Enox T550 User Manual

Enox user manual mp3 player t550, t560
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Be sure read this user manual before using the EVR-T550/T560
Keep this manual in good custoday it may be useful later.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T550 and is the answer not in the manual?

Questions and answers

Related Manuals for Enox T550

Summary of Contents for Enox T550

  • Page 1 Be sure read this user manual before using the EVR-T550/T560 Keep this manual in good custoday it may be useful later.

  • Page 2: Table Of Contents

    EVR-T550-Eng 11/28/03 4:02 PM Page 2 Table of Contents Getting started Safety notes ...4 Features ...6 Package contents ...8 Names of the parts ...9 Using the player (Basic Operations) Turning the power on/off...11 Selecting folder ...12 Voice recording (VR selection) ...13 Playing back file ...14...

  • Page 3: Evr-T550-Eng 11/28/03 4:02 Pm

    EVR-T550-Eng 11/28/03 4:02 PM Page 4 Safety notes Read this manual completely before using this product. Keep away from the reach of Do not short, disassemble, heat, infants and children. Batteries apply pressure or throw into fire. are dangerous to them. If anyone...

  • Page 4: Features

    EVR-T550-Eng 11/28/03 4:02 PM Page 6 Features Digital music playback Plays back the MP3 and WMA type digital music.(For WMA file playback, bit rate of 64Kbps or more is available.) FM radio reception and recording Available to listen to FM radio and record the FM broadcasting.

  • Page 5: Package Contents

    EVR-T550-Eng 11/28/03 4:03 PM Page 8 Package contents REC/STOP Voice Recorder Earphone USB connection User's Manual Two Batteries cable External device Installation CD Neck strap Phone connection connection cable cord/adaptor If these accessories are damaged or broken, you can get them from the Service Center.

  • Page 6: Turning The Power On/Off

    EVR-T550-Eng 11/28/03 4:03 PM Page 10 LCD display Operation of Internal Speaker Playback Level Resume on/off Folder Sensitivity of Microphone FM RADIO/VOICE/MP3 Function Mode Bit rate Playback Time Track Number Title (Title of a track and musician) Check the remaining battery amount.

  • Page 7: Selecting Folder

    EVR-T550-Eng 11/28/03 4:03 PM Page 12 Selecting folder You can select a folder to playback in the VR or FM Radio mode. Press the Folder selection button (A B/FOLDER) button in the Stop mode. To control the volume level You can control the volume level from 0 to 30 in the Stop or Playback mode.

  • Page 8: Setting The A-B Repeat

    EVR-T550-Eng 11/28/03 4:03 PM Page 14 Playing back file Press the PLAY/STOP button to turn on the power and select the mode – MP3 or VR. In the VR mode, select the folder containing the file to playback by pressing the folder selection button (A B/FOLDER).

  • Page 9: Deleting File

    EVR-T550-Eng 11/28/03 4:03 PM Page 16 Deleting file To delete one music or voice file Press the REC/STOP button to turn on the power and select the mode – MP3 or VR. In the VR mode, select the folder containing the file to playback by pressing the folder selection button (A B/FOLDER).

  • Page 10: Deleting All Files In The Player

    EVR-T550-Eng 11/28/03 4:03 PM Page 18 To delete entire music or voice files Select the MP3 or VR file and press the MENU button. Select the Erase using REW/FF button. Select the “ALL" using the REW/FF button and press the MENU button.

  • Page 11: Setting Menu (When The Mp3 Is Selected)

    EVR-T550-Eng 11/28/03 4:03 PM Page 20 Setting the Intro scan Press the PLAY/STOP button longer than 2 seconds while playing back MP3 or VR files. Starting from the current file, the intro section of all files will be played back for 7 seconds, and the mode will be released and the initial state will be resumed.

  • Page 12: Setting The Repetition

    EVR-T550-Eng 11/28/03 4:03 PM Page 22 Setting My Option (when the MP3 is selected) Setting the EQ mode After pressing the MENU button in the Playback or Stop mode, select the EQ Mode using the REW/FF button. The player will enter the Sound setting mode.

  • Page 13: Setting The Lcd Light

    EVR-T550-Eng 11/28/03 4:03 PM Page 24 Setting the LCD light After pressing the MENU button in the Playback or Stop mode, select the LCD light using the REW/FF button. Select the time you want using the REW/FF button. You can set the flashing time of the LCD light by 7 steps (2 – 7 seconds) after button manipulation.

