BUILT BETTER THAH IT HAS TO BE
Owner's
Manual
Bottom
Freezer
Refrigerator
Ordering
parts
and
accessories?
Questions
about
your
features?
Please contact us with your model and serial number:
Consumer Affairs Department
Amana Appliances
2800 - 220th Trail
Amana, lowa 52204
Ph# 1(800)843-0304
in U.S.A.
1(866)587-2002
au Canada
Internet: htlp://www.amana.com
Keep
instructions
for
future
reference.
Keep this manual and your sales receipt together in a safe
)lace in case warranty service is required.
Contents
Introduction ............................................................
2
Important Safety Information ................................. 3
Installing Your Refrigerator .................................... 4
How to Remove the Doors and Hinges ............ 4
How to Reverse the Doors ................................ 5
How to Install and Remove Handles ................ 5
How to Replace the Doors and Hinges ............ 6
How to Remove and Install the Pullout Drawer 7
How to Connect the Water Supply ..................... 8
How to Level Your Refhgerator .......................... 9
How to Adjust the Temperature Controls .......... 9
Fresh Food Features ........................................... 10
Intedor Shelves ................................................ 10
Door Storage ....................................................
10
Accessories .....................................................
10
Drawers ........................... 11
Storage Drawers ..............................................
11
Freezer Features ................................................. 12
Pdrnary Features ............................................. 12
Shelves ............................................................
12
Drawers ...........................................................
12
Door Storage .................................................... 12
Accessories .....................................................
13
Hints and Care ....................................................
14
How to Clean Your Unit .................................... 14
How to Remove and Replace Light Bulbs ...... 15
Trouble Shooting ................................................. 16
Wan'anty ...............................................................
19
Part No. 12642702
Printed in U.S.A. 01102
Advertisement
Table of Contents
Related Manuals for Amana ARB1917CW-PARB1917CW1
Summary of Contents for Amana ARB1917CW-PARB1917CW1
-
Page 1: Table Of Contents
Consumer Affairs Department Hints and Care ............ Amana Appliances How to Clean Your Unit ........14 2800 - 220th Trail Amana, lowa 52204 How to Remove and Replace Light Bulbs ..15 Ph# 1(800)843-0304 in U.S.A. Trouble Shooting ..........16... - Page 2 To locate an authorized servicer, call 1-800-NAT-LSVC (t-800-628-5782), Amana's strong warranty. This plan or call 1(319)622-5511 if outside the U.S.A. You may also contact us on the web at covers parts, labor, and travel charges.
- Page 3 Important Safety Information What Need to Know Recognize Safety Symbols, Words, Labels about Safe_ Instructions DANGER Warning and Important Safety DANGER--immediate hazards which WILL result in severe personal injuryor Instructions appearing in this manual death, are not meant to cover all possible conditions and situations that may WARNING...
- Page 4 Installing Your Refrigerator These instructions were provided to aid you in the installation of your unit. Amat_a cannot be responsible for improper installation. to Transport Your Unit do I measure Follow these tips when moving the unit to final location: NEVER transport unit on its side, If an upright position is not possible, lay unit on its back.
- Page 5 Installing Your Refrigerator IMPORTANT: When working directly on doors, place doors to Reverse Doors on a nonabrasive surface protected by towels or rugs to avoid damage to door finish. Remove Doors Hinges. Perform all steps listed in How bottom edge of fresh fooa Transfer...
-
Page 6: Installing Your Refrigerator
Installing Your Refrigerator to Install Remove Handles ,.o,,tJ,,,,._ Removing Fresh Food Side-Mounted Handles Installing Fresh Food Side-Mounted Handles Removing handles may be necessary when transporting unit If installing handles for the first time, the fresh food handles through tight spaces, or when reversing the door. can be located on the back of the relhigerator. - Page 7 Installing Your Refrigerator to Remove Install Pullout Drawer WARNING To avoid electrical shock which can cause severe personal injury or death, disconnect power to refrigerator before removing doors. After replacing doors, connect power. CAUTION To avoid possible injury, product, or propertydamage, you will need two people to perform the following instructions. Installing Pullout Drawer...
