Emerson Control Wave SCADA RTU Brochure

Product Data Document
420DS-12A
October 1, 2007 - Page 1
Integrated Pump Control
SCADA RTU
Pre-Engineered Water and Wastewater
Remote Pump Control Application Package
Single program offers performance and simplicity
for monitoring and control of remote water and
wastewater applications
• Well station
• Remote tank level control
• Reservoir Control
• Duplex Lift or Booster station
• Triplex Lift or Booster station
This standard pre-programmed application lever-
ages our decades of experience monitoring and
controlling remote pumps in a wide variety of water
and wastewater sites in North America and through-
out the world. The standard application can be
used with the appropriate Bristol
PLC/RTU, from Emerson Process Management to
meet the I/O requirements at the various sites. The
combined solution offers a cost effective system that
is ready to deploy without the typical programming
overhead.
Remote Automation Solutions
Website: www.EmersonProcess.com/Remote
® ®
ControlWave
Benefits
• Pre-programmed package eliminates the need
for custom programming
• One package for one to three pumps provides
consistency for operators and technicians
• Local Display/Keypad Operator Interface panel
for on-site system control
• Alarm and historical data reporting for full
SCADA integration
• Multiple pump scenarios allow flexibility to meet
a wide range of applications
• Pump start/stop as well as VFD speed control
• Easy-to-use web page station configuration and
setup
• Easily interfaces to field devices and sensors
• Security and water quality functions can be
easily added as needed
Plant managers will take maximum advantage of
the flexibility and maintenance personnel will ap-
preciate the simplicity of the Bristol ControlWave
pump control application. All remote water and
wastewater applications have the same require-
ments to automatically control one or more pumps
to maintain level, pressure and/or flow. Some sites
may also have the need to control chemical feed,
measure rain level, and detect intrusion events. All
of these are pre-programmed and available for use
to customize for the specific site.
When the application requires modifications or addi-
tions to the standard program, Bristol ControlWave
Designer allows unlimited customization by your
engineering staff or other integrators.
