GV-R7032T/GV-R7064T
RADEON
7000 Graphics Accelerator
TM
USER'S MANUAL
¤¤¤å¨Ï¥Î¤â¥U
REV. 1.02
1 2 M D - R 7 0 6 4 T- 1 0 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-R7032T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigabyte GV-R7032T

Summary of Contents for Gigabyte GV-R7032T

  • Page 1 GV-R7032T/GV-R7064T RADEON 7000 Graphics Accelerator USER'S MANUAL ¤¤¤å¨Ï¥Î¤â¥U REV. 1.02 1 2 M D - R 7 0 6 4 T- 1 0 2...
  • Page 2 Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineer- ing or disassembly is prohibited. Jul. 03, 2003 Taipei, Taiwan GV-R7032T/GV-R7064T Graphics Accelerator - 2 -...

  • Page 3: Table Of Contents

    Table of Contents 1.INTRODUCTION 1.1. PREFACE ................... 4 1.2. Key Feature ................4 2.HARDWARE INSTALLATION 2.1. UNPACKING ................5 2.2. BOARD LAYOUT ................. 6 2.3. HARDWARE INSTALLATION ............7 3.SOFTWARE INSTALLATION 3.1Win98 / WinME /Win XP Driver And Utilities Installation ....... 9 3.1.1 Operating system requirement ..........

  • Page 4: Introduction

    1.INTRODUCTION 1.1. PREFACE GV-R7032T/GV-R7064T delivers enhanced 3D and 2D graphics performance for today’ s demanding applications. Powered by the ATi RADEON™ 7000 graphics processor and 32 / 64 MB DDR memory; GV-R7032T/GV-R7064T features HYPER Z™ technology to increase effective memory bandwidth and PIXEL TAPESTRY™...

  • Page 5: Hardware Installation

    DO NOT APPLY POWER TO YOUR SYSTEM IF IT HAS BEEN DAMAGED ON THE CARD. In order to ensure your graphics card working correctly, please use official Gigabyte BIOS only Use none official gigabyte BIOS might cause problem on the graphics card.

  • Page 6: Board Layout

    2.2. BOARD LAYOUT GV-R7032T (32MB DDR) GV-R7064T (64MB DDR) VGA Monitor Connector (15pin) TV-Out VGA Monitor Connector VGA Output (15pin) Analog LCD Monitor Analog Monitor TV-OUT AV Output NTSC / PAL TV S-VideoOutput Projector GV-R7032T/GV-R7064T Graphics Accelerator - 6 -...

  • Page 7: Hardware Installation

    2.3. HARDWARE INSTALLATION Installing Your Graphics card. Now that you have prepared your computer, you are ready to install your graphics accelerator card. To install your graphics accelerator card: 1. Power off the computer and monitor, then disconnect the display cable from the back of your computer.
  • Page 8 To TV or VCR To VGA Monitor You are now ready to proceed with the installation of the Graphics card driver. For detailed instructions, select your operating system from the list below. GV-R7032T/GV-R7064T Graphics Accelerator - 8 -...

  • Page 9: Software Installation

    Installation" to install the driver for your GV-R7032T/GV-R7064T graphics accelerator. 3.1.1.Operating system requirement l If your OS is Microsoft Windows, when loading the GV-R7032T/GV-R7064T drivers for the system, please make sure your system ( Win 98/98SE or Win ME / Win2000 / Win XP) has installed DirectX or later.

  • Page 10: Directx Installation

    DirectX of your operating system to what is required for your graphics accelerator hardware to run to its best performance. For example, if your graphics accelerator can support DirectX 8.1, updating with DirectX 9.0 can upgrade your operating system to the fullset of DirectX 8.1. GV-R7032T/GV-R7064T Graphics Accelerator - 10 -...
  • Page 11 3.Click "Next" icon. 4.Click "Finish" icon to restart computer. - 11 - Software Installation...

  • Page 12: Driver Installation

    The following is the step-by-step installation guide. Step 1: New Hardware Found After GV-R7032T/GV-R7064T is inserted into your computer at the first time, the windows will automatically detect a new hardware in the system and pop out a "New Hardware Found"...
  • Page 13 3.Click "NO" icon. After the system has finished loading, insert the GV-R7032T/GV-R7064T driver CD disk into your CD-ROM, and then you can see the AUTORUN window. If it does not show up, please run "D:\setup.exe". Step 5: Driver Setup 1. Click "Windows XP Driver(Radeon VE Series)"...
  • Page 14 2.Click "Yes" icon. 3.Click "Express" than click "Next" icon. 4.Click "Finish" icon to restart computer. GV-R7032T/GV-R7064T Graphics Accelerator - 14 -...

  • Page 15: Utilities On Driver Cd

    3.1.4.Utilities on driver CD The utilities include Display Driver and V-Tuner utilities. Please browse the driver CD for detail. Other Utility (V-Tuner and Hydravision) A.Installing V-Tuner Utility Click "V-Tuner" Item. 2.Click "Next". 3. Enter your name and company. 4. Click "Finish" to restart computer. - 15 - Software Installation...

