Compatibility with all MP3 encoding/writing software, recording
Presetting radio stations
device, and recording media cannot be guaranteed. Incompatible
MP3 discs may produce noise or interrupted audio or may not play
1
Tune in the desired station.
at all.
2
Press TUNER MEMORY
to select the tuner
* This include folders that have no MP3 or other files. The number
memory mode.
of folders that the system can recognize may be less than actual
number of folders, depending on the folder structure.
Creating your own program
(Program Play)
3
Press +/ or ///
1
Select the CD function.
the desired preset number.
Press CD FUNCTION
on the remote or press
If another station is already assigned to the selected
FUNCTION
on the unit repeatedly.
preset number, the station is replaced by the new
station.
2
Select the play mode.
4
Press
to register the station.
Press PLAY MODE
repeatedly until "PGM"
appears while the player is stopped.
5
Repeat steps 1 through 4 to register other stations.
3
Select a folder (MP3 disc only).
You can preset up to 20 FM and 10 AM stations.
Press
+/
repeatedly to select the desired
To tune in to a preset radio station
folder.
If you registered a radio station to a preset number 1
4
Select the desired track or file.
to 6, the radio station will be tuned in by just pressing
Press /
the TUNER MEMORY NUMBER (1 to 6) when the
repeatedly until the desired track
or file number appears.
system function is set to FM or AM.
If you registered a radio station to a preset number 7
or higher, press TUNING MODE repeatedly until
"PRESET" appears then press +/ repeatedly to
select the desired preset number.
Selected track or file
Total playing time
number
Playing the iPod/iPhone
Total playing time for all the programmed tracks or
files, including the selected track or file, is displayed at
right on the panel.
1
Select the iPod function.
5
Program the selected track or file.
Press iPod FUNCTION
on the remote or press
FUNCTION
on the unit repeatedly.
Press
to enter the selected track or file.
"--.--" appears when the total playing time reaches 100
2
Place the iPod/iPhone.
minutes for a CD or when you program MP3 files.
3
Start playback.
6
Repeat steps 3 through 5 to program additional
Press
on the remote or press
tracks or files, up to a total of 25 tracks or files.
unit.
7
To play your program of tracks or files, press
To control the iPod/iPhone
(or
on the unit).
The program remains available until you remove the
To
Press
disc from the disc compartment or unplug the
Pause playback
/ (or
power cord.
unit).
To play the same program again, press
(or
Pause
on the unit).
/
Select a track
or chapter of
fast-rewind, hold down the button.
To cancel Program Play
audiobook/
Press PLAY MODE
repeatedly until "PGM"
podcast
disappears while the player is stopped.
Find a point in a
Hold down /
To delete the last track or file of the program
track or chapter
playback, and release the button at
Press CLEAR
while the player is stopped.
of audiobook/
the desired point.
podcast
Choose the
/
Listening to the radio
selected item
Scroll up/down
/
.
1
the iPod menus
Select the TUNER function.
TOOL MENU /RETURN /
Return to the
Press FM or AM FUNCTION
on the remote or
previous menu
.
press FUNCTION
on the unit repeatedly.
2
Perform tuning.
To use the system as a battery charger
You can use the system as a battery charger for an iPod/
For automatic scanning
iPhone while the system is on.
Press TUNING MODE
repeatedly until "AUTO"
To see whether charging is operating or not, check
appears, and then press +/
. Scanning stops
the battery icon of the iPod/iPhone display. Check the
automatically when a station is tuned in, and
"iPod/iPhone section" of the "Specifications" for a list of
"TUNED" and "STEREO" (for stereo programs only)
iPod/iPhone models compatible with this system.
light up in the display.
To stop charging an iPod/iPhone
Remove the iPod/iPhone.
Notes
The performance of the system may be vary, depending on the
If "TUNED" does not light up and the scanning does
specifications of your iPod/iPhone.
not stop, press
to stop scanning, then perform
When placing or removing the iPod/iPhone, handle the iPod/iPhone
manual tuning (below).
in the same angle as that of the iPod/iPhone connector on the unit
and do not twist or sway the iPod/iPhone to prevent connector
damage.
For manual tuning
Do not carry the system with an iPod/iPhone set on the connector.
Press TUNING MODE
repeatedly until
Doing so may cause a malfunction.
"MANUAL" appears, and then press +/
When placing or removing the iPod/iPhone, brace the system with
one hand and take care not to press the controls of the iPod/iPhone
repeatedly to tune in the desired station.
by mistake.
Tip
To use an iPod/iPhone, refer to the user's guide of your iPod/iPhone.
