User Guide

   Related Manuals for Emerson EMP516-2

   Summary of Contents for Emerson EMP516-2

  • Page 1

    User Guide EMP516-2...

  • Page 2

    IN THE BOX Stereo headphones Portable speaker Quick Start and Media Transfer 2 GB EMP516-2 USB 2.0 Cable MP3 Music & Video Player Installation CD Quick Start Guide (for battery charging and high speed data transfer)

  • Page 3

    ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. Southern Telecom, Inc. 14-C 53rd Street Brooklyn, NY 11232 Tel.: 718-567-7778 MP3 Music & Video Player EMP516-2...

  • Page 4: Copyright Information

    INTRODUCTION Congratulations on purchasing the Emerson MP3 Music & Video Player. This manual contains important safety information and correct operation instructions. Before using the player, read this manual thoroughly and keep it for future reference. Copyright Information Trademarks and trade names used in this instruction manual are owned by their respective companies or organizations.

  • Page 5

    IMPORTANT SAFETY PRECAUTIONS Always follow these basic safety precautions when using your player. This will reduce the risk of product damage and personal injury. Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel. The use of a Non-Recommended accessory may cause fire, electric shock, or injury. For approved accessories please contact customer support. This device contains a built- in battery, do not dispose of in fire.

  • Page 6

    FEATURES  Vivid color display 2 GB internal memory   Two headphone jacks (to share your music)  USB 2.0 high speed connection  Stores and plays music, video, and pictures  Text reading (txt format)  Digital voice recording (built-in microphone) ...

  • Page 7

    LOCATIONS OF CONTROLS Neck strap hole Headphone jacks (two) [POWER] switch [PREVIOUS] - Previous track / Fast backwards [MENU] - Back to the previous menu USB 2.0 Hi-Speed connector for battery charging and data transfer [NEXT] - Next track / Fast forward [PLAY] - Select / Start or stop play / On-Off button [DOWN] - Volume - / Menu / Option [UP] - Volume + / Menu / Option / A-B Loop...

  • Page 8: System Requirements

    PC connection In order to enjoy the multimedia capabilities of your MP3 Player, you have to first copy your favorite files from your PC to it’s internal memory. Connect your MP3 Player to the computer using the included USB 2.0 cable. The device will be detected automatically without installing any driver.

  • Page 9: Disconnecting The Usb Cable

    Disconnecting the USB cable After completing the file transfer, please disconnect the USB cable the following way: 1. Double click the green arrow “Safely Remove Hardware” in the task bar on the bottom right of the window. 2. Select “USB Device” and click “Stop”. 3.

  • Page 10

    CHARGING THE BATTERY Your MP3 Player has an integrated rechargeable Li-ion battery. It is recommended to fully charge the player before using it for the first time. Recharge the battery by connecting the player to a computer using the included USB 2.0 cable.

  • Page 11: Adjusting The Volume, Selecting Main Menu Or Mode

    BASIC OPERATION Turning on/off ● To turn on the player place the [POWER] switch in the “ON” position, and press and hold the [PLAY] button for 3 seconds until the LCD screen lights up. ● To turn the player off, press and hold the [PLAY] button until the LCD screen shuts off, or place the [POWER] switch in the “OFF”...

  • Page 12: Transferring Media To The Player

    1. Connect the MP3 player to the USB port of your computer. 2. Open “Windows Explorer” or “My Computer”, and locate “Emerson MP3”. 3. Select the files on your computer, and simply move it into “Emerson MP3” in the usual way (drag-and-drop, copy-and-paste). After copying is completed, the data will be available on the MP3 player.

  • Page 13: Listening To Music

    MUSIC Store and playback your favorite songs and organize them by playlists, atrist, and other options. See “TRANSFERRING MEDIA FILES TO THE PLAYER” (page 11) and follow the steps below to playback and organize your music. 1. Select “MUSIC” from the main menu, and press the [PLAY] button. 2.

  • Page 14: Skipping Tracks, Searching Backward Or Forward Within A Track

    Skipping tracks ● Briefly press the [PREVIOUS] button to go to the previous track. ● Briefly press the [NEXT] button to go to the next track. Searching backward or forward within a track ● Press and HOLD the [PREVIOUS] button to search backward within a track. ●...

  • Page 15: Music Player Settings

    Music player settings You can choose the equalization mode that fits your preferences. To do so, browse to “SETTINGS” → “MUSIC” → “EQ select” and choose one of the 6 available modes: “Normal”, “MS PlayFX”, “Rock”, “Pop”, and “Classic” or “Jazz”. The playing order of the tracks depends on the selected mode.