  • Page 16: Taskbar Icon

    You may click the "Display Properties" item, and then click Settings. Click "Advanced" after clickng Settings. Click the appropriate tab to change your display settings. Right click the icon. You can link to GBT website for updated information about the graphics card, latest drivers, and other information. GV-R7032T/GV-R7064T Graphics Accelerator - 16 -...
  • Page 17 V-Tuner (Overclock Utility) V-Tuner lets you adjust the working frequency of the graphic engine and video memory (Core Clock and Memory Clock) Min V-Tuner Display & Adjust Close V-Tuner Core Clock Display Memory Clock Display Core Clock Display & Adjust Memory Clock This Page Close V-Tuner To...
  • Page 18 VGA Info VGA Info lists the relevant information about your card. Color Adjust Color Adjust allows you to make color adjustments, such as brightness, contrast, and gamma values for each or all of RGB colors. GV-R7032T/GV-R7064T Graphics Accelerator - 18 -...
  • Page 19 After installation of the display drivers, you will find an ATi icon on the taskbar's status area. Clicking this icon open the ATi control panel. 1.Using Single Display HYDRAVISION ™ HYDRAVISION and the Desktop Manager are activated whenever Windows starts. Installing ™...

  • Page 20: Property

    Show ATI icon on taskbar adds or removes the ATI icon from the taskbar. n Disable quick resolution feature is accessible by left-clicking the ATI icon in the taskbar. n Reduce DVI frequency on high-resolution displays enables or disables to reduce the DVI frequency when using high-resolution. GV-R7032T/GV-R7064T Graphics Accelerator - 20 -...
  • Page 21 OpenGL Properties: The OpenGL properties page gives you complete control of the OpenGL settings. n Main Settings slider Moving the slider to the left will maximize appli- cation performance, while moving the slider to the right will provide excellent 3D image quality. Moving this slider from one position to the next changes the individual Custom Settings sliders found below.
  • Page 22 Note that most applications will not be affected by activating this feature. l Defaults button allows you to reset the OpenGL Compatibility Settings to default values. n Defaults button This button allows you to reset the OpenGL Settings to default values. GV-R7032T/GV-R7064T Graphics Accelerator - 22 -...
  • Page 23 Direct 3D Properties: The Direct 3D properties page allows you to adjust the Direct 3D settings. n Main Settings slider Moving the slider to the left will maximize applica- tion performance, while moving the slider to the right will provide excellent 3D image quality. Moving this slider from one position to the next changes the individual Custom Settings sliders found below.
  • Page 24 Defaults button allows you to reset the Direct 3D Compatibility Settings to default values. n Defaults button This button allows you to reset the Direct 3D Settings to default values. GV-R7032T/GV-R7064T Graphics Accelerator - 24 -...
  • Page 25 Color Properties: The Color Properties is used to adjust the color settings. It also allows gamma control for video playing of the Video Overlay. The color settings affect all display devices mapped to the view.You can change red, green, and blue display colors. Set Desktop and Video Overlay brightness (gamma) levels can also be changed.
  • Page 26 SMARTGART(tm) Properties: The SMARTGART Properties ensures system stability by automatically performing a variety ™ of bus tests that determine your optimal graphics accelerator settings. Changing these settings might result in system instability. GV-R7032T/GV-R7064T Graphics Accelerator - 26 -...

  • Page 27: Display Properties

    Display Properties: If you VGA card is equipped with a S-Video connector , you can use a second output device (e.q. a TV or a computer monitor) as part of your operating desktop extending your desktop to second device or copying your desktop on the second device. Select Display Type Enable /Disable”...

  • Page 28: Windows 2000 Driver Installation

    ® version 2 (or later) before installing the graphics accelerator driver. With Windows 2000 running on your computer, you need to install the GV-R7032T/GV- ® R7064T driver to take advantage of the higher performance, resolutions, and special graphic features of the Graphics card. To ensure you install the latest driver, use the Installation CD that shipped with your Graphics card.

  • Page 29: Troubleshooting Tips

    4. Troubleshooting Tips The following troubleshooting tips may help if you experience problems. Contact your dealer or GBT for more advanced troubleshooting information. n Check that the card is seated properly in the AGP slot. n Ensure that the display cable is securely fastened to the card's display connector. n Make sure that the monitor and computer are plugged in and receiving power.

  • Page 30: Appendix

    / Windows XP. please use the bootable disk to MS-DOS mode) 3. Change the command path to the file location C:\> or A:\> 4. Reflash BIOS command as below : C:\> atiflash -p 0 <filename> 5. Reboot your PC when it's done. GV-R7032T/GV-R7064T Graphics Accelerator - 30 -...

  • Page 31: Resolutions And Color Depth Table

    5.2.Resolutions and Color Depth Table RADEON 7000 2D Display Modes Display Refresh Hor. Pixel Color Depth (bpp) Screen Rate Scan Clock 8bpp(256 color) 16bpp(65K color) 32bpp(16.7M) Resolution (Hz) (KHz) (Mhz) Standard mode High mode True mode 31.5 25.2 37.9 31.5 37.5 31.5 640x480...
  • Page 32 1280x1024 75 80.0 135.0 91.1 157.5 97.0 169.2 108.5 190.9 131.6 233.7 64.2 137.7 71.9 155.4 1600x1200 60 75.0 162.0 82.2 178.9 93.8 202.5 95.2 208.7 106.3 229.5 116.4 257.0 127.1 280.6 To be continued.. GV-R7032T/GV-R7064T Graphics Accelerator - 32 -...
  • Page 33 DDisplay Refresh Hor. Pixel Color Depth (bpp) Screen Rate Scan Clock 8bpp(256 color) 16bpp(65K color) 32bpp(16.7M) Resolution (Hz) (KHz) (Mhz) Standard mode High mode True mode 1792x1344 60 83.5 203.0 105.2 259.3 119.9 295.5 1800x1440 60 89.4 219.5 1920x1080 60 67.0 172.7 78.6...
