Precautionary Measures and General Notes
• Make sure the label side of the hard drive is ahead, and the hard drive connector is
downward before it is inserted. Otherwise, the hard drive can not be inserted.
• Do not eject the hard drive while it is working.
• Hold the hard drive with its front edge instead of the PCB at the bottom side.
• Hard drives are precise equipment. Read the user manual attached with the hard
drive before using.
• Do not put anything inside the product except 2.5" or 3.5" SATA I/II hard drives.
• Freecom warranty this product against defects of materials and workmanship under
normal use, Freecom cannot be made responsible for any damage caused by accident,
abuse, misuse etc, nor any hardware/software damage or data loss.
The surface temperature of hard drive may reach 0°C, please mind and
be careful, altough it is not hot enough to burn people.
Features
• Works under open space, no dissipating device for hard drive is needed.
• Supports 2.5" & 3.5" SATA I/II hard drive
• Supports USB 2.0 up to 480 Mbps, compatible with USB 1.1 up to 12 Mbps.
• Supports 1.5 Gbit/s or 3.0 Gbit/s SATA HDD
• Supports hot swaps
• Unique hard drive ejection apparatus
Specification
• Interface: USB 2.0/eSATA to SATA
• Speed: 480 Mbps (USB 2.0), 12 Mbps (USB 1.1)
• Material: Plastic/Metal
• Weight: 295 g
• Dimensions: 125 (L) x 80 (W) x 72 (H) mm
General information
