RAID Configuration Guide
1.
Introduction of RAID ..........................................................2
2.
RAID Configuration ...........................................................4
2.1 Install the hard disk drives ........................................5
2.2 Set up UEFI ..............................................................5
2.3 Configure Intel RAID BIOS .......................................6
3.
4.
Installing Windows
RAID mode ..................................................................12
®
..................................................................10
®
on a HDD larger than 2TB in
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z77 Extreme11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK Z77 Extreme11

Summary of Contents for ASROCK Z77 Extreme11

  • Page 1: Table Of Contents

    RAID Configuration Guide Introduction of RAID ............2 RAID Configuration ............4 2.1 Install the hard disk drives ........5 2.2 Set up UEFI ..............5 2.3 Configure Intel RAID BIOS ........6 ® Installing Windows on a HDD under 2TB in RAID mode ..............10 ® Installing Windows on a HDD larger than 2TB in RAID mode ..............12...

  • Page 2: Introduction Of Raid

    Introduction of RAID This motherboard adopts a chipset that supports RAID. The term “RAID” stands for “Redundant Array of Inde- pendent Disks”, which is a method of combining two or more hard disk drives into one logical unit. For optimal performance, please install identical drives of the same model and capacity when creating a RAID set. The fol- lowing are common examples of RAID. Please refer to the user manual for the types of RAID your motherboard supports, and notice that other requirements such as a RAID supporting disk drive and operating system are also crucial for creating a RAID volume. RAID 0 (Data Striping) RAID 0 is called data striping that optimizes two identical hard disk drives to read and write data in parallel, interleaved stacks. It will improve data access and storage since it will double the data transfer rate of a single disk alone while the two hard disks perform the same work as a single drive, but at a sustained data transfer rate and it has no fault tolerance. RAID 1 (Data Mirroring) RAID 1 is called data mirroring that copies and maintains an identical image of data from one drive to a second drive. It pro- vides data protection and increases fault tolerance to the entire system since the disk array management software will direct all applications to the surviving drive as it contains a complete copy of the data in the other drive if one drive fails.
  • Page 3 RAID 10 RAID 10 is a striped configuration with RAID 1 seg- ments whose segments are RAID 1 arrays. This confi- guration has the same fault tolerance as RAID 1, and has the same overhead for fault-tolerance as mirroring alone. RAID 10 achieves high input / output rates by striping RAID 1 segments. In some instances, a RAID 10 configuration can sustain multiple simultaneous drive failure. A minimum of four hard disk drives is required for this setup. RAID 5 RAID 5 stripes both data and parity information across three or more hard disk drives. Among the advantages of RAID 5 configuration include better HDD perfor- mance, fault tolerance, and higher storage capacity. The RAID 5 configuration is best suited for transaction processing, relational database applications, enterprise resource planning, and other business systems. Use a minimum of three identical hard disk drives for this setup.

  • Page 4: Raid Configuration

    2. RAID Configuration RAID Configuration Precautions Please use two new drives if you are creating a RAID 0 (striping) array for performance. It is recommended to use two SATA drives of the same size. If you use two drives of different sizes, the smaller capacity hard disk will be the base storage size for each drive. For example, if one hard disk has an 80GB storage capa- city and the other hard disk has 60GB, the maximum storage capacity for the 80GB-drive becomes 60GB, and the total storage capacity for this RAID 0 set is 120GB. You may use two new drives, or use an exi- sting drive and a new drive to create a RAID 1 (mirroring) array for data protection (the new drive must be of the same size or larger than the existing drive). If you use two drives of diffe- rent sizes, the smaller capacity hard disk will be the base storage size. For example, if one hard disk has an 80GB storage capacity and the other hard disk has 60GB, the maximum storage capacity for the RAID 1 set is 60GB. Please verify the status of your hard disks be- fore you set up your new RAID array. Please backup your data fi rst before you cre- Please backup your data first before you cre- ate RAID functions. In the process you create RAID, the system will ask if you want to “Clear Disk Data” or not. It is recommended to select “Yes”, and then your future data building will operate under a clean environment.

