Work with Advanced Redlines
and Markups
Autodesk DWF Composer includes easy-
to-use shapes, text, freehand, stamp, and
custom symbol tools in addition to
markup tools.
Control Markup Shape
Hold down the Shift key to constrain the
range of movement when marking up
drawings.
1. To start again, press the Esc key and
try again.
2. To delete a markup, use the Selection
tool and press Delete.
Color Code Reviews
Use different markup colors to indicate
different users.
1. Select from the 48 predefined colors
or one of your own.
2. Change the Text Color and Line Color
on the main menu, and then click your
chosen color.
Save a New Markup View
When you create a markup, the current
view of the page is stored with that mark-
up. To change and automatically store a
new view, pan and zoom to the desired
view, and then move the markup slightly
or modify it in some way.
Measure Accurately
The dimension tools with the AutoSnap™
feature help project team members
determine lengths, polylines, and areas.
Snap to Endpoints
Set the measure tools to snap to end-
points, midpoints, and lines for precision
measurement of design elements in the
DWF file. Click the Tools command, and
turn on the Snap to Geometry feature.
Zoom In for Greater Accuracy
To achieve greater accuracy, zoom in to
the section of the drawing to which you
are applying the starting and ending
points of the dimension.
