- Page 1 Product Owners Manual SPEAKER SYSTEMS SERIAL NUMBER: DATE OF PURCHASE:...
-
Page 2: Special Thanks
SPECIAL THANKS Dear Valued Customer, Thank you for choosing Diamond D3 speakers. These speakers represent the latest advances in acoustic technology, and like all Diamond products, are hand built and tested in our own factory, using the highest grade components and state of the art techniques. When installed properly, they will provide many years of accurate sound reproduction. -
Page 3: Standard Connection
FEATURES • Textured Copolymer Cones • Foam Surrounds • Heavy Gauge Proprietary Frames • Flat Progressive Spider • Extended Pole Motor Design • Rubber Boot Magnet Protector • Aluminum Dome Tweeters with Ferro Fluid Cooling • Model Specific Crossovers • Shallow Mount D3 INTEGRATED SPEAKER SYSTEMS Parts List - D342i, D352i, D362i, D372i, and D392i (2) D3 Coaxial Speakers... - Page 4 MID-BASS SPEAKER MOUNTING The illustration below shows the parts included and correct mounting assembly of the D3 integrated and component mid-bass drivers. Mounting ring and grill are optional. ©007 Diamond Audio Technologies, LLC...
-
Page 5: Tweeter Mounting
D3 COMPONENT SPEAKER SYSTEMS Parts List - D342, D352, and D362 (2) D3 Mid-Bass Speakers (2) D3 Grills w/ Mounting Rings (2) Mounting Gaskets (2) D3 12dB Crossovers (2) D3 Tweeters in Flush Mount Cups (2) D3 Tweeter Surface Mounting Cups (1) Mid-Bass Mounting Hardware Kit (1) Tweeter Mounting Hardware Kit Tweeter Mounting... -
Page 6: Thiele/Small Parameters
COMPONENT SYSTEM CONNECTION The following illustration shows how to connect one channel of the D3 component system. THIELE/SMALL PARAMETERS Parameter (unit) D/i D/Di D/Di D./D.i D7i D9i 89.5 90.5 91.5 Sensitivity 0.73 0.92 Fs (Hz) Vas (L) 11.5 11.5 17.4 Re (ohm) Xmax (mm/N) Impedance (ohm) -
Page 7: Physical Dimensions
PHYSICAL DIMENSIONS Dimension (Inches) D/i D/Di D/Di D./ D7i D9i DTAK D.i Total Diameter (A) 6.25 5.6 x 8.7 1.73 1.73 Mounting Diameter (B) 3.94 4.68 5.35 5.35 4.9 x 7.1 4.9 x 8.4 1.62 Screw Hole Diameter (C) 5.24 4.3 x 4.6 4.7 x 6.6 Mounting Depth (D) 2.26... -
Page 8: Service/Tech Support
LIMITED SPEAKER WARRANTY STATEMENT Diamond Audio Technologies, LLC (DAT) warrants this product to be free from defects in material and workmanship for a period of one (1) year from the original date of purchase provided it was purchased from an authorized DAT retailer within the United States.