  • Page 5: Install The Hard Disk Drives

    2.1 Install the hard disk drives Connect two or more new hard disk drives of the same model and capacity to your system. Before creating a RAID array, please check the user manual for information of: 1. What levels of RAID does your motherboard support 2. Which SATA ports support RAID 3. Other related requirements 2.2 Set up UEFI Enter UEFI SETUP UTILITY Advanced screen Storage Configuration. Set “SATA Mode Selection” to [RAID].

  • Page 6: Configure Intel Raid Bios

    2.3 Configure Intel RAID BIOS Reboot your computer. Press <Ctrl+I> to enter the RAID BIOS when you see the RAID software status screen. Select the option Create RAID Volume and press <Enter>. In the Create Volume Menu, please insert a unique name for your RAID volume.
  • Page 7 Select your desired RAID Level. If you selected RAID 0 (Stripe), you are required to select the stripe size for your RAID 0 array. The available values range from 8 KB to 128 KB. The default selection is 128 KB. The strip value should be chosen based on the planned drive usage. • 8/16 KB - low disk usage • 64 KB - typical disk usage • 128 KB - performance disk usage...
  • Page 8 After setting strip size, set the disk Capacity. Press <Enter> and then Press <Y> to continue when the utility prompts a confirmation message. After the configuration, you will see the detailed information about the RAID array that you set up.
  • Page 9 Please note that you are only allowed to create one RAID partition at a time under BIOS RAID. If you want to create an extra RAID partition, please use the RAID utility under Windows to configure RAID after you install the OS. If you want to delete a RAID volume, please select the option Delete RAID Volume, press <Enter>, and then follow the instructions on the screen.

  • Page 10: Installing Windows ® On A Hdd Under 2Tb In Raid Mode

    ® Installing Windows on a HDD under 2TB in RAID mode After the UEFI and RAID BIOS setup you may start ® installing Windows 7 / 7 64-bit / Vista / Vista bit OS as usual.
  • Page 11 Windows 7 64-bit. After the UEFI and RAID BIOS setup, please follow the steps below. ® STEP 1: Copy Intel RAID drivers into a USB flash disk You can download the drivers from ASRock's website and unzip the files into a USB flash disk or copy the files from ASRock's motherboard support CD. (Please copy the files under the following directory: 32 bit: ..\i386\Win7_Vista_Intel.. 64-bit: ..\AMD64\Win7-64_Vista64_Intel.. ® STEP 2: Install Windows...
  • Page 12 ® Start Windows Installation. When you see “Where do you want to install Windows?” page, please click “Load Driver”. Plug the USB flash disk into your USB port; select “Browse” to find the RAID driver. Then choose the directory you have copied in the first step. Please keep the USB flash disk installed until the system's first reboot. Continue to install the OS by following the instructions.
  • Page 13 ® If you install Windows 7 64-bit / Vista 64-bit on a large hard disk (ex. ® Disk volume > 2TB), it may take more time to boot into Windows or install driver/utilities. If you encounter this problem, you will need to follow the instructions below to fix this problem. ® Windows Vista 64-bit: ® Microsoft does not provide hotfix for this problem. The steps listed below ® are Microsoft 's suggested solution: A. Disable System Restore. a. Type “systempropertiesprotection” in the Start Menu. Then press "Enter".
  • Page 14 B. Disable “Volume Shadow Copy” service. a. Type “computer management” in the Start Menu, then press “Enter”. b. Go to “Services and Applications>Services”; Then double click “Volume Shadow Copy”.
  • Page 15 c. Set “Startup type” to “Disable” then Click “OK”. C. Reboot your system. D. After reboot, please start to install motherboard drivers and utilities. ® Windows 7 64-bit: A. Please request the hotfix KB2505454 through this link: http://support.microsoft.com/kb/2505454/ ® B. After installing Windows 7 64-bit, install the hotfix kb2505454. (This may take a long time; >30 mins.) C. Reboot your system. (It may take about 5 minutes to reboot.) ® D. Windows will install this hotfix then reboot by itself. E. Please start to install motherboard drivers and utilities.
