User Manual
Projector
CP-X205/CP-X305
User's Manual (detailed)
Network Guide
This manual is only intended to explain Network Functions.
For safety, operations or any other issues, refer to the Safety Guide or Operating
Guide.
WARNING
product. Be sure to read Safety Guide first. After reading, keep the manuals in a
safe place for future reference.
NOTE
• The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in
this manual.
• The reproduction, transfer or copy of all or any part of this document is not
permitted without express written consent.
Trademark acknowledgement
• Windows is a registered trademark of Microsoft Corporation.
• Netscape is a registered trademark of Netscape Communications Corporation.
• JavaScript is a registered trademark of Sun Microsystems, Inc.
All other trademarks are the properties of their respective owners.
Contents
Network Functions .................................................................. 2
E-mail Alerts .......................................................................... 23
Projector Management using SNMP ...................................... 25
Event Scheduling ................................................................... 26
e-SHOT (Still Image Transfer) Display .................................. 29
Command Control via the Network ....................................... 31
• Before using this product, please read all manuals for this
Advertisement
Table of Contents
Related Manuals for Hitachi CPX305 - XGA LCD Projector
Summary of Contents for Hitachi CPX305 - XGA LCD Projector
-
Page 1: Table Of Contents
Projector CP-X205/CP-X305 User’s Manual (detailed) Network Guide This manual is only intended to explain Network Functions. For safety, operations or any other issues, refer to the Safety Guide or Operating Guide. WARNING • Before using this product, please read all manuals for this product. -
Page 2: Network Functions
Network Functions Network Functions This projector is equipped with the following network functions. Configuring and Controlling the Projector via a Web Browser You can change the settings of or control the projector via a network by using a web browser from a PC that is connected to the same network. (4) E-mail Alerts The projector can automatically send an alert to specified e-mail addresses when... -
Page 3: Before Using The Network Functions
Network Functions Before Using the Network Functions… To use the network functions of this projector, the projector must be configured to suit your network. Consult with your network administrator before connecting the projector to your network. Incorrect network configuration of this projector may cause problems on your network. -
Page 4: Configuring And Controlling The Projector Via A Web Browser
Configuring and Controlling the Projector via a Web Browser Configuring and Controlling the Projector via a Web Browser You can adjust or control the projector via a network from a web browser on a PC that is connected to the same network. NOTE •... - Page 5 Configuring and Controlling the Projector via a Web Browser When configuring or controlling the projector via a web browser, an ID and password are required. There are two types of IDs, Administrator and User. The following chart describes the differences between User and Administrator IDs. Item Description Administrator...
- Page 6 Configuring and Controlling the Projector via a Web Browser Refer to the following for configuring or controlling the projector via a web browser. Example: If the IP address of the projector is set to 192.168.1.10: ) Enter "http://192.168.1.10/" into the Fig.
-
Page 7: Network Information
Configuring and Controlling the Projector via a Web Browser Network Information All screen images displayed in this manual are screens of a logon using an Administrator ID. Any Administrator only functions will not be displayed when using a User ID. Refer to the descriptions in each table. -
Page 8: Network Settings
Configuring and Controlling the Projector via a Web Browser Network Settings Displays and configures network settings. Item Description IP Configuration Configures network settings. DHCP ON Enables DHCP. DHCP OFF Disables DHCP. IP Address Configures the IP address when DHCP is disabled. Subnet Mask Configures the subnet mask when DHCP is disabled. -
Page 9: Port Settings
Configuring and Controlling the Projector via a Web Browser Port Settings Displays and configures communication port settings. Item Description Network Control Port1 Configures command control port 1 (Port:23). (Port:23) Port open Click the [Enable] check box to use port 23. Click the [Enable] check box when authentication is required Authentication for this port. -
Page 10: Mail Settings
Configuring and Controlling the Projector via a Web Browser Mail Settings Displays and configures e-mail addressing settings. Item Description Click the [Enable] check box to use the e-mail function. Send mail Configure the conditions for sending e-mail under Alert Settings. Configures the address of the mail server in IP format. -
Page 11: Alert Settings
Configuring and Controlling the Projector via a Web Browser Alert Settings Displays and configures failure & warning alert settings. Alert Item Description Cover Error The lamp cover has not been properly fixed. Fan Error The cooling fan is not operating. The lamp does not light, and there is a possibility that interior Lamp Error portion has become heated. - Page 12 Configuring and Controlling the Projector via a Web Browser Alert Settings (Continued) The Alert Items are shown below. Setting Item Description Configures the time to alert. Alarm Time (Only Lamp Time Alarm and Filter Time Alarm.) SNMP Trap Click the [Enable] check box to enable SNMP trap alerts. Click the [Enable] check box to enable e-mail alerts.
-
Page 13: Schedule Settings
Configuring and Controlling the Projector via a Web Browser Schedule Settings Displays and configures schedule settings. Item Description Daily Configures the daily schedule. Sunday Configures the Sunday schedule. Monday Configures the Monday schedule. Tuesday Configures the Tuesday schedule. Wednesday Configures the Wednesday schedule. Thursday Configures the Thursday schedule. - Page 14 Configuring and Controlling the Projector via a Web Browser Schedule Settings (Continued) The daily and weekly event items are shown below. Item Daily & Weekly Description Schedule Click the [Enable] check box to enable the schedule. Schedule List Displays the current schedule. The specific date event items are shown below.
- Page 15 Configuring and Controlling the Projector via a Web Browser Date/Time Settings Displays and configures the date and time settings. Item Description Current Date Configures the current date in year/month/day format. Current Time Configures the current time in hour:minute:second format. Click the [ON] check box to enable daylight savings time and Daylight Savings Time set the following items.
