- Page 1 ® DiamondMax 96147H8, 94610H6, 93073H4, 92305H3, 91536H2 Part # 1478 All material contained herein Copyright © 2000 Maxtor Corporation. MaxFax™ is a trademark of Maxtor Corporation. DiamondMax ® , Maxtor ® and No Quibble Service ® are registered trademarks of Maxtor Corporation.
-
Page 2: Before You Begin
During handling, NEVER drop, jar, or bump a drive. Once a drive is removed from the Maxtor shipping container, IMMEDIATELY secure the drive through its mounting holes within a chassis. Otherwise, store the drive on a padded, grounded, antistatic surface. -
Page 3: Table Of Contents
Contents Section 1 Section 1 Section 1 — Introduction Introduction Introduction Introduction Section 1 Section 1 Introduction Maxtor Corporation 1 - 1 Products 1 - 1 Support 1 - 1 Manual Organization 1 - 1 Abbreviations 1 - 1 Conventions... - Page 4 DIAMONDMAX 60 PRODUCT MANUAL Section 3 Section 3 Section 3 — Product Specifications Section 3 Section 3 Product Specifications Product Specifications Product Specifications Product Specifications Models and Capacities 3 - 1 Drive Configuration 3 - 1 Performance Specifications 3 - 1 Physical Dimensions 3 - 2 Power Requirements...
- Page 5 DIAMONDMAX 60 PRODUCT MANUAL Section 5 Section 5 Section 5 Section 5 Section 5 — AT Interface Description AT Interface Description AT Interface Description AT Interface Description AT Interface Description Interface Connector 5 - 1 Pin Description Summary 5 - 1 Pin Description Table 5 - 2 PIO Timing...
- Page 6 DIAMONDMAX 60 PRODUCT MANUAL Write Verify Sector(s) 7 - 4 Write Sector Buffer 7 - 4 Write DMA 7 - 5 Write Multiple 7 - 5 Mode Set/Check Commands 7 - 6 Set Features Mode 7 - 6 Read Native Max Address 7 - 7 Set Max 7 - 7...
- Page 7 DIAMONDMAX 60 PRODUCT MANUAL Figures Figures Figures Figures Figures Figure Title Page 2 - 1 PCBA Jumper Location and Configuration 2 - 6 3 - 1 Outline and Mounting Dimensions 3 - 2 4 - 1 Multi-pack Shipping Container 4 - 2 4 - 2 Single-pack Shipping Container (Option A) 4 - 3...
-
Page 8: Maxtor Corporation
VL 30 series hard drives deliver industry- leading capacity, reliability and value for entry-level systems and consumer electronics applications. Support No matter which capacity, all Maxtor hard drives are supported by our commitment to total customer satisfaction and our No Quibble Service ®... -
Page 9: Conventions
DIAMONDMAX 60 – INTRODUCTION Conventions If there is a conflict between text and tables, the table shall be accepted as being correct. Key Words The names of abbreviations, commands, fields and acronyms used as signal names are in all uppercase type (e.g., IDENTIFY DRIVE). -
Page 10: Ultradma - Mode 4
Maxtor's latest advancements in electronic packaging and integration methods have lowered the drive's power consumption and increased its reliability. Advanced giant magneto-resistive read/write heads and a state-of-the-art head/disk assembly - using an integrated motor/spindle design - allow up to four disks in a 3.5-inch package. -
Page 11: Product Features
15,367 MB (*) The fields LZone (Landing Zone) and WPcom (Write Pre-comp) are not used by the Maxtor hard drive and the values may be either 0 or the values set by the BIOS. All capacities listed in the above table are based on 10 or one million bytes. -
Page 12: Defect Management Zone
PRODUCT DESCRIPTION The LBA is checked for violating the drive capacity. If it does not, the LBA is converted to physical drive cylinder, head and sector values. The physical address is then used to access or store the data on the disk and for other drive related operations. -
Page 13: Major Hda Components
(depending on the model), read pre-amplification and write drive circuitry. Read/Write Heads and Media Low mass, low force giant magneto-resistive read/write heads record data on 3.5-inch diameter disks. Maxtor uses a sputtered thin film medium on all disks for DiamondMax 60 drives. -
Page 14: Subsystem Configuration
PRODUCT DESCRIPTION Subsystem Configuration Dual Drive Support Two drives may be accessed via a common interface cable, using the same range of I/O addresses. The drives are jumpered as device 0 or 1 (Master/Slave), and are selected by the drive select bit in the Device/Head register of the task file. -
