MURO VISLIDER VL71-FLR Instruction Manual

Heavy duty auto feeding screwdriving tool
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Heavy Duty Auto Feeding Screwdriving Tool
Instruction manual

Table of contents

1
1
1
2
3 - 5
5 - 6
7
(with warranty card)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISLIDER VL71-FLR and is the answer not in the manual?

Questions and answers

Related Manuals for MURO VISLIDER VL71-FLR

Summary of Contents for MURO VISLIDER VL71-FLR

  • Page 1 Heavy Duty Auto Feeding Screwdriving Tool Instruction manual (with warranty card) Table of contents Safety precautions Parts designation Specifications Assembling VISLIDER Loading VISROPE 3 - 5 Driving screws 5 - 6 Maintenance and inspection...

  • Page 2: Safety Precautions

    Safety precautions WARNING Denotes risk of personal injury, loss of life or damage to the tool In case of nonobservance of the instructions in this manual. Before use, be sure to carefully read the instructions. screws fall. Read the related Drill instruction manual, too. Never direct this unit toward anybody.

  • Page 3: Assembling Vislider

    Assembling VISLIDER 1. Assembly and fitting of rod handle Remove the hexagon fitting bolt and the washer Mount the assembled rod handle on the rear of the from the handle rod. To the handle rod, fit the main body. Tighten the two fitting screws using handle bar, the washer and the hexagon bolt in this the 6mm wrench.

  • Page 4: Loading Visrope

    Loading VISROPE 1.Setting VISROPE Open the magazine cover while pulling the Set the VISROPE to the magazine as shown magazine lever. below. (Remove the rubber band from the VISROPE.) 2. Switching magazine inner lid Lift the inner lid while holding the inner lid stopper on the magazine cover. Insert the inner lid until it snaps in the orientation corresponding to the screw length.
  • Page 5 * Factory setting is for 30mm type. 4. Screw guide position adjustment Carry out the screw guide position adjustment according to the length of the screws used. * Factory setting is for 45mm screw length. 5. Feeding screws Insert the VISROPE into the feeder block until it stops. Push the main body by no less than 30mm, and then pull it back.

  • Page 6: Driving Screws

    6. Adjustment of guide cover Improper guide cover play can affect screw feeding or screw driving. Any time the VISROPE was replaced, make sure to check the guide cover play and adjust it to the adequate level. To adjust the play, first loosen the hexagon nut using the 7mm spanner and then adjust the cap screw using the 3mm wrench.
  • Page 7 5. Removal of VISROPE To remove the VISROPE, pull out the VISROPE while the guide cover and the grip finger are open. * Push the main body 5mm or so to facilitate withdrawal of the VISROPE. 6. Bit replacement To remove the bit, first pick up the bit as much as possible while pulling the sleeve. Then, while pulling back (pressing down) the top end, pull out the whole bit.

  • Page 8: Maintenance And Inspection

    This warranty covers free repairs within the written warranty period and under the condition of proper use. This card is not intended to restrict the user's legal rights. For repairs after the warranty period, contact your dealer or the Customers' Services of MURO NORTH AMERICA INC. or MURO CORPORATION. Manufacturer Please ask to…...