- Page 16 Configuring and Controlling the Projector via a Web Browser Date/Time Settings (Continued) Item Description Configures the time difference. Time difference Set the same time difference as the one set on your PC. If unsure, consult your IT manager. Click the [ON] check box to retrieve Date and Time SNTP information from the SNTP server and set the following items.
-
Page 17: Security Settings
Configuring and Controlling the Projector via a Web Browser Security Settings Displays and configures passwords and other security settings. Item Description Administrator authority Configures the Administrator ID and password. Configures the Administrator ID. Administrator ID The length of the text can be up to 32 alphanumeric characters. - Page 18 Configuring and Controlling the Projector via a Web Browser Security Settings (Continued) Item Description Configures the authentication password for the command Network Control control. Configures the authentication password. Authentication The length of the text can be up to 32 alphanumeric Password characters.
-
Page 19: Projector Control
Configuring and Controlling the Projector via a Web Browser Projector Control The items shown in the table below can be performed using the Projector Control menu. Select an item using the up and down arrow keys on the PC. Most of the items have a submenu. Refer to the table below for details. - Page 20 Configuring and Controlling the Projector via a Web Browser Projector Control (Continued) Item Description Image Aspect Selects the aspect ratio. Over Scan Adjusts the over-scan setting. V Position Adjusts the vertical position. H Position Adjusts the horizontal position. H Phase Adjusts the horizontal phase.
- Page 21 Configuring and Controlling the Projector via a Web Browser Projector Control (Continued) Item Description Screen Language Selects the language for the OSD. Menu Position V Adjusts the vertical Menu position. Menu Position H Adjusts the horizontal Menu position. Blank Selects the Blank mode. Startup Selects the start-up screen mode.
-
Page 22: Projector Status
Configuring and Controlling the Projector via a Web Browser Projector Status Displays and configures the current projector status. Item Description Error Status Displays the current error status. Lamp Time Displays the usage time for the current lamp. Filter Time Displays the usage time for the current filter. Power Status Displays the current power status. -
Page 23: E-Mail Alerts
E-mail Alerts E-mail Alerts The projector can automatically send an alert message to the specified e-mail addresses when the projector detects a certain condition that is requiring maintenance or detected an error. NOTE • Up to five e-mail addresses can be specified. •... - Page 24 E-mail Alerts Mail Settings (Continued) 8) Configure the Failure/Warning Alerts via E-mail settings. Click [Alert Settings] on the main menu. 9) Select and configure each alert item. Refer to Alert Settings in "Configuring and Controlling the Projector via a Web Browser" for further information ( 11).
-
Page 25: Projector Management Using Snmp
Projector Management using SNMP Projector Management using SNMP The SNMP (Simple Network Management Protocol) enables to manage the projector information, which is a failure or warning status, from the computer on the network. The SNMP management software will be required on the computer to use this function. -
Page 26: Event Scheduling
Event Scheduling Event Scheduling The scheduling function enables to setup scheduled events including power on / power off. It enables to be “self-management” projector. NOTE • You can schedule the following control events: Power ON/OFF, Input Source and Transferred Image Display. •... - Page 27 Event Scheduling Schedule Settings Schedule settings can be configured from a web browser. Example: If the IP address of the projector is set to 192.168.1.10: ) Enter "http://192.168.1.10/" into the address bar of the web browser. 2) Enter the Administrator ID and password and click [Logon]. 3) Click [Schedule Settings] on the main menu and select the required schedule item.
- Page 28 Event Scheduling Date/Time Settings The Date/Time setting can be adjusted via a web browser. Example: If the IP address of the projector is set to 192.168.1.10: ) Enter "http://192.168.1.10/" into the address bar of the web browser. Enter the Administrator ID and password and click [Logon]. ) Click [Date/Time Settings] on the main menu and configure each item.
-
Page 29: E-Shot (Still Image Transfer) Display
e-SHOT (Still Image Transfer) Display e-SHOT (Still Image Transfer) Display The projector can display a still image that is transferred via the network. Communication Port The following port is used for e-SHOT. TCP #9716 NOTE • e-SHOT is not available via communication ports (TCP #23 and TCP #9715) (9) which are used for the command control. - Page 30 (Still Image Transfer) Transmission e-SHOT transmission requires an exclusive application for your PC. You can download it from the Hitachi web site. Refer to the manual for the application for instructions. To display the transferred image, select the e-SHOT item in the NETWORK menu ("NETWORK menu"...
-
Page 31: Command Control Via The Network
Command Control via the Network Command Control via the Network You can configure and control the projector via the network using RS-232C commands. Communication Port The following two ports are assigned for the command control. TCP #23 TCP #9715 NOTE •... - Page 32 Command Control via the Network Command Control Settings (Continued) When the authentication setting is enabled, the following settings are required. (17) ) Click [Security Settings] on the main menu. ) Click [Network Control] and enter the desired authentication password. 9) Click the [Apply] button to save the settings. NOTE •...
-
Page 33: Command Format
Command Control via the Network Command Format Command formats differ among the different communication ports. ● TCP #23 You can use the RS-232C commands without any changes. The reply data format is the same as the RS-232C commands. However, the following reply will be sent back in the event of authentication failure when authentication is enabled. - Page 34 Command Control via the Network Command Format (Continued) Reply Data format The connection ID (the data is same as the connection ID data on the sending data format) is attached to the RS-232C commands reply data. <ACK reply> Connection Reply 0x06 byte <NAK reply>...
- Page 35 Command Control via the Network Automatic Connection Break The TCP connection will be automatically disconnected after there is no communication for 30 seconds after being established. Authentication The projector does not accept commands without authentication success when authentication is enabled. The projector uses a challenge response type authentication with an MD5 (Message Digest 5) algorithm.
