Power ON Self-Test

Every DP-301P+ has been factory-tested to operate properly.
When the DP-301P+ is powered ON, it also automatically performs a Self-Test on
each of its major components. The final result of the Self-Test is signaled by the
state of the LPT LED indicator following the Self-Test. Preliminary to the actual
component tests, the three LED indicators are tested to confirm their steady and
flashing operation.
Immediately after power-up, all three of the green LEDs should illuminate steadily
for several seconds. Then the LPT LED should light OFF. Irregularity of any of the
three LEDs during these LED tests may mean there is a problem with the LEDs
themselves.
The actual component tests immediately follow the LED tests. A normal (no fault)
result is signaled by a simultaneous flashing of the LPT LED three times, followed
by a quiescent state with the LPT LED dark.
If the Self-Test routine traps any component error, then following the LED tests the
Self-Test will halt and the LPT LED will continuously signal the error according to
the following table. In the event of any such error signal, contact your dealer for
correction of the faulty unit.
LPT LED
On
1 long 3 short
1 long 5 short
1 long 6 short
1 long 8 short
Faulty Component
DRAM error
Flash Protected
Flash Erase/Program error
LAN Controller error
LPT Controller error