-
Page 8: How To Connect The Water Supply
Installing Your Refrigerator to Connect Water Supply WARNING To reduce the risk of injury or death, follow basic precautions, including following: Read all instructions before installing device. DO NOT attempt installation if instructions are not understood or if they are beyond personal skill level Observe all local codes and ordinances. -
Page 9: How To Level Your Refhgerator
Installing Your Refrigerator Level Your Refrigerator If your refrigerator requires an ice maker water supply connection, proceed to How to connect the water supply section before levelin_ your refrigerator. A CAUTION To protect personal propertyor unit from damage, observe the following: •... -
Page 10: Fresh Food Features
Fresh Food Features nterior Shelves Door Storage Dairy Center _]g CAUTION The dairy center provides convenient IIA___F_ To avoid personal injury or property damage, observe the i i__L_.__jr _ ,._ storage for items such as butter, following: yogurt, cheese, etc. This compartment I _m'_'_-__ •... -
Page 11: Climate-Controlled Drawers
Fresh Food Features Climate-Controlled Drawers Humidity-Controlled Crisper Drawers The crisper drawer keeps produce fresh longer by providing an environment with adjustable humidity. The crisper controls regulate the amount of humidity in the crisper drawer. Use the low setting for produce with outer skins. Use the high setting for leafy produce. Controls Temperature-Controlled Drawer... -
Page 12: Freezer Features
Freezer Features Primary Features avoidproperly d amage, observethefollowing: CAUTION Do not force ice maker arm down or up. Automatic Maker (some models) Do not place or store anything in ice storage bin. Drawers Using Ice Maker for the First Time .. -
Page 13: Accessories
Freezer Features Accessories • ice Cube Tray (some models) The ice cube tray provides an area to JJ_;_,,_ Ireeeze cubes for manual dispensing of _,_" To re_ease ice cubes from tray, hold tray upside down over a storage container and twist both ends of tray until cubes release. -
Page 14: Hints And Care
• product? WARNING Amana has a cleaner available for To avoid electrical shock which can cause severe personal injury or death, purchase (Part # 31960801) through our disconnect power to refrigerator before cleaning. After cleaning, connect power. Consumer Affairs division. - Page 15 j-- Iints and Care Remove Replace Light Bulbs U WARNING Most To avoid electrical shock which can cause severe personal injury or death, Your Energy to Get disconnect power to refrigerator before replacing light bulb. After replacing light Dollar bulb, connect power, •...
- Page 16 Trouble Shooting Today's refrigerators have ncw features and are more energy efficient. Foam insulation is very energy efficient and has excellent insulating capabilities, however, foam insulation is not as sound absorbent. As a result, certain sounds may be NOISE )))_ unfamiliar.
-
Page 17: Trouble Shooting
Trouble Shooting OPERATION_ SOLUTION TOPIC POSSIBLE CAUSE Refrigerator is not level. See How to Level Your Refrigerator for Food temperature Door is not closing properly. details on how to level your unit, appears too warm Check gaskets for proper seal. Clean, if necessary, according to cleaning instructions in owner's manual Check for internal obstructions that are keeping door from closing property (i.e, improperly closed drawers, ice buckets,... - Page 18 Improper water valve was installed. Check water connection procedure in your Installation Instructions. Self-piercing and saddle valves cause low 3/16" water pressure and may clog the line over time, Amana is not responsible for property damage due to Improper installation or water connection,...
- Page 19 Amana Refrigerator Warranty First Year Amana will replace, free of charge, any part which is defective due to workmanship or materials. Second through Fifth Year Amana will replace free of charge, any sealed system component (compressor, condenser, evaporator, drier and interconnecting tubing) and repair any food compartment liner (exclusive of door liner) which is defective due to workmanship or materials.