To reduce static noise on a weak FM stereo station, press FM MODE
Sony cannot accept responsibility in the event that data recorded to
repeatedly until "MONO" appears to turn off stereo reception.
iPod/iPhone is lost or damaged when using an iPod/iPhone with
this system.
To change the AM tuning interval
The default setting for AM tuning interval is 9 kHz (or
Using optional audio components
10 kHz for some areas). Use the buttons on the unit to
perform this operation.
1
Prepare the sound source.
1
Select the AM TUNER function.
Connect additional audio component to the AUDIO
Press AM FUNCTION
on the remote or press
IN jack
on the unit using an audio analog cord
FUNCTION
on the unit repeatedly to select the
(not supplied).
AM station.
2
Turn down the volume.
2
Press
/
to turn off the system.
Press VOLUME
.
3
Press DISPLAY
to change the clock display.
3
Select the AUDIO IN function.
4
Press and hold
and press
/
on the unit.
Press AUDIO IN FUNCTION
"9K STEP" or "10K STEP" appears in the display.
press FUNCTION
on the unit repeatedly.
When you change the interval, all the AM preset
4
Start playback.
stations are erased.
Start playback of the connected component and adjust
the volume.
Note
The system may enter Standby mode automatically if the volume
level of the connected component is too low. Adjust the component's
volume accordingly. See "To turn off the Automatic Standby function. "
Adjusting the sound
To
Press
Adjust the volume VOLUME +/
.
To check the setting
Preset number
BASS BOOST .
Generate a more
1
dynamic sound
2
SOUND EFFECT repeatedly
Set the sound
effect
until desired sound effect is
displayed.
3
Each time you press this button,
repeatedly to select
sound effects are displayed in
the order "ROCK" "POP"
To cancel the timer
"JAZZ" "FLAT. "
Repeat the same procedure as above until "OFF" appears
in step 3, and then press
To change the setting
Changing the display
Start over from step 1.
Notes
To
Press
If the sound source for a Play Timer is set to an FM/AM station
tuned in using auto scanning or manual scanning, when you change
Change
DISPLAY
repeatedly when the
the radio station after setting the Play Timer, radio station tuning for
information on
system is on.
the Play Timer will also changed.
the display
1)
If the sound source for a Play Timer is set to an FM/AM station
Change Display
DISPLAY
repeatedly when the
with a registered preset number, the radio station tuning for the Play
Timer is fixed at what you set for it. Even if you change the radio
mode (see below.)
system is off.
station after setting the Play Timer, the radio station setting for the
Play Timer will not change.
1)
For example, you can view CD/MP3 disc information, such as:
Notes for the iPod/iPhone user
CD-DA disc
Make sure the iPod/iPhone is not playing when using the Play
remaining playing time of a track during playback
Timer.
total remaining playing time
The Play Timer may not be activated depending on the status of the
MP3 disc device
connected iPod/iPhone.
track or file name ("
")
Tip
artist name (" ")
The Play Timer setting remains in effect as long as the setting is not
album name ("
")
canceled manually and clock setting is completed.
The system offers the following display modes.
Display mode
When the system is off
Troubleshooting
Power Saving
The display is turned off to conserve
mode
power. The timer and clock continue
1)
to operate.
1
Clock
The clock is displayed.
2)
on the
2
You cannot set the clock in Power Saving mode.
1)
2)
The clock display automatically turns to Power Saving mode after 8
seconds.
Notes on the display information
General
When the information includes double-byte characters, each double-
on the
byte character will occupy 2 bytes
Characters that cannot be displayed appear as "_"
The system does not turn on.
The following are not displayed:
Is the power cord plugged in correctly?
total playing time for an MP3 disc
. To fast-forward or
total remaining playing time for an MP3 disc
The system has entered Standby mode
remaining playing time for an MP3 file on MP3 disc
unexpectedly.
The following are not displayed correctly:
elapsed playing time of an MP3 file encoded using VBR (variable
This is not a malfunction. The system enters Standby
bit rate)
mode automatically in about 30 minutes when there is
during
folder and file names that do not follow either the ISO9660
no operation or audio signal output. See "To turn off
Level 1, Level 2, or Joliet in the expansion format
the Automatic Standby function. "
The following are displayed:
total playing time for a CD-DA disc (except when PGM mode is
The clock setting or the Play Timer operation
selected and the player is stopped)
has been cancelled unexpectedly.
.
remaining playing time for a track of CD-DA disc
remaining playing time for a CD-DA disc (only when Normal Play
If about a minute elapses with no operation, the clock
mode is selected during playback)
setting or Play Timer setting is cancelled automatically.
