Lightolier ProSpec DRP70 Specification

Page 1 of 2

Ordering Information

Catalog No. Finishes
DR2PS70WH
White
DR2PS70BK
Black
DR2PS70SL Silver

Description

Remote controlled spotlight that can be mounted anywhere along the track and
remotely aimed through the use of a hand-held controller. Can not be dimmed.
Can not turn on/off using hand-held controller.

Features

1. Full remote control of pan and tilt movement to aim at any object below the
luminaire.
2. Positions can be recorded for future use.
3. Continuous movement and sequencing option.
4. Interchangeable Click-On™ reflectors to achieve desired beam spread.
Reflectors sold separately.
5. Die-cast aluminum housing.

Electrical

Electronic Ballast
Input Voltage: 120V, 60 Hz
Power Factor: >95%
Input Power: 78W
Max. Input Current: .67A
Total Harmonic Distortion: <10%
ANSI Code: M139, M143, M98
Do not use on a dimming circuit.
Lightolier is a Philips group brand
6 1/2"
(165)
12 13/16"
(325)
( ) Denotes dimensions in mm
Track Mounting
Compatible with all ProSpec
Track Systems
ProSpec Track Lighting System
™
2 13/32"
(61)
5 1/4"
(133)
Lamp
T6 Single Ended, G12 Base,
Ceramic Metal Halide 70W
Labels
cULus Classified
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • C1108
DRP70
Director Metal Halide 70W T6
®
Requires Laser
Remote Control
for Operation
Reflectors
Use one of:
DRT6RS
DRT6RM
DRT6RF
Type:
