4. If the drawing contains xrefs, the
Group By Xref Hierarchy option is
selected by default. Clear the check
box if you do not want to display the
objects grouped by xref hierarchy in
the published DWF file.
5. Under Group Individual Objects By,
select one of the following options to
group individual objects in the DWF
file for viewing. Click OK.
• Layer. Group individual objects
by layer.
• Object Type. Group individual
objects by object type (for example,
by block).
Increase the Precision of
the DWF File
Specify the pixel resolution for vector
and raster graphics when creating DWF
files. The higher the resolution, the
greater the precision but the larger the
file size.
1. From the File menu, choose Plot to
display the Plot dialog box.
2. Ensure that DWF 6 ePlot.pc3 is
selected. Click Properties to display
a tree control.
3. Select Graphics from the tree, and
expand it. Select Custom Properties
in the tree control, and then click the
Custom Properties button.
4. Set Vector Resolution to the desired
value. You can leave the other DPI
values (Gradient Resolution, Color
and Grayscale Resolution, and Black
and White Resolution) as they are.
Valid values from the pull-down menu
are between 150 and 4800. Use the
keyboard to enter a custom value, such
as 30270.
Add Object Properties from
AutoCAD Blocks
Enable team members to access
AutoCAD block properties in the DWF
file by setting DWF publishing options.
1. From the File menu, choose Publish.
2. In the Publish dialog box, under Pub-
lish To, click DWF File, and then click
Publish Options.
3. In the Publish Options dialog box,
under DWF Data Options, Block
Information, select Include from the
drop-down list.
Note: By default, Block Information is
set to Don't Include. If you change the
setting to include block information, you
can use the viewer to view or print block
property and attribute information in
the DWF file.
4. Click OK.
5. In the Publish dialog box, either con-
tinue with publishing tasks or close the
dialog box.
