Lightolier ALETTA AL1T8 Specification

Page 1 of 2
2.00"
(5.08cm)
Louver w/ Elongated
Ordering Information
Family Shielding
A
Aletta LE=Louverw/ 2=2'(60.96cm)
4=4'(121.92cm)
Elongated Lens
* For dimming, use "D" option. If "D" is not selected, ballast will be static.
Features
1. Housing: 23gaugepre-paintedsteel.20gaugeavailable,consultfactory.
2. Lamp: OneT8.(byothers)
3. Faux Housing: ExtrudedFrostyacrylic.
4. Louver:HighpuritySemi-Specular,2-3/4"(6.99cm)openingx1-3/8"(3.49cm)
deepon2"(5.08cm)ctrswithmicro-prismaticsideoverlays.Elongatedlens
openingsare22"(55.88cm)windows.
5. Performance Kick Reflector:.020"(0.05cm)95%-98%reflective,UV
resistant polypropylene.
6. Trim:Extrudedaluminumtrim,paintedwhite,interfaceswithceilinggridor
plasterframebyothers.
Electrical
Ballastsareelectronicandhighpowerfactor.Dimmingballastsareavailableon
manylamptypes,pleaseconsultfactoryregardingspecificapplications.1325
maxlumenbatterypackisstandard.Seeapplicationtableonpage2foroutput
with specific lamp types. Continuous luminaires utilize 12 gauge through wires.
Factoryinstalledballastdisconnectallowstheballasttobedisconnectedfromand
reconnected to incoming power under load without turning the entire circuit off.
Mounting
Housingissuspendedbyhangerwiresandlaidintostandardorslot-Tgridceiling.
Mountingaccessoryavailablefordrywallinstallations(seepage2).
Labels
UL,cULandI.B.E.W.
631AirportRoad,FallRiver,MA02720•(508)679-8131•Fax(508)674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com©2010PhilipsGroup•
2.75"
(6.99cm)
23.00"
(58.42cm)
7.00"
(17.78cm)
Lens Detail
Length Lamps Lamp Type
1
T8
1 = 1 Lamp T8 =T8
Standard
Output
D1007

Lighting Systems

LouverShield,1T8LampperFixture,GridMounted
24.00" (60.96cm)
7.00"
(17.78cm)
1 5 4
Ballast Factor
71 = .71 1 = 120v
78 =.78 2 = 277v
88 =.88 3 =347v
10 = *1.0 Dimming
and Static
12 = *1.2 Step Dimming
Ordering Instructions
Individual Fixtures:
1. OrderquantityofIndividualUnitsrequired.
Continuous Runs:
1. OrderoneStarterandoneEnderfixtureperrun.
2. OrderappropriatequantityofJoinerfixtures.
Continuousrunsonly-PriortoinstallingAlettainagridceiling,theinstalling
contractormustensurethatthefixturewillsetintotwomainrunners,spaced2'
(60.96cm)oncenter.Nogridcrossmembersarerequiredexceptatthebeginning
and end of the run.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
ALETTA AL1T8
(13.41cm)
2 3
Voltage Housing Option
U =IndividualUnit D = Dimming
S = Starter E =EMPack
J = Joiner 2 = 2 Circuit
E = Ender 4 =4ThroughWire
5 =5ThroughWire
Type:
5.28"
6
