Serial-ATA Port1/2/3/4 [Enabled]
Allows you to disable or enable the Serial-ATA devices.
Configuration options: [Disabled] [Enabled]
4.4.5

On Board LAN

The items in this menu allow you to change the configurations for onboard LAN.
Select an item then press <Enter> to display the configuration options.
On Board LAN
On Board LAN Chip
S5 WOL
On Board LAN Boot ROM
On Board LAN Chip [Enabled]
Allows you to enable or disable the onboard LAN chip.
Configuration options: [Enabled] [Disabled]
The following item appears only when the On Board LAN Chip item is set to
[Enabled].
S5 WOL [Enabled]
Allows you to enable or disable the LAN S5 wake up.
Configuration options: [Enabled] [Disabled]
On Board LAN Boot ROM [Disabled]
Allows you to enable or disable the onboard LAN Boot ROM.
Configuration options: [Enabled] [Disabled]
4-14
[Enabled]
[Enabled]
[Disabled]
Enable or Disable
Onboard LAN Chip.
Chapter 4: BIOS setup
