- Page 1 ™ E N J O Y T H E F R E E D O M O F W I R E L E S S N E T W O R K I N G Wireless Ethernet Adapter Installation and User’s Guide E N T E R A S Y S .
- Page 3 Enterasys Networks and its licensors reserve the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
-
Page 4: Vcci Notice
Notice FCC Notice Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 5: Declaration Of Conformity
Manager, Compliance Engineering ____________________________________________________ Title Rochester, NH, USA ____________________________________________________ Location 89/336/EEC 73/23/EEC Enterasys Networks, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Enterasys Networks Limited Network House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England RoamAbout Ethernet Adapter... -
Page 7: Table Of Contents
Preface Purpose of the Manual ........... ix Intended Audience . - Page 8 Table of Contents 4 Ethernet Adapter Manager Installation Installation ............. . . 4-1 Uninstall .
- Page 9 A Terminal Configurator Establishing a Direct Serial Connection ........A-2 Establishing a Telnet Connection .
-
Page 11: Site Requirements
Purpose of the Manual This manual describes how to install and set up the RoamAbout Wireless Ethernet Adapter. Intended Audience This manual is intended for use by personnel who will install and set up the RoamAbout Wireless Ethernet Adapter. Organization of this Document This document is organized as follows: Section Chapter 1... -
Page 12: Associated Documents
Preface Associated Documents The following table lists the RoamAbout products and where to find additional information. Check the RoamAbout Wireless web site regularly for product upgrades and documentation. http://www.enterasys.com/wireless Component RoamAbout Access Point RoamAbout Access Point RoamAbout Access Point Manager RoamAbout 802.11 DS PC Card RoamAbout 802.11 Drivers RoamAbout Client Utility... -
Page 13: Getting Help
Getting Help For additional support related to this device or document, contact Enterasys Networks using one of the following methods: World Wide Web Phone: Internet mail To send comments or suggestions concerning this document, contact the Enterasys Networks Technical Writing Department via the following E-mail address: TechWriting@enterasys.com... -
Page 15: Wireless Infrastructure Network
This chapter describes basic considerations for successfully installing the RoamAbout Wireless Ethernet Adapter. Before installing the Wireless Ethernet Adapter, you must complete the following tasks: Review the site requirements. Select the location to install the Ethernet Adapter. Unpack the Ethernet Adapter, and check the contents of the shipment. Site Requirements Review the following to ensure that all site preparation tasks were completed. - Page 16 Site Requirements Table 1-1: Specifications Parameter Dimensions: (Length x Weight x Height) Input voltage Input current Temperature Relative Humidity Radio Interface Ethernet Interface Serial Interface (optional) 1-2 Preparing for Installation Description 6.2" x 3.9" x 1.0" 5.2 VDC 120 mA (excluding radio card) 0 C to 55 C 0% to 90% (non-condensing) RoamAbout 802.11 PC Card...
-
Page 17: Unpacking And Inspecting
Unpacking and Inspecting Physically inspect all cartons for shipping damage. Report any damage to your shipping carrier. Also verify that you have received the correct basic components and options as listed on the following pages. Report any discrepancies to your Enterasys Sales Representative. -
Page 18: Ethernet Adapter
Unpacking and Inspecting Ethernet Adapter Verify that the following components shipped with your RoamAbout Ethernet Adapter: Description RoamAbout Ethernet Adapter 5.2V Universal AC to DC power adapter DC Power Cable AC Power Cord RS-232 serial cable • CD-ROM containing the RoamAbout Ethernet Adapter Manager software and the RoamAbout Ethernet Adapter Installation and User’s Guide in PDF. -
Page 19: Wireless Ad-Hoc Networks
The RoamAbout Wireless Ethernet Adapter transforms wired devices (for example., desktop computers and printers) into wireless devices. The RoamAbout Wireless Ethernet Adapter is easily integrated into your existing wireless network. The RoamAbout Wireless Ethernet Adapter can be used in the following wireless topologies: Wireless infrastructure networks, which require the RoamAbout Access Point. - Page 20 Wireless Infrastructure Network Figure 2-1: Infrastructure Network Example The re-association capabilities of the IEEE 802.11 standard enable clients to move throughout the wireless LAN area and roam between Access Points. Re-association can occur as long as the Ethernet Adapter has the same network name as the AP to which it is trying to make a connection.
