
PAL-M, PAL-L, NTSC (KV-29VL65A only)
Channel coverage
VHF:2-13/UHF:14-69/CATV:1-125
Visible screen size
27-inch picture measured (KV-27V40/V45/V65)
29-inch picture measured (KV-29VL40/65A/65C/85/95)
Actual screen size
27-inch picture measured (KV-27V40/V45/V65)
29-inch picture measured (KV-29VL40/65A/65C/85/95)
Antenna
75 ohm external terminal for VHF/UHF
Supplied Accessories
Remote commander (w/2 size AA (R6) batteries)
RM-Y165: (KV-27V40/29VL40)
RM-Y167: (KV-27V45/65, 29VL65A/65C/85/95)
Optional Accessory
Connecting Cables:
VMC-810S/820S, VMC-720M, YC-15V/30V
TV Stand SU-27A3
VHF, UHF Mixer EAC-66
Design and specifications are subject to change without notice.

SPECIFICATIONS

KV-27V40
KV-27VL40
120V,60Hz
2
1
2
1
1
5Wx2
140W
2W
—
2 —
KV-27V45
KV-29VL85
120V,60Hz (KV-27V65/29VL95)
120V,60Hz 220V, 50/60Hz (KV-29VL65A/65C)
3
1
3
1
1
5W x 2
140W
2W
3W (KV-27V65/29VL65A/65C)
690 x 575.4
x 503.4mm
27 1/4 x 22 3/4
7/8
X19
42.4kg
93 lbs.
1) 1 Vp-p 75 ohms unbalanced, sync negative
2) Y: 1 Vp-p 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
3) 500 mVrms (100% modulation), Impedance: 47 kilohms
4) More than 408 mVrms at the maximum volume setting (variable)
( ) SRS (SOUND RETRIEVAL SYSTEM)
The ( ) SRS (SOUND RETRIEVAL SYSTEM) is manu-
factured by Sony Corporation under license from SRS
Labs, Inc. It is covered by U.S. Patent No. 4,748,669. Other
U.S. and foreign patents pending.
The word 'SRS' and the SRS symbol (
trademarks of SRS Labs, Inc.
BBE and BBE symbol are trademarks of BBE Sound,Inc.
and are licensed by BBE Sound, Inc. under U.S.Patent
No. 4,638,258 and 4,482,866.
KV-27V65
KV-29VL65A/65C
KV-29VL95
3
1
3
1
1
10WX2
170W
2W (KV-29VL95)
) are registered
