GE Profile PS978STSS Features

PS978STSS
GE Profile Slide-In Double Oven Electric Range
™
Dimensions and Installation Information (in inches)
Note: To reduce the possibility of scorching the side walls above the countertop
KW Rating
when no load is present on burners, it is recommended that a minimum 6"
240V
14.8
spacing from adjacent side wall be allowed for possible extended high-heat
element operation.
208V
10.8
Receptacle Locations: For all 30" Slide-In Ranges locally approved flexible
Breaker Size
service cord or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location of electrical
240V 40 Amps
outlet box. Recommended outlet locations allow range to be installed directly
208V 40 Amps
against rear wall.
Minimum dimensions between cooktop, walls and above the cooktop:
A. Make sure the wall covering, countertop, flooring and cabinets around the range can
withstand the heat (up to 200°F) generated by the range.
B. Allow 30" minimum clearance between surface units and bottom of unprotected wood or
metal cabinet, or allow a 24" minimum when bottom of wood or metal cabinet is protected
by no less than 1/4" thick flame retardant millboard covered with not less than No 28 MSG
sheet metal, (.015"), .015" thick stainless steel, .024" aluminum or .020" copper. Acceptable
electrical outlet area. Orient electrical receptacle so the length is parallel to floor.
C. This appliance has been approved for 0" spacing to adjacent surfaces above the
cooktop. However, a 6" minimum spacing to surfaces less than 15" above the cooktop
and adjacent cabinet is recommended to reduce exposure to steam, grease splatter
and heat. To reduce the risk of burns or fire when reaching over hot surface elements,
cabinet storage space above the cooktop should be avoided. If cabinet storage space is
to be provided above the cooktop, the risk can be reduced by installing a range hood that
projects at least 5" beyond the front of the cabinets. Cabinets installed above the cooktop
must be no deeper than 13".
Installation information: Before installing, consult installation instructions
packed with product for current dimensional data.
For answers to your Monogram, GE Profile
®
GE appliance questions, visit our website at
®
geappliances.com or call GE Answer Center
service, 800.626.2000.
or
™
®
Note: Use a 4'power cord to prevent
interference with unit when installing.
All GE ranges are equipped with
Listed by
an Anti-Tip device. The installation
Underwriters
of this device is an important,
required step in the installation Laboratories
of the range.
Specification Revised 8/11
220455
