Power On By PCIE/PCI [Disabled]
[Disabled] Disables the PCIE/PCI devices to generate a wake event.
[Enabled] Enables the PCIE/PCI devices to generate a wake event.
Power On By Ring [Disabled]
[Disabled] Disables Ring to generate a wake event.
[Enabled] Enables Ring to generate a wake event.
Power On By RTC [Disabled]
[Disabled] Disables RTC to generate a wake event.
When set to [Enabled], the items RTC Alarm Date (Days) and Hour/
[Enabled]
Minute/Second will become user-configurable with set values.
RTC Alarm Date (Days)
This item appears only when you set the previous item to [Enabled] and allows you to select
RTC alarm time (days). When you set the time to zero, the RTC alarms everyday. Use <+>
and <-> keys to adjust the time.
- Hour / - Mimute / - Second
Allows you to set the RTC alarm time. Use <+> and <-> keys to adjust the time.
2.5.11

Serial Port Console Redirection

Console Redirection [Enabled]
Enables or disables the console redirection feature. When enabled, it allows you to maintain
a system from a remote location by redirecting keyboard input and text output through the
serial port. Configuration options: [Enabled] [Disabled]
Console Redirection Settings
Allows you to configure how the host computer and the remote computer (which the user is
using) will exchange data. Both computers should have the same or compatible settings.
Out-of-Band Mgmt Port [COM0 (Disabled)]
Microsoft Windows Emergency Managment Services (EMS) allows for remote
management of a Winsows Server OS through a serial port. Configuration options:
[COM0 (Disabled)] [COM1 (Pci Bus0, Dev0, Func0) (Disabled)]
Terminal Type [VT-UTF8]
VT-UTF8 is the preferred terminal type for out-of-band management. The next best
choice is VT100+ and then VT100. Configuration options: [VT100] [VT100+] [VT-UTF8]
[ANSI]
Bits per second [115200]
Selects serial port transmission speed. The speed must be matched on the other side.
Long or noisy lines may require lower speeds. Configuration options: [9600] [19200]
[57600] [115200]
Chapter 2: BIOS information
Use <+> and <-> keys to adjust the time.
2-23