- Page 21 Wireless Ad-Hoc Networks Wireless Ad-Hoc Networks Wireless ad-hoc networks, also known as peer-to-peer or independent networks, do not include Access Points. Instead, the ad-hoc network is a loose association, or workgroup, of computers that can communicate with each other using the PC Card in Ad-Hoc Mode. Figure 2-2 shows a network in which three Ethernet Adapter units are used to provide wireless connectivity between Ethernet devices.
-
Page 23: Installation Procedure
This section describes how to install the RoamAbout Wireless Ethernet Adapter. It also includes the installation of the PC (PCMCIA) wireless LAN card into the Ethernet Adapter. The Ethernet Adapter does NOT include a RoamAbout 802.11 DS PC card. NOTE These cards are sold separately. - Page 24 Installation Procedure 3) If you are planning to mount the Ethernet Adapter (optional), remove the bottom mounting plate as shown in Figure 3-2: Removing the Bottom Mounting Plate 4) Remove the small combs from the end cap. The combs are generally not needed. The combs, when cut to an appropriate NOTE size, are for use only when the Ethernet Adapter is in an environment with extreme vibrations.
- Page 25 5) Gently insert PC card (face up) into the designated slot as shown in Figure 3-3. Figure 3-3: Inserting the PC Card 6) Replace the cap on the Ethernet Adapter that you removed in step 3 by snapping the cap straight down on the body. 7) If you are mounting the Ethernet Adapter, install the bottom mounting plate where desired as shown in the mounting plate and snap it into place.
-
Page 26: Ethernet Adapter Led Indicators
Ethernet Adapter LED Indicators 9) Connect the six-pin DC power cable to the power supply. 10) Connect the AC power cord to the other side of the power supply. 11) Connect the round power plug to the Ethernet Adapter port labeled 5V DC. 12) Insert the AC power cord into the AC socket. -
Page 27: Installation
Ethernet Adapter Manager Installation This chapter describes how to install and configure the Ethernet Adapter Manager. The RoamAbout Ethernet Adapter Manager is used to configure the Ethernet Adapter. You can install it on a PC or workstation running Windows 95/98/NT/2000 or Millennium. The Ethernet Adapter Manager allows you to graphically and remotely: Display a list of Ethernet Adapter stations running on the local network Display and edit the current Ethernet Adapter configuration... -
Page 28: Uninstall
Uninstall 3) Click YES if you agree to the terms presented and allow the continuation of installation. Click NO if you do not agree, and terminate the installation. The Choose Destination window appears. 4) Choose the default path and location. Or, enter a selected path. 5) Click NEXT. -
Page 29: Using The Ethernet Adapter Manager
Using the Ethernet Adapter Manager Starting the Ethernet Adapter Manager To start the Ethernet Adapter Manager, select Start-->Programs-->RoamAbout-->RoamAbout Ethernet Adapter Manager. The RoamAbout Ethernet Adapter Unit List window appears Ethernet Adapter units currently detected. All Ethernet Adapter units are controlled from this main window. -
Page 30: Configuring The Ethernet Adapter
Using the Ethernet Adapter Manager HELP Launches this document. You need the Adobe Acrobat Reader to read this document. Configuring the Ethernet Adapter To configure the Ethernet Adapter, perform the following steps: Highlight the Ethernet Adapter that you want to configure. 2) Click on the Configure button, or double-click on the desired Ethernet Adapter listing. - Page 31 The Configuration window File menu pull-down options allow you to: Save or load a configuration Reset the Ethernet Adapter to factory defaults Set a new password or clear it Access a view of the log files Update the Ethernet Adapter firmware Table 4-2: Configuration Window Tab Information Tab Name Action...
