Audio Note Kageki User Manual

Congratulations and thank you for your purchase of the Audio Note Kageki mono power
amplifiers. The Kageki is a Pure Class A Parallel Singled Ended valve amplifiers that
uses the highly regarded 2A3 directly heated triode valve. The Kageki produces a level of
performance that is radically superior to current designs and was specifically designed for
sonic performance rather than technical specifications. It also fulfills all Level 5 criteria.
-Pure Class A operation.
-Zero negative feedback.
-Single ended output stage.
-Valve rectification.
-Directly heated Triode.
-Materials and component quality.
This Level 5 amplifier has the following features: Audio Note silver wired output
transformer, silver signal capacitors, AN-Vx silver internal wiring, 2W Tantalum
resistors and the best available NOS valves.
UNPACKING AND INSTALLATION
These amplifiers are shipped without the valves installed. It is necessary to install
the valves first. It is essential that the valves are installed correctly or serious
damage that is not covered by the warranty will result. We recommend that your
dealer does this for you.
Installing the valves
Please take care when unpacking the amplifiers as they are fairly heavy and place on a
suitable clean space (table or floor) it is recommend that you store the packaging
materials in case the unit requires shipping at a later date.
Carefully unwrap all the valves. You will find 1x 5692, 2 x 2A3 and 1x 5U4G valves for
each amplifier.
Looking from the front of the amplifier, the first valve to insert is the 5692 valve which
goes into the first valve base at the front of the amplifier.
Inspect the locating pin on the bottom center of the valve and align with the valve base
(the locating pin can only go in one way round due to a locating spigot) and with gentle
but firm pressure insert the valve.
Looking from the front of the amplifier, the next valve to plug in is the 5U4G valve
which goes into the last valve base at the back of the amplifier.
July 05 1
