Freecom HD Dock Quattro User Manual page 7

1. HDD installation for ." or ."
1.
2.
USB
3.
4.
Start Up the HD Dock Quattro
Connect the cable of the power supply to the
Freecom HD Dock Quattro and the power supply
itself to the socket.
a) USB: Connect the USB cable to the USB port on the
HD Dock Quattro (for data transfer with USB).
or
b) Firewire 400/800: Connect the Firewire cable to
the Firewire port on the HD Dock Quattro (for data
transfer with Firewire).
or
c) eSATA: Connect the eSATA cable to the eSATA port
on the HD Dock Quattro (for data transfer with
eSATA).
Vertically insert the hard drive into the drive slot,
make sure the hard drive matches firmly with the
connector inside the dock.
Switch on the HD Dock Quattro.
EN
1