-
Page 32: Saving A Configuration
Using the Ethernet Adapter Manager Saving a Configuration You can save the configuration settings of the Ethernet Adapter to a local file. This feature allows you to restore settings to a known state, or easily configure multiple Ethernet Adapter units with the same settings. 1) Click on the Update and Reset Unit button. -
Page 33: Setting And Removing Passwords
Setting a password prevents unauthorized users from accessing or changing the settings on your Ethernet Adapter. You will need to enter this password each time you want to reconfigure the Ethernet Adapter. Enterasys Networks recommends that you set a password for each Ethernet Adapter. -
Page 34: Upgrading The Ethernet Adapter Firmware
Using the Ethernet Adapter Manager Upgrading the Ethernet Adapter Firmware To update the firmware on your Ethernet Adapter, perform the following steps: 1) Download the latest version of firmware from the RoamAbout Wireless web site, www.enterasys.com/wireless, to the computer that is currently running the Ethernet Adapter Manager. -
Page 35: Changing Your Pc Card Type
Changing Your PC Card Type The Ethernet Adapter Manager is designed to detect the type of PC card you are currently using, and to reset the specific radio parameters accordingly. To change the PC card and retain the network and serial parameters of your old radio type, perform the following steps: 1) With your current PC card, follow the instructions for saving a configuration described in 2) Remove power from the Ethernet Adapter, switch your PC card, and return... - Page 36 Using the Ethernet Adapter Manager Figure 4-2: Log View Window GUI Message Log The Show GUI Message Log displays status messages from the Ethernet Adapter Manager. Event Log The Event Log displays messages generated by the Ethernet Adapter. Event log messages include basic information about the Ethernet Adapter hardware and any status messages generated by the Ethernet Adapter.
- Page 37 Forward Table The Forward Table (Figure Adapter. The table lists the interface, wire or PC card, where each MAC address was observed. The time for each entry indicates the number of seconds until that entry is removed from the forwarding table. Figure 4-3: Forwarding Table Using the Ethernet Adapter Manager 4-3) displays the MAC addresses detected by the Ethernet...
-
Page 38: Pc Card Configuration
PC Card Configuration PC Card Configuration This section describes how to add the Ethernet Adapter to your wireless network. When the Ethernet Adapter has joined your wireless network, the PC card association LED is green. To configure the PC card settings, perform the following steps: Basic Tab Page 1) Open the configuration window for the desired Ethernet Adapter, as described in... - Page 39 3) Enter the Network Name. The Network Name must match the Access Point, or match the name to which you will use to establish a Ad-Hoc network. The Network Name is case sensitive. The Network Name is used to specify a unique IEEE 802.11 wireless network.
-
Page 40: Advanced Tab Page
Detect - detects the first packet received on the wired side, not the radio side. This feature sets the MAC address used by the wireless LAN interface. Check to ensure that the unit is set to DETECT. Enterasys Networks recommends to set this option to DETECT, unless you are performing an advanced configuration. -
Page 41: Encryption Tab Page
3) Select the Transmit Rate from the drop-down menu. 4) Click on the Update and Reset Unit button. Encryption Tab Page The Encryption tab (Figure Encryption is necessary to associate to an Access Point which is configured to deny unencrypted connections. Consult your PC card documentation for a detailed description of how to set up encryption. - Page 42 PC Card Configuration 3) Enter up to four encryption key values. The values for the encryption keys may to be written as either text (ASCII) strings or hexadecimal numbers. Hexadecimal values must be preceded by “0x” and are composed of the numbers 0 to 9 and the letters A to F. Text strings cannot begin with “0x”.
-
Page 43: Configuring The Ethernet Adapter To Connect To A Wired Ethernet Device
Configuring the Ethernet Adapter to Connect to a Wired Ethernet Device Configuring the Ethernet Adapter to Connect to a Wired Ethernet Device You can configure the Ethernet Adapter as a wireless device to connect to a wired unit, such as a computer or Ethernet printer, to your wireless network. The Ethernet Adapter can act as a wireless device, in addition to performing any one of the serial port applications discussed in the following chapters. -
Page 44: Network Configuration
Network Configuration Network Configuration This section describes the network settings necessary to communicate with the Ethernet Adapter. Communicating directly with the Ethernet Adapter provides: the ability to use the serial port applications. the ability to ping the Ethernet Adapter. the ability to remotely configure the Ethernet Adapter via the telnet protocol. To configure the network settings, perform the following: 1) Ensure that you complete the PC card configuration described in the Card Configuration... - Page 45 Figure 4-7: Network - Basic Tab Page 6) Enter the IP address of the gateway if your network uses a gateway (router or firewall). You need to enter the IP address of your gateway if you plan to use the Ethernet Adapter to access computers or other Ethernet Adapter units beyond your Internet router or firewall.
