Sanyo PLC-WTC500L Command List

% ¡ Transmission format of LCD projector operation key
: NEC Format (single command / command pipelining mode)
% ¡ Transmission format of PC mouse operation button (mouse cursor button) / L / R key
: Interlink Mouse Code Format (Includes 3 bit of ID)
% ¡ Format for the transmission of OSD Laser operation button (mouse cursor button)
: Interlink OSD Mouse Code Format (Includes 3 bit of ID)
% ¡ Custom Code + Custom Code
: 8 patterns as below
33h+00h(Default; code1),33h+11h(code2),33h+22h(code3),33h+33h(code4),
33h+44h(code5),33h+55h(code6),33h+66h(code7),33h+77h(code8)
Key
No.
S1
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
S12
S13
S14
S15
S16
S17
S18
S19
S20
S21
S22
S23
S24
S25
S26
S27
S28
SOB1
*1ÿ e ÿ e ÿ e Transmit code for Mouse *2ÿ e ÿ e ÿ e Transmit code to set Laser Pointer / OSD Laser to ON/OFF
PLC-WTC500L IR Command List
Data Code
(HEX)
*1 L-CLICK
11 ON
10 OFF
38 INPUT 1
39 INPUT 2
06 INPUT 3
89 AUTO PC
43 FREEZE
16 INFO
8C CURSOR UP
1E CURSOR LEFT/VOLUME -
1D CURSOR RIGHT/VOLUME +
8D CURSOR DOWN
1C MENU
0F SELECT
*1 R-CLICK
8A P-TIMER
88 D. ZOOM
82 SCREEN
80 ZOOM
87 FOCUS
40 LENS SHIFT
07 PIP
5C PIP VOL
5B KEYSTONE
84/85 *2 LASER
0B MUTE
8B SHUTTER
*1 Mouse Cursor button
Function
; Back-side Click Trigger Key
1 / 1
2009/05/07
