Pre-Construction Bracket Installation Instructions.

The following product is meant solely for the purpose described and the installation
should be carried out by qualified personnel only.
The Monitor Audio pre-construction brackets are designed with the professional
installers in mind. They will provide a quick and easy way of locating the desired
position of Monitor Audio Series 100, 200, 300 Custom Installation looudspeakers.
Staple wings
to joists here
Joists
Pre-
Construction
Bracket