-
Page 47: General Serial Configuration
Chapter 5 General Serial Configuration This chapter describes the general serial settings that are required for all serial port applications. For proper operation, the settings of the Ethernet Adapter always match the settings of the device to which it is connected via the RS-232 port. There are two groups of parameters that need to be configured to accomplish this task: the UART Settings and the Flow Control Settings. - Page 48 Configuration Flowchart Figure 5-1: Configuration Flowchart 5-2 General Serial Configuration...
-
Page 49: Uart Settings
UART Settings UART (Universal Asynchronous Receiver/Transmitter) is the fundamental hardware for serial communication. It controls the speed and method of data transfer of the serial port. To configure the UART settings, perform the following steps: 1) Clicking on the Serial tab. 2) Click on the UART tab. - Page 50 UART Settings 4) Check the Data Bits setting of the device you are connecting to the Ethernet Adapter. Choose the Data Bits setting that matches the Data Bits setting of the device you are connecting to the Ethernet Adapter. Data Bits determine the number of bits used to transmit data.
-
Page 51: Flow Control
Flow Control Flow control is the process of adjusting the flow of data from one device to another to ensure that the receiving device can handle all of the incoming data. Flow control becomes an important factor when one of the devices is capable of transmitting data at a rate faster than the other can receive it. -
Page 52: Flow Control Configuration
Flow Control Flow Control Configuration To configure the Ethernet Adapter flow control, perform the following steps: 1) Click on the Flow Control tab. with the default settings. 2) Check the flow control settings of the device that you are connecting to the Ethernet Adapter. -
Page 53: Wireless Printing
This chapter describes how to configure the Ethernet Adapter to enable wireless printing to a serial printer. If you have an Ethernet printer this section does not apply. To connect to an Ethernet printer, follow the instructions to configure the Ethernet Adapter to a wired device in Chapter The LPD protocol requires an operating system that supports LPD to a remote host, such... - Page 54 Configuring the Ethernet Adapter to Enable Wireless Printing 6) Click on the Flow Control tab. Verify that the Flow control settings of your Ethernet Adapter match those of your printer. If the Flow Control settings do not match, there will likely be errors when NOTE printing.
-
Page 55: A Terminal Configurator
This appendix describes how to use the Terminal Configurator to configure the Ethernet Adapter. The Terminal Configurator is an alternate method used to configure your Ethernet Adapter. The Terminal Configurator is a text-based configuration method. You can access the Terminal Configurator by one of the following methods: Through direct serial connection. -
Page 56: Establishing A Direct Serial Connection
Establishing a Direct Serial Connection Establishing a Direct Serial Connection This method of configuring and managing an Ethernet Adapter uses a serial cable connected from the Ethernet Adapter to a computer running terminal emulation software. To configure the Ethernet Adapter using the Hyperterminal program, perform the following steps. - Page 57 10) Choose None for the Flow control option. The serial port settings needed for use by the Terminal Configurator will NOTE always be exactly as described here, regardless of the General Serial Settings (Chapter 11) Click OK after all of the COM settings have been chosen. The next screen appears blank.