  • Page 14: Setting The Resume Function

    EVR-T550-Eng 11/28/03 4:03 PM Page 26 Setting the Resume function If you stop playback by pressing the REC/STOP button during playback and start playback again, the playback will be resumed from the last played position. After pressing the MENU button in the Playback or Stop mode, select the RESUME using the REW/FF button.

  • Page 15: Setting The Microphone Sensitivity

    EVR-T550-Eng 11/28/03 4:03 PM Page 28 Setting the Microphone sensitivity You can set the Microphone sensitivity base on your environmental situation, such as the distance of sound source to microphone and noisy level. After pressing the MENU button in the Playback or Stop mode, select the MIC SENSE using the REW/FF button then pressing the MENU button.

  • Page 16: Setting Menu (When The Recording Folder Is Selected)

    EVR-T550-Eng 11/28/03 4:03 PM Page 30 Setting menu (when the recording folder is selected) Select the VR mode while the power is turned on by pressing the REC/STOP button. Press the folder button to select the fonder that will save the file to record among A, B, C or D.

  • Page 17: Listening To Fm Radio

    EVR-T550-Eng 11/28/03 4:03 PM Page 32 Listening to FM radio Push REC/STOP button to the FM direction while the power is turned on. If you select the FM Radio mode, the frequency of last selected will be set automatically. Tuning and saving the station frequency To tune and save the station manually Press the MENU button.

  • Page 18: Listening To Radio With Saved Frequency

    EVR-T550-Eng 11/28/03 4:03 PM Page 34 Listening to radio with saved frequency Press the MENU button. The player will enter the Radio mode. Press the MENU button again to select the “PRESET MODE " using the REW/FF button and press the MENU button.

  • Page 19: Recording While Listening To Fm Radio

    EVR-T550-Eng 11/28/03 4:03 PM Page 36 Recording while listening to FM radio Press the REC/STOP button. The red lamp will flash and the saved folder and number will be displayed. Then, the recording will be started. If you press the Folder button before recording, the recording folder will be selected and saved in the file next to the recorded file.

  • Page 20: Recording By Connecting To Audio

    Press the REC/STOP button in the MP3 player while playing back in the external device. The input details will be heard from the MP3 player earphone and recording will be started. Press the REC/STOP button again to stop recording. To adjust recording sound level, use the audio’s volume control function.

  • Page 21: Connecting To Your Pc

    EVR-T550-Eng 11/28/03 4:03 PM Page 40 Connecting to your PC To connect the player to your PC To install the X-ONE Manager You can upload the file saved in the player to the PC, or download the file saved in the PC to the player.
  • Page 22 EVR-T550-Eng 11/28/03 4:03 PM Page 42 To install the driver on Windows 98/SE/ME/2000 The driver will be automatically installed when you connect the player to the PC after installing the X-ONE Manager. If the PC cannot recognize the player, the “New Hardware Installation Wizard”...
  • Page 23 EVR-T550-Eng 11/28/03 4:03 PM Page 44 To install the driver on Windows XP If you install the X-ONE Manager and connect the product to your PC, the "New Hardware Installation Wizard" window is displayed. Press the [Next] button in each window that appears sequentially.

  • Page 24: Using The X-One Window And Icon

    EVR-T550-Eng 11/28/03 4:03 PM Page 46 Using the X-ONE window and icon Double-click the X-ONE shortcut icon on the desktop window while the USB is connected to run the X-ONE program. Main window Play list sync icon ID3 tag edit icon...

  • Page 25: Uploading File

    EVR-T550-Eng 11/28/03 4:03 PM Page 48 Uploading file 4. The selected files will be uploaded to PC. To rename the file, click the right mouse button and input new name. 2. Select the player file 1. Select the player folder.

  • Page 26: Check Points Before Inquiry

    EVR-T550-Eng 11/28/03 4:03 PM Page 50 Searching for the PC Help 1. Click Help button twice to display information on the PC application. 2. Click Help to display information on the PC application. Check points before Inquiry Isn't the battery empty?

  • Page 27: Product Specifications

    EVR-T550-Eng 11/28/03 4:03 PM Page 52 Product Specifications Model Name EVR-T550 (128M)/EVR-T560 (256M) File Format MP3 and WMA (For WMA file playback, bit rate of 64Kbps or more is available.) Recording Time EVR-T550 Up to 35 hours EVR-T550 Up to 72 hours Dimensions 102.5(H)

  • Page 28: Fcc Note

    : Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user's authority to operate the equipment. Warranty Product VOICE RECORDER & MP3 PLAYER Model EVR-T550 / EVR-T550 Assurance period 1 YEAR Item Sales date yy mm dd...

This manual is also suitable for:

T560Evr-t550Evr-t560
