Summary of Contents for Emprex DSC 3380S
-
Page 2: Table Of Contents
Installing the Software... 12 System requirements... 12 PhotoImpression 4.0 Installation ... 13 PhotoBase 4.0 Installation ... 14 Connecting the 3MP Digital Camera to Your PC ... 15-17 Troubleshooting (Digital Camera)... 18-19 Specifications (3-Megapixel Digital Camera) ... 20 Safety Notes... 21-22 Trademarks ... -
Page 3: 3-Megapixel Digital Camera With Color Lcd
3-Megapixel Digital Camera with Color LCD Brief Description Your 3-megapixel digital camera with color LCD display is roughly the size of a credit card - only 13 mm thick. The camera’s portability and convenience are enabled by its “worry free”... -
Page 4: Identifying The Parts
Identifying the parts Front View Red LED Picture-Taking Mode / Playback Mode SD Card slot Back View Viewfinder Liquid Crystal Display(LCD) Flash Strobe Green LED Power On/Off Menu Lens LCD On/Off Select Down... -
Page 5: Using Your 3-Megapixel Digital Camera
Using Your 3-Megapixel Digital Camera Charging the battery Long battery life is one of the key benefits of this camera compared to other digital cameras. On a full charge, the camera will take hundreds of images. Your camera battery has already been charged prior to shipment. -
Page 6: Turning On The Camera
Turning on the camera Press the Power button once to turn on the camera. Press it again to turn the camera off. • Note: The camera has an automatic time-out feature to conserve battery life. After one minute (or 2 minutes) the camera will time-out (turn off). When timed out, the camera will not take a photo when you push the shutter button. -
Page 7: Picture-Taking Mode
Picture-taking mode The green LED will be solid when the camera is ready to take pictures. If the green LED is blinking, the camera is not ready. It may blink for 1 second while storing an image and for 5 seconds while recharging the flash. -
Page 8: Picture-Taking Mode With Timer On
Typical picture-taking mode menu displays Picture-taking mode with timer on Note the timer icon in the center of the display. When the timer is on, and set to 10 seconds (for example), the front red LED begins blinking when the shutter button is pressed. It begins counting down with 8 seconds of slow blinking (with audio beeps if the sound is on) and 2 seconds of fast blinking (with audio beeps). -
Page 9: Playback Mode
Playback mode Use the Playback mode to review images you have captured and to review images in order to delete them. Select Playback mode by sliding the mode switch to the right. The last picture taken is displayed first. If the camera is empty, the display will say “No pictures on camera.” Only the active media (SD card or internal memory) is displayed. -
Page 10: Using Secure Digital (Sd) Memory Cards
SD card (refer to page 11), or use a writable SD card. Changing resolution Your 3MP Digital Camera offers three choices in resolution: Large, Medium and Small. Large resolution is 3264 x 2448 pixels, Medium resolution is 2000 x1500 pixels, and Small resolution is 1000 x 750 pixels. -
Page 11: Turning Sound On/Off
• Select Sound and then select ON or OFF. Taking pictures To take pictures using your 3MP Digital Camera: • Turn the camera on. • In low light conditions, check to make sure the flash is ready. Be sure the Flash is set to AUTO. -
Page 12: Deleting An Image
Deleting an image To delete the most recent image: • Turn the camera on and switch the Picture-Taking Mode/ Playback Mode to playback. • Press the Menu button and select Delete. • Use the up/down arrow buttons to select “Yes” to delete the image or “No” to save the image. -
Page 13: Installing The Software
Installing the Software System requirements Windows • Windows ME, 2000, or XP • 200 MHz Pentium or better • 32MB RAM • 200MB available Hard Drive space • CD-ROM... -
Page 14: Photoimpression 4.0 Installation
PhotoImpression 4.0 Installation 1. Insert installation CD into your PC’s CD-ROM. 2. Introduction screen will appear automatically. 3. Click “ArcSoft PhotoImpression 4.0” 4. Click “Yes” Click “Next“ Note: To find out more about PhotoImpression 4.0 or how to use it, consult online help by clicking “?”... -
Page 15: Photobase 4.0 Installation
PhotoBase 4.0 Installation 1. Insert installation CD into your PC’s CD-ROM. 2. Introduction screen will appear automatically. 3. Click “ArcSoft PhotoBase 4.0” 4. InstallShield Wizard will automatically Begin to install. 5. Click “Next” 6. Click “Yes” 7. Click “Next” 8. Click “Next” 9. -
Page 16: Connecting The 3Mp Digital Camera To Your Pc
Connecting the 3MP Digital Camera to Your PC After the software has been installed on your computer, plug the camera into an available USB port using the provided USB cable. The Windows operating system requires that you install drivers for the camera so that the camera and computer can communicate properly. - Page 17 Click “GETMYPIX.EXE” Click “Transfer”...
- Page 18 Photos transferring, this may take a few moment. Click “Close” when it’s done. The photos are copied from the camera to the specified folder.
-
Page 19: Troubleshooting (Digital Camera)
Troubleshooting (Digital Camera) Problem Symptom No power Camera will not turn on Picture-taking Image appears blurred or dark Flash does not go off as expected Camera will not focus Cannot take pictures when the shutter button is pressed PC Connection... - Page 20 Camera Electrostatic malfunctions discharge during use interfered with the camera The LCD does not light. Everything on Camera the LCD firmware defect flashes and “7” or “8” is displayed LCD displays Incompatible “E2” when a file system on SD memory SD memory card is inserted card...
-
Page 21: Specifications (3-Megapixel Digital Camera)
Specifications (3 Megapixel Digital Camera) Imager Imager Resolution Dynamic Range Exposure Control Sensitivity Exposure time Exposure-to-exposure time Lens Lens focus Viewfinder Display Controls Strobe Strobe activation Strobe distance Image resolution settings White Balance Built-in storage Expansion slot Computer/host interface System requirements... -
Page 22: Safety Notes
• Do not immerse the camera in water. Notes on Copyright Images recorded using your digital camera system cannot be used in ways that infringe copyright laws without the consent of the owner, unless intended only for personal use. Note that some restrictions apply to the photographing of stage performances, entertainments and exhibits, even when intended purely for personal use. - Page 23 Places to Avoid Do not use or store the camera in the following types of locations: • In the rain or in very humid, dirty or dusty places. • Places subject to extreme temperature rises, such as in direct sunlight or a closed car in summer.
-
Page 24: Trademarks
Trademarks • Autobrite is a registered trademark of SMaL Camera Technologies, Inc. of Cambridge, Massachusetts, USA. • Microsoft and Windows are trademarks of the Microsoft Corporation of the U.S. and other countries. Windows is an abbreviated term referring to the Microsoft Windows Operating System.
