- Page 1 SHALLOW MOUNT SUBWOOFER INSTALLATION MANUAL S104 S124...
- Page 2 Dear Valued Customer, Congratulations on your purchase of a Diamond Audio HEX shallow mount subwoofer. ™ Your new HEX subwoofer is the result of endless hours of trial and error. We tasked ™ our engineers to develop a subwoofer that would fit almost anywhere yet still provide the same performance you have come to expect from a Diamond Audio subwoofer.
- Page 3 PHYSICAL DIMENSIONS Dimension (in./mm) S104 S124 Total Diameter (A) 10.5 in. (266.5 mm) 12.4 in. (315 mm) Mounting Diameter (B) 9.3 in. (236.5 mm) 11.2 in. (284 mm) Screw Hole Diameter (C) 10.1 in. (257.5 mm) 11.9 in. (300 mm) Mounting Depth (D) 2.7 in.
- Page 4 LIMITED SPEAKER WARRANTY STATEMENT Diamond Audio Technologies, LLC (DAT) warrants this product to be free from defects in material and workmanship for a period of one (1) year from the original date of purchase provided it was purchased from an authorized DAT retailer within the United States. However, if this product was installed by the authorized DAT retailer, the warranty period will be extended to three (3) years.
