3. ASMedia 1061 Serial ATA 6.0Gb/s connectors (7-pin SATA6G_E1/E2 [navy blue])
These connectors connect to Serial ATA 6.0 Gb/s hard disk drives via Serial ATA 6.0
Gb/s signal cables.
P8H61-M PRO ASMedia
• Install the Windows
• The SATA6G_E1/E2 (navy blue) connectors are for data drives only. ATAPI device is not
4. Intel H61 Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1~4 [blue])
®
These connectors connect to Serial ATA 3.0 Gb/s hard disk drives and optical drives via
Serial ATA 3.0 Gb/s signal cables.
P8H61-M PRO Intel
Install the Windows
1-24
P8H61-M PRO
XP Service Pack 3 or later version before using Serial ATA.
®
supported.
P8H61-M PRO
SATA 3.0Gb/s connectors
®
XP Service Pack 3 or later version before using Serial ATA.
®
SATA6G_E2 SATA6G_E1
SATA 6.0Gb/s connectors
®
SATA3G_2 SATA3G_1
SATA3G_4 SATA3G_3
Chapter 1: Product introduction