ID3 tag information for MP3 files when ID3 version 1 and
Perform the operation again from the beginning.
version 2 tags are used (ID3 version 2 tag information display has
priority when both ID3 version 1 and version 2 tags are used for a
There is no sound.
single MP3 file)
Press VOLUME + to turn up the volume.
up to 64 characters for an ID3 tag, where characters allowed are
uppercase letters (A to Z), lowercase letters (a to z) (lowercase will
Make sure additional audio components are connected
be displayed as uppercase), digits (0 to 9), and symbols (˝ $ % ' ( )
correctly.
* + , – . / < = > ? @ [ \ ] `)
Make sure the function is set to AUDIO IN.
Is anything blocking the ventilation holes of the system?
The specified station may have temporarily stopped
Using the timers
broadcast.
The system offers 2 timer functions. If you use both
Severe hum or noise.
timers, the Sleep Timer has priority.
Move the system away from sources of noise.
Sleep Timer:
Connect the system to a different wall outlet.
You can fall asleep to music. This function works even if
Install a noise filter (not supplied) to the power cord.
the clock is not set.
The remote does not function.
Press and hold SHIFT
and press SLEEP
repeatedly.
Remove any obstacles between the remote and the
With each press of SLEEP
with SHIFT
held
remote sensor
pressed, the setting time is decreased by 10 minutes from
away from fluorescent lights.
a maximum of 90 minutes to minimum of 10 minutes.
Point the remote at the system's sensor
To cancel the Sleep Timer, select "OFF. "
Move the remote closer to the system.
Play Timer:
You can wake up to CD, FM/AM reception, or iPod/
CD/MP3 disc
iPhone at a preset time. Make sure you have set the clock.
1
The sound skips, or the disc will not play.
Prepare the sound source.
Wipe the disc clean, and replace it.
Prepare the sound source, and then press VOLUME
Move the system to a location away from vibration (for
+/ to adjust the volume. You can set the CD,
example, on top of a stable stand).
iPod, FM, or AM function as the sound source.
To start from a specific CD track, audio file, and radio
Play does not start from the first track.
station create your own program.
Return to normal play by pressing PLAY MODE
2
Select the timer set mode.
repeatedly until both "PGM" and "SHUF" disappear.
Press and hold SHIFT
and TIMER MENU
.
Starting playback takes more time than usual.
3
Set the play timer.
The following discs can increase the time it takes to
Press /
repeatedly to select "PLAY SET, " then
start playback:
press
.
a disc recorded with a complicated tree structure
4
a disc that has many folders
Set the time to start playback.
Press /
repeatedly to set the hour, then press
Erroneous display.
. Use the procedure above to set the minutes.
on the remote or
The data stored in the CD-DA, MP3 disc may have
5
Use the same procedure as in step 4 to set the time
been corrupted, perform the transferring again.
to stop playback.
The character codes that can be displayed by this
system are as follows:
6
Select the sound source.
Uppercase (A to Z)
Press /
repeatedly until the desired sound
Lowercase (a to z) (lowercase will be displayed as
source appears, then press
.
7
Turn off the system.
Digits (0 to 9)
Press
. The system automatically turns on
Symbols (˝ $ % ' ( ) * + , – . / < = > ? @ [ \ ] `)
before the preset time.
If the system is on at the preset time, the Play Timer
will not play. Do not operate the system from the time
iPod/iPhone
the system turns on until the playback starts.
There is no sound.
If the sound source is set to an FM/AM station for a
Make sure the iPod/iPhone is connected securely.
timer, the system automatically turns on 15 seconds
Make sure the iPod/iPhone is playing music.
before the preset time. If the sound source is set to
CD, the system automatically turns on 30 seconds
Make sure the iPod/iPhone is updated with the latest
software. If not, update the iPod/iPhone before using
before the preset time. If the sound source is set
to iPod/iPhone, the system automatically turns on
with the system.
30 seconds before the preset time.
Adjust the volume.
The sound is distorted.
Make sure the iPod/iPhone is connected securely.
Press and hold SHIFT and TIMER MENU .
Turn down the volume.
Press /
repeatedly to select "SELECT, " and then
Set the "EQ" setting of the iPod/iPhone to "Off " or
press
.
"Flat. "
Press /
repeatedly to select "PLAY SEL, " and
The iPod/iPhone does not function.
then press
.
Shut down any other iOS applications running on the
iPod/iPhone. For details, refer to the operation manual
supplied with the iPod/iPhone.
.
Make sure the iPod/iPhone is connected securely.
