INSTALLATION & OPERATION MANUAL
MODEL NUMBERS:
Thank you for purchasing this product from a fine line of heating equipment.
We wish you many years of safe heating pleasure with your new heating appliance.
IMPORTANT: IF YOU HAVE A PROBLEM WITH THIS UNIT DO NOT RETURN IT TO
THE DEALER. CONTACT TECHNICAL SUPPORT @ 1-800-245-6489.
These freestanding pellet units are approved for mobile home or doublewide installation with
outside combustion air hook-up. See "Flue System" section of manual.
Mobile home installation should be in accordance with the Manufactured Home and Safety
CAUTION: The structural integrity of the mobile home floor, wall and ceiling/roof must
Please Note the Following Precautionary Statements:
NOTE: WE DO NOT RECOMMEND PELLET STOVES AS YOUR ONLY SOURCE OF HEAT.
England's Stove Works highly recommends the use of smoke detectors and
Carbon Monoxide detectors with any hearth product, including this unit. Follow all
manufacturer's instructions when using smoke or Carbon Monoxide detectors.
CAUTION: Please read this entire manual before installation and use of this pellet fuel
burning room heater.
Keep children, furniture, fixtures and all combustibles away from any heating
appliance.
WARNING: USE OF OUTSIDE AIR IS MANDATORY WITH THIS UNIT.
DO NOT OPERATE UNIT WITH HOPPER OPEN. LID MUST BE SHUT AND TIGHTLY SECURED.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE,
BODILY INJURY OR EVEN DEATH. FOR YOUR SAFETY AND PROTECTION, FOLLOW ALL
THE INSTALLATION INSTRUCTIONS. CONTACT YOUR LOCAL BUILDING OR FIRE
OFFICIALS FOR RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
(INCLUDING PERMITS) IN YOUR AREA.
25-PDV
25-PDVE
Save These Instructions.
Mobile Home Use:
Standard (HUD), CFR 3280, Part 24.
WARNING: Do Not Install in Sleeping Room
be maintained.
DO NOT OPERATE WITH DOOR OPEN
SAFETY NOTICE
Questions? Need Parts or Options?
55-SHP22
55-TRP22
55-SHP22E
55-TRP22E
www.englanderstoves.com
Rev. 5/06
Advertisement
Table of Contents
Related Manuals for England's Stove Works 55-TRP22E
Summary of Contents for England's Stove Works 55-TRP22E
- Page 1 Please Note the Following Precautionary Statements: NOTE: WE DO NOT RECOMMEND PELLET STOVES AS YOUR ONLY SOURCE OF HEAT. England’s Stove Works highly recommends the use of smoke detectors and Carbon Monoxide detectors with any hearth product, including this unit. Follow all manufacturer’s instructions when using smoke or Carbon Monoxide detectors.
- Page 2 A letter from our Technical Support department: Thank you for purchasing this fine product from England’s Stove Works! England's Stove Works was started, and is still owned by, a family that believes strongly in a "Do It Yourself" spirit – that’s one reason you found this product at your favorite “Do It Yourself”...
- Page 3 Read and comply with the instructions in this manual. This unit should be tested (dry run) before loading pellets for 20 minutes. The stove should automatically shut itself off after the 20-minute dry run.
-
Page 4: Unit Preparation
It is important to note that this stove is equipped with a dual auger system. The top auger runs intermittently and drops pellets to the bottom auger; the bottom auger runs constantly and simply pushes the pellets forward to the burn pot. - Page 5 Occasionally in shipping, the impingement (baffle) plate may shift out of its proper position. If this is the case with your stove, follow these instructions to return the plate to its proper position. Remove the plate from the stove, holding the plate by its tab handle, with the cutout notch facing upwards.
-
Page 6: Flue System
If you live in an area that has heavy snowfall, it is recommended the installation be taller than three feet (3’) to get above the snowdrift line. The same type installation can be used if your stove is below ground level by adding the clean- out section and vertical pipe inside until ground level is reached. - Page 7 Connect a three inch (3”) tee with clean-out to the pipe adapter -- seal this with high temperature stove cement, then extend your pipe to the installed reducer at the thimble. If the thimble is in the ceiling, the pipe will go straight up, but if the thimble is in the wall another 90-degree elbow will be required to make the connection.
