Operating Manual
Style RX 300
Version 230V - 20625
120V - 20725
Canada 120V - 20725.1VS
Elinca S.A Style RX 01.01.2007 ENG (73253) Printed in Switzerland
Style RX 600
Version 230V - 20626
120V - 20726
Canada 120V - 20726.1VS Canada 120V - 20727.1VS
Style RX 1200
Version 230V - 20627
120V - 20727
English
Advertisement
Table of Contents
Related Manuals for Elinchrom RX 1200
Summary of Contents for Elinchrom RX 1200
- Page 1 Operating Manual Style RX 300 Style RX 600 Style RX 1200 Version 230V - 20625 Version 230V - 20626 Version 230V - 20627 120V - 20725 120V - 20726 120V - 20727 Canada 120V - 20725.1VS Canada 120V - 20726.1VS Canada 120V - 20727.1VS...
-
Page 2: Table Of Contents
Synchronisation, Wireless Remote control and flash triggering Acoustic signal Troubleshooting 7, 10 Flash tube replacement Technical Data Elinchrom Accessories Guarantee P.S: Technical data subject to change. The listed values are guide values which may vary due to tolerances in components used. -
Page 3: Introduction
ELINCHROM in lighting products for the studio and the utilization of the latest technology in this area. Totally integrated to the range of the ELINCHROM flashes, the Style 300RX - 600RX - 1200RX units maintain the traditional look and function that is ELINCHROM. -
Page 4: Declaration Of Conformity, Disposal And Recycling, Ce Marking
Any components not reclaimed will be disposed of in a environmentally acceptable manner. If you have any question on disposal, please contact your local office or your local ELINCHROM agent (check our website for a list of all ELINCHROM agents world wide). -
Page 5: Safety Notice And Precaution
Safety notice According to safety regulations, we draw your attention to the fact that these electronic flash units are not designed for use outdoors, in damp or dusty conditions and should not be used after being exposed to sudden temperature changes causing condensation. They must always be connected to an earthed (grounded) mains supply. -
Page 6: Operating Instructions
Modelling lamp coincides with the voltage line. They must always be connected to an earthed ( grounded) mains supply. All Style RX units have a bayonet mount and locking ring reflector fitting, for fixing all Elinchrom and Prolinca accessories. -
Page 7: Control Panel
Control Panel 14 15 Overview of controls 1.Mains inlet socket 12. + Power adjustment in 1/10 f-stops 2.Mains fuse (slow blow) 1 3. Modelling lamp switch 3.Mains Illuminated on/off switch (on/off free or prop) 4.Modelling fuse (fast blow) 14.+ Modelling power control 5.Open-flash 15. -
Page 8: Switch And Fuse
See page 10 / Troubleshooting. This equipment is not user serviceable and contains high voltages which are dangerous. In the event of failure, please return the unit to an authorized Elinchrom service station. Mains Fuse Standard type 5 x 20 mm, (use only tempered fuse) •... -
Page 9: Modelling Light
Modelling Light The touch pad (14) controls the modelling lamp on/off and the proportional light. Select the power with the touch pad (15). The modelling light output (100%) is achieved when the power value is set to maximum. Proportional modelling lamp, is set when the position "PROP" is selected (led is illuminated), the light output is proportional to the selected flash power. -
Page 10: Digital Power Display, Photo-Cell
Digital Power Display The actual flash power is displayed in a f-stop compatible format. The power range is 6 f-stops. The digital display, provides continuous power indication of the flash and modelling lamp. The controls cover a continuous output range from full power 1/1 to 1/32th in 1/10th, f-stop intervals. -
Page 11: Synchronisation, Wireless Remote Control And Flash Triggering
RX Multi Remote > EL-Skyport. Sync Sychronisation socket The standard socket 3.5 mm mini-jack (6). N.B. Do not link ELINCHROM units by cable to other manufacturers sync outlets. ELINCHROM uses the low voltage (5 V) for security reasons. Open flash "test" Test and Ready Having pressed the touch pad to release a flash, the green «READY»... -
Page 12: Flash Tube Replacement
Flash tube replacement If the unit does not flash but the ON/OFF switch indicates that there is power, it could be that the flashtube needs replacing. Note: Flash tubes (Swiss quality) have a long life with average use, but multiflashing in long sequences can cause overheating of the electrodes leading to premature ageing, or perhaps the flash tube is broken or cracked. -
Page 13: Technical Data
• Central umbrella tube plus external fitting • Acoustic recharging signal • Mains cable • Synchro cord of 5m (jack 3.5mm plug) • Protective cover • Total compatibility with all Elinchrom accessories • Very fast recycling time • Very short flash duration Technical data 300RX... -
Page 14: Elinchrom Accessories
Elinchrom Accessories code Reflectors Wide angle ø 16 cm /90° 26143 Compact ø 18 cm /60° 26144 Standard ø 21 cm /50° 26141 Mini Soft ø 44 cm silver 26166 Mini Soft ø 44 cm white 26168 Snoot & Grid... -
Page 15: Guarantee
Guarantee This ELINCHROM product will be repaired free of charge by the vending agent if during a period of 24 months from date of purchase its working order is impaired through a manufacturing or material defect. The faulty product should be immediately sent to the authorized dealer or ELINCA agent. - Page 16 www.elinchrom.com...