-
Page 58: Establishing A Telnet Connection
Establishing a Telnet Connection Establishing a Telnet Connection This method opens a Telnet connection to the Terminal Configurator on port 23. Port 23 is the default for most Telnet programs. This only works after the Ethernet Adapter is assigned a TCP/IP address. If you need to assign the Ethernet Adapter an IP address you need to use the Ethernet Adapter Manager or the Terminal Configurator using a direct serial connection. -
Page 59: Main Menu Overview
Using the Terminal Configurator Main Menu Overview The section provides a list of main menu selections and their functions. Resume operation This option exits Configuration. It returns the Ethernet Adapter to the settings the Ethernet Adapter had before the Configure button was pressed. Edit configuration Brings up a list of files to edit. -
Page 60: The Editor
Using the Terminal Configurator Edit Configuration Menu The Edit Configuration menu contains three selections/Config files to edit. Return to Main Menu Goes back to the previous menu selections. System Brings up the editor screen with the configuration file for options that are not communication dependent. -
Page 61: Configuration File Format
Configuration File Format The configuration file format is broken down into sections that define a particular grouping of options. Each section contains at the top a section header which is a string of text surrounded by square brackets: [ ] (the section title). After each section header, there is a list of entries containing equal signs. - Page 62 Using the Terminal Configurator [bridge] Bridge provides variables that are common to all radios. Bridge affects the behavior of radios. AP refresh period. Periodically an Ethernet Adapter pings an Access Point. The AP Refresh Period is the time, in units of seconds, between pings. The default for this value is 60 (which should be left at this default).
- Page 63 [software] The [software] section is used to control the receiving and sending of bytes over the serial port. Proper setting of these values can significantly enhance the efficiency of data transmission because the radio is “packet based” and the UART is “stream based.” Stream based data means that the data is transmitted and received one byte at a time, without any mechanism to separate chunks of data from other chunks of data.
- Page 64 Using the Terminal Configurator transmitted immediately. Conversely, if another character is received before this time-out, the timer is restarted from the beginning. The range for this value is from 10 to 65536 milliseconds, though it will always round up to the nearest tens of milliseconds.
- Page 65 Using the Terminal Configurator [flow control] The Ethernet Adapter supports the following six flow control options: Recognize RTS, Generate CTS, Recognize DTR, Generate DSR, Recognize XON/XOFF, and Generate XON/XOFF. It also supports the original RS-232 specification for flow control where CTS is generated only when RTS is asserted.
- Page 66 Using the Terminal Configurator immediately; otherwise, all of the data thereafter would be lost.) The host computer, however, would have to ask permission from the modem to send data. The host would do this by asserting the RTS line. The modem would see this, and check to see if it were ready to accept data.
- Page 67 CTS and DSR are output lines. When set to “negate” or “assert,” they will output a continuous digital value. The value “negate” outputs a logic 1, or “mark” which is electrically negative. This is also the state seen on an RS-232 connector when the cable is unplugged.
- Page 68 Using the Terminal Configurator [telnet] The following section specifies the operating parameters for the Telnet protocol. connect. This entry dictates what kind of prompt is seen on the serial port output. The two choices available are: wait for keystroke and command prompt.
-
Page 69: Network Bindings
Network Bindings This section describes the meaning behind each of the entries that describe network binding. [rmpbind] This binding can be used for both the passthrough protocol and for the I/O control socket setting. protocol. This example uses the RMP protocol so the value of this entry is “rmp.”... - Page 70 Using the Terminal Configurator transmit retry interval. When attempting additional transmit attempts as specified with “transmit try count” above, it can be useful to additionally specify how long to wait between attempts. This setting determines the time period for retransmission attempts. The value is specified in 1/100ths of a second, so that 100 means 1 second.
-
Page 71: Bridged Ethernet (Lan0
serial connect data. The format is the same as in socket connect data. This causes data to be written to the UART once a connection is successful. serial disconnect data. This causes data to be written to the UART when the network connection has been closed. - Page 72 Using the Terminal Configurator [encryption] This value uses the RC4 algorithm as defined in the IEEE Wired Equivalent Privacy (WEP) standard to encrypt data. Enter up to four keys. The standard RoamAbout PC Card supports the 40-bit encryption only. The standard 40- bit encryption uses a 5-character key (or a 10 digit hexadecimal digits).
- Page 73 [ip] The following sections sets the configuration of the IP protocol. ip address. This is the IP address that will be used by other computers to communicate with a particular Ethernet Adapter. netmask. This is a value that, when logical ANDed with the IP address, specifies the range of IP addresses within the local network.
