Viadux 2000
Subscriber Bridge is
a compact, cost-
effective and low
maintenance CPE
device designed to
support:
Full Media
Access Control
(MAC) bridging
functions
supporting
Point-to-Point
over Ethernet
(PPPoE) & IP
Seamless
integration with
Viadux 8000
Broadband
Gateway
Fast installation
and low
maintenance
Plug-and-play
connectivity
Remote
management of
all Viadux 2000
subscriber
bridges via
Viadux 8000
Broadband
Gateway
R17
VIADUX 2000 SUBSCRIBER BRIDGE
Viadux 2000 Subscriber Bridge – High-
speed, cost effective Customer Premise
Equipment (CPE) is designed for plug-
and-play operation with the Viadux 8000
Broadband Gateway.
VIADUX 2000 SPECIFICATIONS
Traffic Forwarding
Routing (integrated with the Viadux 8000): IP, NAT &
DHCP
Bridging: MAC, PPPoE & IP
LAN Interface
10/100 Ethernet
IEEE 802.3 compliant
RJ-45 connector
WAN Interface
Standard: SDSL per ETR-152 & POTS
RJ-11 connector
Up to 7,000 ft / 2130 m over POTS with Viadux AnyPair
solution; and 17,000 ft / 5181 m without Viadux AnyPair
solution
Protocol: Frame Relay
Telephone Interface (optional)
Standard: Analog POTS
Connector: RJ-11
Auto-Configuration
Plug-and-play to Viadux 8000
Automatic configuration downloads and code updates
Quality of Service
Supports multiple PVCs to segregate traffic (i.e. voice &
data)
Configurable minimum, maximum, and burst data rates per
PVC
Diagnostics
LED status indicators for WAN & LAN
Remote monitoring
Power
12 VDC / 500 mA
Physical Dimensions
Height: 1.75 in / 4.4 cm
Length: 5.5 in / 14.0 cm
CB
TM
VIADUX
2000 Subscriber Bridge
®
Width: 5.25 in / 13.3 cm
Weight: 2.5 lbs. / 0.91 kg shipping weight
Environment
o
o
Temperature: 32
– 104
F / 0
Humidity: 0 to 90% (non-condensing)
Safety
rd
UL & cUL per UL 1950, 3
Edition
CSA C22.2 No. 950-05
nd
IEC 60950 2
Edition, 1991 + A1-A4
CB certificate
EMI
Federal Commission, Part 15, Class B Communications
Industry Canada, ICES-003, Class B
EN 55022, Class A
Immunity
EN 55024
Viadux 2000 Models
RC2000: with built-in Viadux AnyPair solution enabling
services over existing, in-use phone lines
RC2010: without built-in Viadux AnyPair solution
Products manufactured by Viadux
and distributed by Motorola.
To purchase, please contact:
o
o
– 40