Make sure the iPod/iPhone is updated with the latest
software. If not, update the iPod/iPhone before using
with the system.
Because the operation of the system and the iPod/
iPhone are different, you may not operate the iPod/
iPhone using buttons on the remote or unit. In this
case, use the control buttons on the iPod/iPhone.
The iPod/iPhone cannot be charged.
Make sure the iPod/iPhone is connected securely.
Make sure the system is turned on.
If you cannot fully charge the iPod/iPhone, charge it
again after turning the Automatic Standby function off.
Tuner
Severe hum or noise, or stations cannot be
received. ("TUNED" or "STEREO" flashes on the
display.)
Connect the antenna properly.
Find a location and an orientation that provide good
reception, and then set up the antenna again.
Keep the antennas away from the power cord to avoid
picking up noise.
Turn off nearby electrical equipment.
Make sure the power cord is firmly connected.
Several radio stations can be heard at the same
Find your problem in the checklist below, and take
time.
the indicated corrective action.
Find a location and an orientation that provide good
If the issue persists, contact your nearest Sony dealer.
reception, and then set up the antenna again.
Bundle the antenna cables using commercially available
cord clips, for example, and adjust the cable lengths.
To reset the system to factory settings
If the system still does not operate properly, reset the
system to factory settings.
Use buttons on the unit to reset the system to its factory
default settings.
1
Disconnect and reconnect the power cord, and then
turn on the system.
2
Press and hold and
/
"RESET" appears in the display.
All user-configured settings, such as preset radio
stations, timer, and the clock, are deleted.
To turn off the Automatic Standby function
This system is equipped with an Automatic Standby
function. With this function, the system enters Standby
mode automatically in about 30 minutes when there is no
operation or audio signal output.
By default, the Automatic Standby function is turned on.
Use buttons on the unit to turn off the Automatic
Standby function.
Hold down
while the system is on, until
"AUTO. STBY OFF" appears.
To turn on the function, repeat the procedure until
"AUTO. STBY ON" appears.
Notes
"AUTO. STBY" appears in the display for 2 minutes before the
system enters Standby mode.
The Automatic Standby function is invalid for the tuner function
(FM/AM), even when you have enabled it.
on the unit, and position the unit
The system may not enter Standby mode automatically in the
following cases:
while an audio signal is being detected
.
during playback of audio tracks or files
while the preset Sleep Timer or Play Timer is in process
The system counts down the time again until it enters Standby
mode, even when Automatic Standby function is enabled in the
following cases:
when an iPod/iPhone is connected
when a button on the remote or unit is pressed
when a preset time of the Sleep or Play Timer is started
uppercase)
Other characters appear as "_"
Messages
Precautions
COMPLETE: The preset operation ended normally.
Discs that this system CAN play
CONNECT: The connected iPod/iPhone is executing
Audio CD
authentication.
CD-R/CD-RW (audio data/MP3 files)
DEVICE ERROR: Unpredictable situation (or an
unknown device is connected).
Discs that this system CANNOT play
FULL: You tried to program more than 25 tracks or files
CD-ROM
(steps).
CD-R/CD-RW other than those recorded in music CD
NO DISC: There is no disc in the player, or you have
format or MP3 format conforming to ISO9660 Level
loaded a disc that cannot be played.
1/Level 2, Joliet
NO STEP: All of the programmed tracks have been
CD-R/CD-RW of poor recording quality,
erased.
CD-R/CD-RW that have scratches or are dirty,
NO TRACK: There are no playable files on the CD disc.
or CD-R/CD-RW recorded with an incompatible
NOT USED: You tried to perform a specific operation
recording device
under conditions where that operation is prohibited.
CD-R/CD-RW which is finalized incorrectly
OVER CURRENT: The system has detected a power
Discs containing files other than MPEG 1 Audio Layer-
failure from a connected iPod/iPhone. Remove the
3 (MP3) files
iPod/iPhone from the system and turn the system
Discs of non-standard shape (for example, heart,
power off then back on. If the problem persists, contact
square, star)
your nearest Sony dealer.
Discs that have adhesive tape, paper, or sticker attached
PROTECT: The system has detected a power failure.
to them
Unplug the AC adaptor. If the problem persists, contact
Rental or used discs with attached seals where the glue
your nearest Sony dealer.
extends beyond the seal
PUSH STOP: You pressed PLAY MODE
during
Discs that have labels printed using ink that feels tacky
playback in the CD function.
when touched
READING: The system is reading the information on the
disc. Some buttons do not work during reading.