-
Page 8: Floor And Wall Protection
The protection should be U.L. approved or equal, and should be large enough to provide a minimum of six inches (6”) behind and on both sides of the stove. The clearance in front of the stove should be at least six inches (6”). This freestanding pellet unit will need a minimum 36”... -
Page 9: Start-Up Procedure
Do not burn trash (paper bags, etc.) in this unit. This stove has an induced draft system and is designed to operate continuously, as frequent shutdown is not required. The digital control board operates the unit with a time delay-relay system;... -
Page 10: Shutdown Procedure
The red light will then shut off and the entire stove will be shut down. The hotter the unit is operating, the longer it will take for the stove to complete the Shut-Down cycle. -
Page 11: Daily Operation
NOTE: Remember: 1) It is very important for the unit to be vented properly (see instructions on Outside Air), as the natural draft is needed to clear the smoke from the stove. 2) Do not open the hopper lid (or the unit’s door). This may cause fire to burn in the hopper. -
Page 12: Ash Removal And Disposal
Press the “OFF” touch pad and allow the stove to burn for five (5) minutes prior to opening the door. A long-handled screwdriver or long-handled putty knife can be used to scrape off any build-up or crust in the burn pot area. - Page 13 The stove and the flue system should be given a complete cleaning at the end of the heating season. Remove the burn pot assembly, clean it thoroughly, and re-install it (refer to Illustration 4);...
-
Page 14: Maintenance
WARNING: To perform any maintenance inside the rear of the unit, the stove must be out (no fire), cooled down and unplugged. Electrical shock can occur if the unit is not unplugged from power. - Page 15 The Convection (room air) Blower (Part # PU-4C447) is located on the left side of the unit and can be removed by disconnecting the power leads and removing the four mounting screws. Once this is done, the blower will slide out of the stove. This procedure can be reversed to install a new blower.
- Page 16 This part can be removed from the unit by loosening the two outside screws and pulling the board back to the inside of the stove. The rear access panel should be removed prior to removing the control board. A 5-amp “quick-blow” fuse is used on this Control Board.
- Page 17 Consult a professional installer and/or call Technical Support if you have any questions. IMPORTANT SAFETY NOTE: white), the stove is over-fired. This condition could cause a house or chimney fire. Do not operate your unit too hot, or over-firing may result.
- Page 18 Adjusting your Hopper Lid Latches The seals around the top of the pellet hopper are important to safe and efficient operation of the unit. The latches installed on these units are designed to pull the hopper lid tight against this seal. Over the course of operation as these seals “wear in”...
-
Page 19: Accessory Items
“Start-up Procedure” for information on cold starts. There is one piece of J-Channel trim in this kit that snaps onto the ash apron lip of the stove. Match the channel with the correct edge of the ash apron, then remove the protective covering from the trim and force the piece onto the edge. - Page 20 REPLACEMENT PARTS, ACCESSORIES AND OPTIONS AC-GGK Glass Gasket Kit (gasket only, no glass) AC-DGKC Door Gasket Kit (#2 on diagram) AC-114 Brass Louvers (#26 on diagram) (2001 and later Models; for earlier models call 800-245-6489 for AC-112 louvers) AC-114BN Nickel Louvers (#26 on diagram) AC-G9 9”...
- Page 21 Pellet Stove – Exploded View Diagram Illustration 4 Dimensions of your pellet unit: 28 ½”W x 30”H x 28 ½”D 375 lbs. (Approx. 13 ½” height from floor to center of exhaust)
-
Page 22: Troubleshooting Guide
1. Remove auger and clean 2. Re-align auger 1. Check blower for material 2. Check impeller blower screw 1. Check stove connection 2. Check settings; always start unit on “5” to “9”setting 3. Check igniter for buildup 1. Check for flue blockage (nests, rodents, excess soot, etc.) - Page 23 Have this information on hand if you phone the factory or your dealer regarding this product. Retain for your files: Model Number __________________________ Date of Purchase ________________________ Date of Manufacture _____________________ LIMITED 5 YEAR WARRANTY FROM THE DATE OF PURCHASE TO THE ORIGINAL OWNER The manufacturer extends the following warranties: Five Year Period: 1.
-
