Panasonic PT-DW17KU Specification
3-chip dlp projector
Hide thumbs
Also See for PT-DW17KU:
- Brochure (8 pages) ,
- Operating instructions manual (179 pages) ,
- Operating instructions manual (186 pages)
Related Manuals for Panasonic PT-DW17KU
Summary of Contents for Panasonic PT-DW17KU
- Page 1 The PT-DW17K is not equipped with a lens. PT DW17K P ro d u c t N u m b e r : 3-Chip DLP ™ Projector P ro d u c t N a m e : As of September 2012. Specifications and appearance are subject to change without notice. 1 / 1 6 SFD12M007-1...
- Page 5 ( 9 -19 / 32 ) ( 9 -19 / 32 ) (1-27/32) ( 23 -15 /16 ) 620 ( 24-13 / 32 )
- Page 6 ∅60.5 (2-3/8) Upper edge of projected image Projected image (11-23/32) (18) Lower edge of projected image Projected image 87.5 87.5 (3-7/16) (3-7/16) (6-7/8)
- Page 7 Screen size Distance to screen (L) Height from the edge of screen to center of lens (H) (diagonal) Zoom Fixed-focus Zoom lenses Fixed- ET-D75LE6 ET-D75LE10 ET-D75LE20 ET-D75LE30 ET-D75LE40 ET-D75LE8 ET-D75LE50 focus Zoom lens Zoom lens Zoom lens Zoom lens Zoom lens Zoom lens Fixed-focus Except...
- Page 9 3-Chip DLP ™ Projector Optical axis shift function allows to shift the position of a projected image as shown below. (Width of (Width of 0.3H 0.3H 0.2H 0.2H projected image) projected image) Standard postition of projected image Standard postition of projected image Install the projector at an angle within the range shown below.
- Page 10 Display mode Display Scanning frequency Dot clock Format resolution frequency (dots)* (kHz) (kHz) (MHz) NTSC/NTSC4.43/PAL-M/PAL60 720 × 480i 15.7 59.9 − VIDEO/S-VIDEO PAL/PAL-N/SECAM − 720 × 576i 15.6 50.0 480i (525i) SDI/RGB/YC 720 × 480i 15.7 59.9 13.5 576i (625i) 720 ×...
- Page 11 Display mode Display Scanning frequency Dot clock Format resolution frequency (dots) (kHz) (kHz) (MHz) 1280 × 720 1280 × 720 37.1 49.8 60.5 HDMI/DVI-D/RGB 44.8 59.9 74.5 76.3 100.0 131.8 120.0 161.6 92.6 1280 × 768 1280 × 768 39.6 49.9 65.3 47.8...
- Page 12 I1 I2 P1 P2 ... Pn Start (2 byte) Semicolon Colon (1 byte) (1 byte) (1 byte) (1 byte) ID: 2 characters Parameters (2 bytes) (undefined length) Command 01 to 64: Address number (3 bytes) 0A to 0Z: Group ID (Control and/or query commands) ZZ: All units (ID ALL) ID designator...
- Page 13 Projector PC (DTE) Command : Parameter Function Callback Standby power on POWER (STANDBY) Standby power off HDMI IIS:HD1 IIS:HD1 INPUT SELECT IIS:DVI IIS:DVI RGB 1 IIS:RG1 IIS:RG1 RGB 2 IIS:RG2 IIS:RG2 IIS:VID Video IIS:VID Quad (four lamps) LPM:0 LAMP SELECT LPM:0 Lamp 1 + 4 LPM:1...
- Page 14 Command : Parameter Function Callback Description Main power status Shutter function status Freeze function status Input signal status HDMI RGB 1 RGB 2 Video On-screen display status Projector run time 00000h –99999h p1p2p3p4p5 Lamp 1 run time Q$L:1 0000h –9999h p1p2p3p4 Q$L:2 Lamp 2 run time...
- Page 15 ADZZ Start ID Address Command Parameter 500 mm (1 ft 8 in) or more 500 mm (1 ft 8 in) 500 mm (1 ft 8 in) or more or more Do not stack projector 100 mm units directly on top of ( 3-15/16 in) one another.