Page 15: Product Specifications
93073H4 92305H3 91536H2 61,471 46,103 30,735 23,051 15,367 Formatted Capacity (MB LBA Mode) Maxtor defines one megabyte as 10 or one million bytes and one gigabyte as 10 or one billion bytes. Drive Configuration MODEL 96147H8 94610H6 93073H4 92305H3 91536H2... -
Page 16: Physical Dimensions
PRODUCT SPECIFICATIONS Physical Dimensions (maximum) PARAMETER STANDARD METRIC Height 1.028 inches 26.1 millimeters L e n g t h 5.787 inches 147 millimeters W i d t h 4.00 inches 101.6 millimeters Weight 1.3 pounds 0 . 5 9 k i l o g r a m s Figure 3 - 1 Outline and Mounting Dimensions 3 –... -
Page 17: Power Requirements
This is the lowest power state – with the interface set to inactive. A software or hardware reset is required to return the drive to the Standby state. EPA Energy Star Compliance Maxtor Corporation supports the goals of the U.S. Environmental Protection Agency’s Energy Star program to reduce the electrical power consumption of computer equipment. Environmental Limits... -
Page 18: Shock And Vibration
Quality Acceptance Rate < 1,000 DPPM The quality acceptance rate indicates the percentage of Maxtor products successfully installed by our customers, and/or the number of defective parts per million (DPPM) encountered during the entire installation process. -
Page 19: Emc/Emi
Canada. Safety Regulatory Compliance All Maxtor hard drives comply with relevant product safety standards such as CE, CUL, TUV and UL rules and regulations. As delivered, Maxtor hard drives are designed for system integration before they are used. -
Page 20: Handling And Installation
Electro-Static Discharge (ESD) To avoid some of the problems associated with ESD, Maxtor advises that anyone handling a disk drive use a wrist strap with an attached wire connected to an earth ground. Failure to observe these precautions voids the product warranty. -
Page 21: Unpacking And Inspection
As they are removed, inspect drives for evidence of shipping damage or loose hardware. If a drive is damaged (and no container damage is evident), notify Maxtor immediately for drive disposition. Figure 4 - 1 Multi-pack Shipping Container 4 –... -
Page 22: Repacking
Figure 4 - 3 Single Pack Shipping Container (Option A) Single Pack Shipping Container (Option B) Repacking If a Maxtor drive requires return, repack it using Maxtor packing materials, including the antistatic bag. Physical Installation Recommended Mounting Configuration The DiamondMax ®... -
Page 23: Before You Begin
Maxtor recommends that you make a backup copy of the files on any existing hard drives prior to installing the new drive. If required, this data may then be copied to the Maxtor hard drive after it has been installed in the computer. Refer to your computer user’s manual for detailed data backup instructions. -
Page 24: Install Hard Drive In Device Bay
Attach an IDE interface connector to J1 on the Maxtor drive. Attach a power connector to J2 on the Maxtor drive. This connector is keyed and will only fit one way. Check all other cable connections before you power up. -
Page 25: Interface Connector
AT INTERFACE DESCRIPTION SECTION 5 AT Interface Description Interface Connector All DiamondMax ® 60 AT drives have a 40-pin ATA interface connector mounted on the PCBA. The drive may connect directly to the host; or it can also accommodate a cable connection (maximum cable length: 18 inches). -
Page 26: Pin Description Table
AT INTERFACE DESCRIPTION Pin Description Table PIN NAME SIGNAL NAME SIGNAL DESCRIPTION RESET - Host Reset Reset signal from the host system. Active during power up and inactive after. Host Data Bus 16 bit bi-directional data bus between host and drive. Lower 8 bits used for register and ECC byte transfers. -
Page 27: Pio Timing
AT INTERFACE DESCRIPTION PIO Timing TIMING PARAMETERS MODE 0 MODE 1 MODE 2 MODE 3 MODE 4 Cycle Time (min) 600 ns 383 ns 240 ns 180 ns 120 ns Address valid to DIOR-/DIOW- setup (min) 70 ns 50 ns 30 ns 30 ns 25 ns... -
Page 28: Dma Timing
AT INTERFACE DESCRIPTION DMA Timing TIMING PARAMETERS MODE 0 MODE 1 MODE 2 Cycle Time (min) 480 ns 150 ns 120 ns DMACK to DMARQ delay DIOR-/DIOW- (min) 215 ns 80 ns 70 ns DIOR- data access (min) 150 ns 60 ns DIOR- data hold (min) 5 ns... -
Page 29: Initiating An Ultra Dma Data In Burst
AT INTERFACE DESCRIPTION Ultra DMA Timing TIMING PARAMETERS (all times in nanoseconds) MODE 0 MODE 1 MODE 2 MODE 3 MODE 4 Cycle Time (from STROBE edge to STROBE edge) Two cycle time (from rising edge to next rising edge or from falling edge to next falling edge of STROBE) Data setup time (at recipient) Data hold time (at recipient) -
Page 30: Sustained Ultra Dma Data In Burst
AT INTERFACE DESCRIPTION 2CYC 2CYC DSTROBE at device DD(15:0) at device DSTROBE at host DD(15:0) at host Figure 5 - 5 Sustained Ultra DMA Data In Burst DMARQ (device) DMACK- (host) STOP (host) HDMARDY- (host) DSTROBE (device) DD(15:0) (device) Figure 5 - 6 Host Pausing an Ultra DMA Data In Burst 5 –... -
Page 31: Device Terminating An Ultra Dma Data In Burst
AT INTERFACE DESCRIPTION DMARQ (device) DMACK- (host) STOP (host) HDMARDY- (host) IORDYZ DSTROBE (device) DD(15:0) DA0, DA1, DA2, CS0-, CS1- Figure 5 - 7 Device Terminating an Ultra DMA Data In Burst DMARQ (device) DMACK- (host) STOP (host) HDMARDY- (host) IORDYZ DSTROBE (device) -
Page 32: Initiating An Ultra Dma Data Out Burst
AT INTERFACE DESCRIPTION DMARQ (device) DMACK- (host) STOP (host) ZIORDY DDMARDY- (device) HSTROBE (host) DD(15:0) (host) DA0, DA1, DA2, CS0-, CS1- Figure 5 - 9 Initiating an Ultra DMA Data Out Burst 2CYC 2CYC HSTROBE at host DD(15:0) at host HSTROBE at device DD(15:0) -
Page 33: Device Pausing An Ultra Dma Data Out Burst
AT INTERFACE DESCRIPTION DMARQ (device) DMACK- (host) STOP (host) DDMARDY- (device) HSTROBE (host) DD(15:0) (host) Figure 5 - 11 Device Pausing an Ultra DMA Data Out Burst DMARQ (device) DMACK- (host) STOP (host) IORDYZ DDMARDY- (device) HSTROBE (host) DD(15:0) (host) DA0, DA1, DA2, CS0-, CS1- Figure 5 - 12... -
Page 34: Device Terminating An Ultra Dma Data Out Burst
AT INTERFACE DESCRIPTION DMARQ (device) DMACK- (host) STOP (host) IORDYZ DDMARDY- (device) HSTROBE (host) DD(15:0) (host) DA0, DA1, DA2, CS0-, CS1- Figure 5 - 13 Device Terminating an Ultra DMA Data Out Burst 5 – 10... -
Page 35: Task File Registers
HOST SOFTWARE INTERFACE SECTION 6 Host Software Interface The host communicates with the drive through a set of controller registers accessed via the host’s I/O ports. These registers divide into two groups: the Task File, used for passing commands and command parameters and the Control/Diagnostic registers. -
Page 36: Sector Count Register
HOST SOFTWARE INTERFACE Sector Count Register Holds the number of sectors to be sent during a Read or Write command, and the number of sectors per track during a Format command. A value of zero in this register implies a transfer of 256 sectors. A multi- sector operation decrements the Sector Count register. -
Page 37: Command Register
HOST SOFTWARE INTERFACE Command Register Contains code for the command to be performed. Additional command information should be written to the task file before the Command register is loaded. When this register is written, the BUSY bit in the Status register sets, and interrupt request to the host clears;... -
Page 38: Summary
HOST SOFTWARE INTERFACE Summary C O M M A N D N A M E C O M M A N D C O D E P A R A M E T E R S U S E D S D H R e c a l i b r a t e R e a d S e c t o r ( s ) -
Page 39: Control Diagnostic Registers
HOST SOFTWARE INTERFACE Control Diagnostic Registers These I/O port addresses reference three Control/Diagnostic registers: I/O PORT READ WRITE 3F6h Alternate Status Fixed Disk Control 3F7h Digital Input Not used Alternate Status Register Contains the same information as the Status register in the Task File. However, this register may be read at any time without clearing a pending interrupt. -
Page 40: Reset And Interrupt Handling
HOST SOFTWARE INTERFACE Reset and Interrupt Handling Reset Handling One of three different conditions may cause a reset: power on, hardware reset or software reset. All three cause the interface processor to initialize itself and the Task File registers of the interface. A reset also causes a set of the Busy bit in the Status register. -
Page 41: Interface Commands
INTERFACE COMMANDS SECTION 7 Interface Commands The following section describes the commands (and any parameters necessary to execute them), as well as Status and Error register bits affected. Read Commands Read Sector(s) Read Verify Sector(s) Read Sector Buffer Read DMA Multi-word DMA Ultra DMA Read Multiple... -
Page 42: Read Commands
INTERFACE COMMANDS Read Commands Read Sector(s) Reads from 1 to 256 sectors, as specified in the Command Block, beginning at the specified sector. (A sector count of 0 requests 256 sectors.) Immediately after the Command register is written, the drive sets the BSY bit and begins execution of the command. -
Page 43: Read Dma
INTERFACE COMMANDS Read DMA Multi-word DMA Identical to the Read Sector(s) command, except that The host initializes a slave-DMA channel prior to issuing the command, Data transfers are qualified by DMARQ and are performed by the slave-DMA channel The drive issues only one interrupt per command to indicate that data transfer has terminated and status is available. -
Page 44: Write Commands
INTERFACE COMMANDS Set Multiple Mode Enables the controller to perform Read and Write Multiple operations, and establishes the block count for these commands. Before issuing this command, the Sector Count register should be loaded with the number of sectors per block. The drives support block sizes of 2, 4, 8 and 16 sectors. When this command is received, the controller sets BSY and examines the Sector Count register contents. -
Page 45: Write Dma
INTERFACE COMMANDS Write Multiple Performs similarly to the Write Sector(s) command, except that: 1. The controller sets BSY immediately upon receipt of the command, 2. Data transfers are multiple sector blocks and 3. The Long bit and Retry bit is not valid. Command execution differs from Write Sector(s) because: 1. -
Page 46: Mode Set/Check Commands
Disable Advanced Power Management A A h Enable Read Look-ahead feature B B h 4 bytes of Maxtor specific data appended on Read Long/Write Long commands Disable Automatic Acoustic Management C C h Enable reverting to Power-on defaults 7 – 6... -
Page 47: Read Native Max Address
INTERFACE COMMANDS Read Native Max Address This command returns the native maximum address. The native maximum address is the highest address accepted by the drive in the factory default condition. The native maximum address is the maximum address that is valid when using the SET MAX ADDRESS command. Set Max Individual SET MAX commands are identified by the value placed in the Features register. -
Page 48: Power Mode Commands
INTERFACE COMMANDS Power Mode Commands Standby Immediate – 94h/E0h Spin down and do not change time out value. This command will spin the drive down and cause the drive to enter the STANDBY MODE immediately. If the drive is already spun down, the spin down sequence is not executed. -
Page 49: Default Power-On Condition
INTERFACE COMMANDS Default Power-on Condition The drive’s default power on condition is the ACTIVE MODE. Upon receiving a Power Mode command, except the SLEEP MODE command, the drive sets BSY and performs the requested power operation. Once the requested Power Mode change has begun, the drive resets BSY and generates an interrupt - without waiting for the drive to spin up or spin down. -
Page 50: Initialization Commands
Capabilities 15 - 14 = reserved 13 = standby timer (1 = values as specified in this standard are supported, 0 = values are Maxtor specific) 12 = reserved (advanced PIO mode support) 11, 1 = IORDY supported, 0 = IORDY may be supported 10, 1 = IORDY can be disabled 9-8 = shall be set to one. - Page 51 INTERFACE COMMANDS - W O R D CONTENT DESCRIPTION Reserved 51 - 52 Obsolete 15 -3 = reserved 2, 1 = the fields supported in words 88 are valid, 0 = the fields supported in words 88 are not valid 1, 1 = the fields reports in words 64-70 are valid, 0 = the fields reports in words 64-70 are not valid 0, 1 = the fields reports in words 54-58 are valid, 0 = the fields reports in words 54-58 are not valid Number of current logical cylinders...