-
Page 75: Problem Solving
Appendix B Problem Solving This appendix contains problem solving information for the RoamAbout Ethernet Adapter. If your Ethernet Adapter is not operating properly, please make sure the Ethernet Adapter is running the latest firmware, and use this guide before contacting Technical Support. If you receive an error message in your log file, save the error in the SAVE CONFIGURATION file. - Page 76 Table B-1: Problem Diagnosis Situation The power light is off or the power light is blinking. The power light is on steady and the status light is on. Radio Association light is not turning on and the Status light is off.
- Page 77 Situation Problem The Ethernet Adapter Invalid connection to is connected to an Ethernet Ethernet cable, but the Ethernet Link Light is not lit. Steps to take • Verify that both ends of the cable are plugged in securely. • If the Ethernet Adapter is attached to a hub, a crossover Ethernet cable must be used.
- Page 78 Table B-2: Event Log Error Table All entries in the event log are preceded by a number. This number is a timestamp used by Technical Support, but is not relevant to looking up items in this table. Error Code Configuration Errors xxxx: [yyyy]: section does not exist xxxx: [yyyy]: “zzzz”: entry...
- Page 79 Error Code xxxx: [yyyy]: “zzzz”: entry is invalid Unable to bring up interface “lanX”. Xxxx: <[yyyy]zzzz>: Unable to add route. UART Error – No Rx Buffer Available Any other errors Problem Steps to take • Check the entry in the Entry zzzz in sec- configuration for zzzz.
- Page 80 Error Code Hardware Errors FLASH failure. Unable to read or write configuration. Initialization of interface “lan0” failed. xxxx: file does not exist. Problem Steps to take FLASH may be Contact Technical Support. damaged. Configuration can- not be accessed or saved. Radio could not be Try each of these steps in order.
- Page 81 This appendix describes how to perform wireless serial line replacement, configure your Ethernet Adapter as a network serial port, and configure your Ethernet Adapter as a serial telnet client. Serial Line Replacement Two Ethernet Adapter’s are required to perform wireless serial line replacement. Serial line replacement can operate with the radio in either Infrastructure or Ad-hoc mode.
- Page 82 Serial Line Replacement To configure for the RMP Pipe protocol, perform the following steps: 1) Complete the Basic Radio Configuration instructions described in If you are replacing a serial line or serial network with two or more Ethernet NOTE Adapter units without using an Access Point, ensure that your radio is using Ad-hoc mode.
- Page 83 Destination Address. This address tells the Ethernet Adapter where to send data received on the serial port. You may enter the RMP address of another Ethernet Adapter for direct serial line replacement. Other possible values are “dynamic” or “broadcast”. Entering “dynamic” causes data to be sent to the Ethernet Adapter from which the unit last received data.
- Page 84 Serial Line Replacement TCP Pipe TCP Pipe, like RMP Pipe, makes no changes to the serial data stream. TCP Pipe differs from RMP Pipe in that it creates two independent network connections for transmitted and received data. Using two connections allows each Ethernet Adapter to detect conditions when it has lost radio contact with the opposite unit, as can occur in environments with poor radio communication.
- Page 85 Network Serial Port This section describes how to configure your Ethernet Adapter as a network serial port. Connection to a network serial port is accomplished over a TCP/IP socket connection. Any program that uses standard TCP/IP network sockets may be used to communicate with the serial port of the Ethernet Adapter.
- Page 86 Network Serial Port TCP Listen Port Configuration Complete the configuration described in and then perform the following steps: 1) Click on TCP Listen Port in the Protocol list. 2) Click on the Listen tab. 3) Type in the port number on which the Ethernet Adapter will listen for a connection.
- Page 87 Serial Telnet Client This section describes how to configure your Ethernet Adapter as a serial telnet client. Telnet is a method to connect and remotely log-in to a host computer or network device. The host computer or device must be running a telnet server for this service to be available. Once the telnet session is established from the Ethernet Adapter, any data received by the serial port of the Ethernet Adapter is sent to the host.
- Page 88 Serial Telnet Client 4) Leave the Reconnect After Shutdown box checked to allow a new session after closing an active one. 5) Click on the Update and Reset Unit button. Command Prompt Connection Configuration This section describes the command prompt connection method for a serial telnet client. The command prompt connection method provides a “telnet prompt”...