  • Page 16

    VIDEO You can play AVI / WMV / MPG / VOB / ASF videos that you previously converted to the AVI format (XVID with MP2 audio and 128 x 128 resolution), using the easy soft- ware tool included inside the bundled CD. NOTE: You must convert a video to the correct format before transferring to the player.

  • Page 17

    CREATING AVI VIDEOS Before transferring video files to the MP3 Player, you must convert them to the correct format. With the AVI Converter software tool you can easily convert your AVI / WMV / MPG / VOB / ASF videos to the AVI format (XVID with MP2 audio and 128 x 128 resolution) so you can enjoy them on your MP3 Player.

  • Page 18: Converting Videos

    Converting videos 1. Connect the MP3 Player to the USB port of your computer (optional). 2. Click on “AVI Converter ”from the “Start ” menu, or the icon on your desktop. 3. Click on the “Add” button and select 128 x 128 resolution.

  • Page 19

    Click on the “Target File Path” drop down window to select the destination for the converted video. You can send it directly to your player by selecting “Emerson MP3”, and clicking “OK”, or if you would like to save the video to your computer, we recommend sending it to your “Desktop”...

  • Page 20

    12. Once finished, press “Close” to exit the application. 13. Copy the new AVI file(s) to your player. See “TRANSFERRING MEDIA TO THE PLAYER” (page 11). “Target File Name” Click “Save” 128 x 128 Lake.avi Emerson MP3 Lake.avi then Click “Close” Lake.avi Emerson MP3 Lake.avi...

  • Page 21: Viewing Pictures

    PHOTO Viewing pictures The MP3 Player is capable of storing and displaying your favorite pictures. See “TRANSFERRING MEDIA FILES TO THE PLAYER” (page 11) and follow the steps below: 1. Select “PHOTO” from the main menu, and press the [PLAY] button..

  • Page 22: Viewing Txt Files

    E-BOOK View and enjoy your electronic books (e-book in TXT format) anywhere with the high resolution LCD screen of your MP3 Player. Viewing TXT files 1. Select “E-BOOK” from the main menu, and press the [PLAY] button. 2. Select the file you wish to view, and press the [PLAY] button to open it.

  • Page 23

    RECORD Your MP3 Player is able to perform voice recordings with its integrated microphone. The files are in WAV format. You can listen to these files while being at the “BROWSER” mode, and selecting the “Voice” folder. Recording 1. Select “RECORD” from the main menu, and press the [PLAY] button.

  • Page 24

    ● From your computer You can easily delete music, picture or video files by connecting your video player to the computer and selecting “Emerson MP3” from Windows Explorer or “My Computer”, or click on “Open Folder” to view files from the “Auto play” option window, simply select the file and delete it as you would delete any other file from your computer.

  • Page 25

    SETTINGS The player’s settings can be customized by accessing “SETTINGS” in the main menu. The settings menu consists of several items where various functions can be selected concerning music, power, language, display, recording, system, etc. 1. Select “SETTINGS” from the main menu, and press the [PLAY] button. 2.

  • Page 26

     Press the reset hole with a metal pin to re-initialize the system of the player My computer is not detecting the MP3 Player with Windows Vista  There is a USB mass storage devices recognition issue with Windows Vista acknowledged by Microsoft. A solution is available in the Service Pack 1 which may be downloaded from Microsoft’s website...

  • Page 27

    SPECIFICATIONS Connect with PC USB 2.0 (HIGH SPEED) Built-in memory Power source Built-in Lithium battery Sampling rate Recording Recording format Recording time Earphone Max output MP3 bit rate MP3, WMA WMA bit rate Frequency response Music file format MP3 / WMA Video file format Operating temperature -5 - 40...

  • Page 28

    LIMITED WARRANTY In the unlikely event that this product is defective, or does not perform properly, you may within ninety (90) days from your original date of purchase return it to the authorized service center for repair or exchange. TO OBTAIN WARRANTY SERVICE: - Provide proof of the date of purchase within the package (Dated bill of sale) - Prepay all shipping costs to the authorized service center, and remember to insure your return.

  • Page 29

    To obtain service after the warranty period, please e-mail cs@southerntelecom.com with product information, date of purchase and nature of the problem. Customer service will reply to the e-mail with service instructions. Warranty service not provided: This warranty does not cover damage resulting from accident, misuse, abuse, improper installation or operation, lack of reasonable care, and unauthorized modification.

  • Page 30

    Manufactured by: AIT Inc. Brooklyn, NY 11232 Emerson and the G-Clef logo are registered trademarks of Emerson Radio Corp. Parsippany, New Jersey USA © 2009 AIT Inc. All rights reserved Microsoft, the Windows logo, and Windows Media are either registered trademarks or trademarks of Microsoft...
