SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
BISTRO 4500
B Y : S H E R W O O D I N D U S T R I E S L T D
OWNER'S MANUAL
NOTE: This appliance must not be used indoors.
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any phone in your building.
• Immediately call your gas supplier from a neighbour's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the
vicinity of this or any other appliance.
A propane (LP) cylinder not connected for use shall not be stored in the vicinity
of this or any other appliance
.
Advertisement
Table of Contents
Related Manuals for Enviro Bistro 4500 C-10124
Summary of Contents for Enviro Bistro 4500 C-10124
- Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE BISTRO 4500 B Y : S H E R W O O D I N D U S T R I E S L T D OWNER’S MANUAL NOTE: This appliance must not be used indoors.
-
Page 2: Table Of Contents
Table of Contents Safety Precautions...3 Specifications...4 Dimensions...4 Orifice Sizes...4 Clearances To Combustibles...4 Assembly Instructions...5 Tools Required...5 Cart Components...5 Engine Components...6 Side Burner Components (Optional)...7 Rotisserie Components (Optional)...7 Casters and Wheels Installed Onto Cart Assembly...8 Engine Installed Onto Cart Assembly...9 Side Shelf And Utensil Rack Installed Onto Cart Assembly...10 Side Burner Installed Onto Cart Assembly (Optional)...11 Rotisserie Installed Onto Cart Assembly (Optional)...12 Grill Removal...12... -
Page 3: Specifications
The ENVIRO BISTRO is designed for outdoor use only. The ENVIRO gas barbecue must be installed and operated in accordance with the installation requirements of your local gas supply authority or the appropriate installation code in the area of installation. In the absence of local codes, use either the National Fuel Gas code, ANSI Z223.1, or CAN/CGA-B149.1, National gas Code or CAN/CGA-... -
Page 4: Specifications
DO NOT USE THIS APPLIANCE IN AN ENCLOSED AREA, for example: Garages, sheds or enclosed sundecks or any other enclosed areas. Do not use this gas grill under overhead, unprotected combustible materials such as awnings or umbrellas. KEEP THIS APPLIANCE FREE FROM COMBUSTIBLE MATERIALS. -
Page 5: Assembly Instructions
Assembly Instructions Your ENVIRO BISTRO will require some assembly. Please do not use a drill to modify any component, it is not necessary. Inspect all components for damage before assembly begins. If damage is present, please contact your local dealer or a courier company. Replace the damaged components with original manufacturer’s parts, no substitutions will be permitted. -
Page 6: Engine Components
2 plated caster assemblies 2 BBQ wheels Figure 6 NGINE OMPONENTS ● Pre-assembled engine ● Metal Foil Container ● Grill removal tool ● (8) 1⁄4” x 1⁄2” stainless steel bolts Figure 7 The components shown in Figure 8 should be found in the manual bag found inside the engine. -
Page 7: Side Burner Components (Optional)
URNER OMPONENTS ● Pre-assembled side burner ● (2) Shelf gussets ● Cast side burner grill (2 pieces) ● Side burner porcelain diffuser cap ● NG Orifice ● Nutdriver (used to change orifice) ● (10) 1⁄4” x 1⁄2” stainless steel bolts ●... -
Page 8: Casters And Wheels Installed Onto Cart Assembly
ASTERS AND HEELS NSTALLED When the cart cabinet has been emptied the wheels and casters can be installed. Leave the cart body upside down; this will make installing the wheels and casters easier. Components Required: ● Pre-assembled cart ● (2) Stainless steel axle mount ●... -
Page 9: Engine Installed Onto Cart Assembly
NGINE NSTALLED Components Required: ● Rolling cart ● (4) 1⁄4” stainless steel lock washers WARNING: Two (2) people are required to lift the engine onto the cart safely. Empty all the components (frame deflectors, manual bag, and warming tray) from inside the engine to make it lighter to lift. -
Page 10: Side Shelf And Utensil Rack Installed Onto Cart Assembly
HELF TENSIL Components Required: ● Rolling cart with engine ● (12) 1⁄4” x 1⁄2” stainless steel bolts ● (12) 1⁄4” stainless steel lock washers ● Utensil rack The side shelf can be installed on either side but if a side burn is to be installed as well, the side shelf must be installed on the left side (see Figure 18). -
Page 11: Side Burner Installed Onto Cart Assembly (Optional)
URNER NSTALLED Components Required: ● Rolling cart with engine ● Side Burner ● (4) 1⁄4” stainless steel nuts The side burner must be installed on the right side. The initial installation steps for the side burner are very similar to the side shelf so you may refer to Figure 18. 1. -
Page 12: Rotisserie Installed Onto Cart Assembly (Optional)
OTISSERIE NSTALLED Components Required: ● Rolling cart with engine ● (3) Stainless steel thread rolling screws ● Spit bushing 1. Install the motor mounting bracket onto the left side of the engine with the three (3) screws provided. 2. Slide the rotisserie motor into the mounting bracket. 3. -
Page 13: Installing Propane Cylinder In Cabinet