Notes on discs
TIME NG: The Play Timer start and end times are set to
Before playing, wipe the disc with a cleaning cloth from
the same time.
the center out to the edge.
Do not clean discs with solvents, such as benzine,
thinner, or commercially available cleaners or anti-
static spray intended for vinyl LPs.
Do not expose discs to direct sunlight or heat sources
such as hot air ducts, nor leave it in a car parked in
direct sunlight.
On safety
Completely disconnect the power cord (mains lead)
from the wall outlet (mains) if it is not going to be used
for an extended period of time. When unplugging the
system, always grip the plug. Never pull the cord itself.
Should any solid object or liquid get into the system,
unplug the system, and have it checked by qualified
personnel before operating it again.
The AC power cord can be changed only by a qualified
service facility.
On placement
Do not place the system in an inclined position or in
locations that are extremely hot, cold, dusty, dirty, or
humid or lacking adequate ventilation, or subject to
vibration, direct sunlight or a bright light.
Be careful when placing the system on surfaces that
have been specially treated (for example, with wax, oil,
polish) as staining or discoloration of the surface may
on the unit until
result.
If the system is brought directly from a cold to a warm
location or is placed in a very damp room, moisture
may condense on the lens inside the CD player, and
cause the system to malfunction. In this situation,
remove the disc, and leave the system turned on for
about an hour until the moisture evaporates.
On heat buildup
Heat buildup on the unit during operation is normal
and is not cause for alarm.
Do not touch the cabinet if it has been used
continuously at a high volume because the cabinet may
have become hot.
Do not obstruct the ventilation holes.
On the speaker system
This speaker system is not magnetically shielded, and
the picture on nearby TV sets may become magnetically
distorted. In this situation, turn off the TV, wait 15 to
30 minutes, and turn it back on.
Cleaning the cabinet
Clean this system with a soft cloth slightly moistened
with a mild detergent solution. Do not use any type of
abrasive pads, scouring powder, or solvents, such as
thinner, benzine, or alcohol.
Specifications
Amplifier section
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
(The United States model only)
With 8 ohm loads, both channels driven, from 120 - 10,000 Hz; rated 4.5 watts
per channel minimum RMS power, with no more than 0.7% total harmonic
distortion from 250 milliwatts to rated output.
Power output (rated): 4 watts + 4 watts (8 ohms at 1 kHz, 1% THD)
Continuous RMS power output (reference): 5 watts + 5 watts (8 ohms at
1 kHz, 10% THD)
Input
AUDIO IN (stereo mini jack): Sensitivity 900 mV, impedance 47 kilohms
CD player section
System: Compact disc and digital audio system
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6 µW
* This output is the value measurement at a distance of 200 mm from the
objective lens surface on the Optical Pick-up Block with 7 mm aperture.
Frequency response: 20 Hz 20 kHz
Signal-to-noise ratio: More than 80 dB
Dynamic range: More than 80 dB
Tuner section
Antenna: FM lead antenna
AM loop antenna
FM tuner section
Tuning range:
87.5 MHz 108.0 MHz (100 kHz step)
AM tuner section
Tuning range:
530 kHz 1710 kHz (10 kHz step)
531 kHz 1710 kHz (9 kHz step)
iPod/iPhone section
Compatible iPod/iPhone models:
iPod touch (5th generation)
iPod nano (7th generation)*
iPhone 5
* The iPod nano (7th generation) cannot be controlled by the remote when
the command of "TOOL MENU, " ", " ", " ", " ", " "
, " and "RETURN"
is pressed.
"Made for iPod, " and "Made for iPhone" mean that an electronic accessory has
been designed to connect specifically to iPod or iPhone, respectively, and has
been certified by the developer to meet Apple performance standards. Apple
is not responsible for the operation of this device or its compliance with safety
and regulatory standards. Please note that the use of this accessory with iPod
or iPhone may affect wireless performance.
Speaker section
Full-range speaker: 80 mm, cone type
Rated impedance: 8 ohms
General
Power requirements:
AC adaptor
Input: 120 V 240 V AC, 50/60 Hz
Output: DC 9.5 V 1.8 A
Power consumption: 13 watts
Dimensions (W/H/D):
Approx. 400 mm × 197 mm × 114 mm (15 3/4 × 7 7/8 × 4 1/2 in.)
Mass: Approx. 2.4 kg (5 lb 4 5/8 oz)
Quantity of the main unit: 1 piece
Supplied accessories: Remote Commander (1), AC adaptor (1),
AM loop antenna (1), R6 (Size AA) batteries (2)
Design and specifications are subject to change without notice.
Standby power consumption: 0.5 W
Advertisement