- Page 52 1 = Security frozen 1 = Security locked 1 = Security enabled 1 = Security supported 129-130 reserved Spin at power-up, but 0 is asserted when no spin at power-up is enabled. 132-159 Maxtor-specific (not used) 160-255 reserved 7 – 12...
-
Page 53: Initialize Drive Parameters
INTERFACE COMMANDS Initialize Drive Parameters Enables the drive to operate as any logical drive type. The drive will always be in the translate mode because of Zone Density Recording, which varies the number of sectors per track depending on the zone. Through setting the Sector Count Register and Drive Head Register, this command lets the host alter the drive's logical configuration. -
Page 54: Seek, Format, And Diagnostic Commands
INTERFACE COMMANDS Seek, Format and Diagnostic Commands Seek Initiates a seek to the track, and selects the head specified in the Command block. 1. Sets BSY in the Status register, 2. Initiates the Seek, 3. Resets BSY and 4. Generates an interrupt. The drive does not wait for the seek to complete before returning the interrupt. -
Page 55: S.m.a.r.t. Command Set
INTERFACE COMMANDS S.M.A.R.T. Command Set Execute S.M.A.R.T. The Self-Monitoring Analysis and Reporting Technology (S.M.A.R.T.) command has been implemented to improve the data integrity and data availability of hard disk drives. In some cases, a S.M.A.R.T. capable device will predict an impending failure with sufficient time to allow users to backup their data and replace the drive before data loss or loss of service. -
Page 56: Service Policy
E-mail Apactech_Assistance@maxtor.com Language support: English MaxInfo Service Use a touch-tone phone to listen to technical information about Maxtor products and the top Q&A’s from our 24-hour automated voice system. U.S. and Canada 800-2MAXTOR (800-262-9867) Press 1, wait for announcement, listen for option Outside U.S. - Page 57 + 353 1 204 11 22 Asia/Pacific Language support: English Phone + 61 2 9369 4733 Internet Browse the Maxtor home page on Internet, download files from our FTP site. Home Page http://www.maxtor.com Customer Service All Maxtor products are backed by No Quibble Service ®...
- Page 58 GLOSSARY GLOSSARY Glossary Acronym for bits per inch. See bit density. BLOCK ACCESS A group of bytes handled, stored, and accessed as a logical data To obtain data from, or place data into, RAM, a register, or data unit, such as an individual file record. storage device.
- Page 59 GLOSSARY CONTROLLER DIGITAL MAGNETIC RECORDING A miniature CPU dedicated to controlling a peripheral device, such See magnetic recording. as a disk drive, tape drive, video display terminal, or printer. The controller executes commands from the central processing unit and DIRECT ACCESS reissues commands to the peripheral device.
- Page 60 GLOSSARY EXTRA PULSE HEAD DISK ASSEMBLY (HDA) Term used in surface certification. It is when a flux field The mechanical portion of a rigid, fixed disk drive. It usually includes discontinuity remains after the recording surface is erased, thereby disks, heads, spindle motor, and actuator. producing an electrical output of a read head passing over the area with the discontinuity.
- Page 61 GLOSSARY MODIFIED MODIFIED FREQUENCY MODULATION (MMFM) A recording code similar to MFM that has a longer run length limited distance. LANDING ZONE OR LZONE MODULATION The cylinder number to where ParkHeads move the read/write heads. 1. Readback voltage fluctuation usually related to the rotational period of a disk.
- Page 62 GLOSSARY PHASE MARGIN Measure in degrees of the amount of difference between excursions from the window center where flux reversals can occur and the edge of the data window. Similar to window margin. SECTOR A logical segment of information on a particular track. The smallest PHYSICAL SECTOR addressable unit of storage on a disk.
- Page 63 GLOSSARY SOFT ERROR UN-CORRECTABLE ERROR A data error which can be overcome by rereading the data or An error that is not able to be overcome with Error Detection and repositioning the head. Correction. SOFT SECTORED UNFORMATTED CAPACITY A technique where the controller determines the beginning of a Storage capacity of disk drive prior to formatting;...