NSTALLING ROPANE YLINDER Secure the tank to the cabinet using the attached propane tank holder. Simply undo the wing nut provided, slide the mount over the collar of the propane tank and tighten the wing nut until secure (see Figure 23). Install the gas line from the propane cylinder as shown in “Hooking Up To Gas Supply -... -
Page 14: Hooking Up To Gas Supply
1⁄2 psi (3.5 kPa) Check the rating label located on the back of this appliance to confirm that the burner valves and orifices are configured to burn Natural Gas. If required, install a Natural Gas conversion kit available through your ENVIRO dealer. -
Page 15: Operating Instructions
3. Turn fuel supply “ON” at the source. 4. Open the lid to the barbecue and do not put your head over gas grill before lighting. Push the center gas control knob counter clockwise to the high flame setting and depress the ignitor button until the burner lights. To light other burners turn the desired knob counter clockwise and depress ignitor button until main burner lights. -
Page 16: Burner Flame Appearance And Adjustment
1. Remove the cooking grates from the gas grill. 2. Remove the flame deflectors located below the cooking grates. 3. Remove the burner tube. Undo one screw and the mounting plate on the rear of the gas grill and lift burner tube out. -
Page 17: Routine Maintenance And Inspection
The location of the burners to the main orifice is vital for safe operation. Check to assure the valve orifices are inside the burner tubes before using the gas grill. If venturi of the burner is not correctly positioned over the valve orifices, explosion and/or fire may occur when lighting the gas grill. - Page 18 This device catches grease and other cooking debris. Check the grease tray and metal foil container for accumulations after using the gas grill and clean as necessary. Use only a mild abrasive cleaner and a soft cloth to clean the drip tray. Clean the drip tray on a regular basis or fire could occur.
- Page 19 Ignition System: The BISTRO is operated with an electronic battery operated ignition system. If, at any time when lighting the gas grill, a sparking sound is not heard it could be that the battery requires replacing. If the battery has been replaced and spark is still not present, check all wiring and spark electrode for breakage or corrosion (see “Troubleshooting”).
-
Page 20: Cooking On Your Grill
REPARING Some precautions should be taken to ensure proper preparation for health safety. 1. Preheat the gas grill for 5-10 minutes before cooking. Clean off any excess grease or food residue deposited on the cooking surfaces. 2. Remove food from the refrigerator shortly before cooking 3. -
Page 21: Temperature Cooking Chart
FOR YOU CONVENIENCE On the lid of this gas grill there is a thermometer. Simply pull thermometer out and stick into food that you are cooking to ensure the internal temperature of the food is correct for your desired taste. - Page 22 Meat Type of Food Weight or Thickness Burgers Roasts; Blade, Sirloin tip Steaks; Porterhouse, Rib, Ribeye, Sirloin, T-bone Filet Mignon Chicken; Parts Chicken; Whole Chicken; Breast, Boneless Cornish Hen Turkey Chops Ham; Steaks Ham; Whole (Bone in) Ham; Whole, Boneless Ribs;...
-
Page 23: Troubleshooting
Tighten the gas connection at the propane tank, HAND TIGHTEN ONLY. Try to shelter your gas grill from strong winds. DO NOT USE IN ENCLOSED AREAS. Detect the flow of gas by smell or by listening for the hiss of gas being omitted. -
Page 24: Parts Diagram - Grill
Parts Diagram - Grill... -
Page 25: Parts Diagram - Hood
Parts Diagram - Hood... -
Page 26: Parts Diagram - Cart
Parts Diagram - Cart... -
Page 27: Parts Diagram - Side Shelf & Burner
Parts Diagram - Side Shelf & Burner... -
Page 28: Parts List
40-000 Barbecue Cover 40-002 Rear Burner Electrode Mount 40-004 Cart Top - Stainless Steel 40-007 Side Burner Lid 40-009 Grill Removal Tool 40-010 Cover Plate - Stainless Steel 40-014 Cart Assembled With 1 Side Shelf - Painted 40-017 Side Shelf - Painted 40-018 Side Burner LP with NG Conversion Kit - Painted 40-019... -
Page 29: Warranty
Warranty Limited Lifetime Warranty Covers manufacturer’s defects on exterior stainless steel components, namely the cart panelling & doors, the hood, condiment bins and handles against perforation (excluding surface corrosion); for part replacement or repair and labour for the first year and part replacement from then on to the original purchaser. It also covers the stainless steel burners for part replacement or repair and labour for the first year and part replacement from then on to the original purchaser. -
Page 30: Installation Data Sheet
Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MODEL:___________________________________ SERIAL NUMBER:___________________________ DATE OF PURCHASE: _____________ DATE OF INSTALLATION:___________ � NATURAL GAS (NAT) INSTALLER’S SIGNATURE: _________________________________________ NAME OF DEALER:...
