Summary of Contents for Evolution Technologies 36NT
- Page 1 .36NT Control Line Evolution Engine ® US E R GUIDE...
- Page 2 valve assembly. Every feature is designed to ensure Introduction success with your new engine. Congratulations on your purchase of the newest and one of the most technically advanced 2-stroke This user’s guide is intended to provide the basic model airplane engines in the world. Whether information to operate and maintain your Evolution you are new to the sport of model aviation or an CL Engine.
-
Page 3: Mounting The Engine
Mounting the Engine Installing the Muffler The muffler mounting accessory package includes mounting screws (2), lock washers (2), muffler gaskets (2) and an L- wrench. Using the included muffler mounting screws and lock washers, attach your choice muffler with the included hex wrench. -
Page 4: Attaching The Propeller And Spinner
Attaching the Propeller and Spinner Attaching the Fuel Lines Using medium silicone fuel tubing, attach the fuel tank’s clunk line to the fuel nipple. This line will supply fuel to the engine. Attach the vent line to the muffler pressure nipple. - Page 5 prop counter-clockwise through 6 -10 complete SetRight Needle Valves revolutions, thus priming the engine. Have a The design of the SetRight needle valve system is such helper hold your airplane. that, during normal operating conditions, the typical user Step 4. Attach the glow driver. will find that the normal range of adjustment allowed by Step 5.
-
Page 6: Why Would Fuel Go "Bad"
Why would fuel go “bad”? How to tell if your glow plug is bad The largest portion of the fuel is methanol (alcohol). The glow plugs on the market today are designed Methanol is hygroscopic; it attracts moisture. This can to provide good service to the user and may last a long cause your fuel to be contaminated with water, which will time or a short time, all dependent upon the way you... -
Page 7: Troubleshooting Guide
Evolution Control Line Engine Specifications Disp Bore Stroke Weight Crank K Items (c.i.) (mm) (mm) (oz) (ISO) Cylinder Propeller EVOE0365 .354" .806" .695" 1/4X28 11x4 or 11x5 E = height F = length G = crankshaft thread size H = muffler bolt spacing Dimensions(mm) EVOE0365 1/4X28... -
Page 8: Warranty Information
WARRANTY INFORMATION Warranty Period Damage Limits Exclusive Warranty- Horizon Hobby, Inc., (Horizon) HORIZON SHALL NOT BE LIABLE FOR SPECIAL, warranties that the Products purchased (the INDIRECT OR CONSEQUENTIAL DAMAGES, LOSS OF “Product”) will be free from defects in materials and PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN workmanship for a period of 2 years from the date of ANY WAY CONNECTED WITH THE PRODUCT, WHETHER... - Page 9 your email to productsupport@horizonhobby.com, or as well as Visa, MasterCard, American Express, and call 877.504.0233 toll free to speak to our product Discover cards. If you choose to pay by credit card, support staff. please include your credit card number and expiration date.
- Page 10 Description Description Crankcase Screw Set, Engine Rear Cover with Gasket Muffler (Standard) Piston & Liner Set (ABC) Muffler (Tongue Style .36) Connecting Rod (Dual Bushing) Muffler Gasket & Mounting Screw Set Wrist Pin w/Clips (Teflon) Spraybar Bracket (Remote) Crankshaft (1/4 X 28) Spraybar (Remote) Cylinder Head High-Speed Needle Valve Ratchet...
- Page 11 Cross-Reference of Evolution .36 CL Part Number # Description .36CL 1 Crankcase EVO036101 2 Rear Cover w/Gasket EVO032102 3 Piston & Liner (ABC) EVO036203CL 4 Connecting Rod (Dual Bushing) EVO032204 5 Wrist Pin w/Clips (Teflon) EVO032213 6 Crankshaft (1/4 x 28) EVO032210 7 Cylinder Head EVO036103...
- Page 12 © 2008 Manufactured Exclusively for Horizon Hobby, Inc. 877-504-0233 www.horizonhobby.com 12958...
