2.3.10

Rear panel connection

Rear panel connectors
1. PS/2 keyboard/mouse combo port
2. USB 2.0 ports 3 and 4
3. Optical S/PDIF Out port
4. VGA out port
5. LAN (RJ-45) port*
6. USB 2.0 ports 5 and 6
7. Power External SATA port
*and **: Refer to the tables on the next page for LAN port and audio port definitions.
ASUS P8H67-M EVO
8. IEEE 1394a port
9. DisplayPort output port**
10. HDMI out port**
11. DVI out pot
12. USB 3.0 ports 1 and 2
13. Audio I/O ports***
2-39
