Table of Content
Chapter 1 Getting Started
1-1 Unpacking ........ .......................... ... ... ... .... .... ... .. .. .. . 4
1-2 Checking the Parts List .... .... ..... .... ... ....... .... ..... .... 4
1-3 Components of Internal-mount Model (LS-10) .... 4
1-4 Components of Standard Model (LS-10E) .. .... ... .. 6
1-5 Software Backups ........................... ............. ......... 6
1-6 Minimum System .......... ..... ... ........... ............ ......... 6
1-7 Notes on Use ........................................................ 8
Chapter 2 Setting the Standard Model (LS-10E)
2-1 Setting Up the LS-10E Scanner .......................... 14
2-2 Setting the SCSI 10 .......................... ................... 16
2-3 Terminating the SCSI Chain .................. ............ 20
2-4 Connecting to the Computer SCSi ................. .. .. 22
2-5 Setting Up the SCSI Chain .. ............................ ... 24
2-6 Setting Up a SCSI Chain w ith the LS-10E ......... 26
Chapter 3 Setting Up the Internal-mount Model
(LS-10)
3-1 Setting Up the LS-10 Scanner .. .... .. .... .. ......... .. .. . 28
3-2 Installing the LS-10 Scanner .............................. 30
3-3 Setting the SCSI 10
.............................................
40
3-4 Terminating the SCSI Chain .... .. ...... .................. 46
3-5 SCSI Cables Used w ith Internal Scanners .... .... 46
3-6 Connecting to the Computer SCSi ..................... 48
3-7 Setting Up a SCSI Chain with the LS-10 50
Chapter 4 Using the Scanner
4-1 Knowledge of Films ............................................ 52
4-2 Operation to Use a Slide Film ........................... 54
4-3 Operation to Use a Strip Film Holder ................ 62
4-4 Focus ........ .. ............ .. .................. .. .... .. .... .... .. ....... 70
4-5 Calibration ........ ...................................... .. ........... 74
4-6 LEO Indicator ...................................................... 76
4-7 TERM. PWR Switch .. ............... ....................... ..... 76
Specifications ......... ......... .. .... .. ...... ................. .. ....... ...... 78
