THE SERIAL NUMBER WILL BE FOUND ON THE LOWER FRAME AT THE HEAD END.
RECORD THE NUMBER BELOW:
SERIAL NUMBER:
Form 900EC Manual
OPERATION
and
SERVICE MANUAL
EC TRANS. CHAIR
MODEL 900EC
800-637-8436 / Fax 325-677-7217
DATE OF PURCHASE
ConvaQuip Ind., Inc.
P.O. Box 3417
Abilene, TX 79604
www.convaquip.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 900EC and is the answer not in the manual?

Questions and answers

Related Manuals for ConvaQuip 900EC

Summary of Contents for ConvaQuip 900EC

  • Page 1 OPERATION SERVICE MANUAL EC TRANS. CHAIR MODEL 900EC THE SERIAL NUMBER WILL BE FOUND ON THE LOWER FRAME AT THE HEAD END. RECORD THE NUMBER BELOW: SERIAL NUMBER: DATE OF PURCHASE ConvaQuip Ind., Inc. P.O. Box 3417 Abilene, TX 79604 800-637-8436 / Fax 325-677-7217 www.convaquip.com Form 900EC Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CONTENTS IMPORTANT INSTRUCTIONS GENERAL WARNINGS AND PRECAUTIONS MODEL 900EC OPERATING THE CHAIR OPERATION OF STEER/BRAKE USING THE 4 - CASTER FREE FUNCTION APPLYING THE BRAKES ADJUSTING THE ARMREST RAISING THE SURFACE I.V. SOCKETS AND STORAGE HANDSET OPERATION DIAGNOSTICS &...

  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS Safety First: The primary concern of ConvaQuip is that this equipment be operated and maintained with the safety of the user in mind. T o assure safe and reliable operation. Read this manual before operating your equipment. It is the responsibility of the purchaser to assure that appropriate personnel are in formed on the contents of this manual.
  • Page 4 T ake special care to lock the casters securely when transferring patient to or from the chair. Do not allow the patient to sit on the chair when it is in the prone position. Never sit or lean on the headrest or the legrest when the chair is in the prone position. Caution: Failure to observe these safety precautions may result in personal injury or mechanical failure.

  • Page 5: Model 900Ec

    MODEL 900EC The backrest is adjustable from 0 - 60°. This chair is equipped with central steering and braking system operable from any corner of the chair. This facilitates patient transport. High density foam seat, leg and back cushions are covered with low shear fabric. OPERATING THE CHAIR Operation of all features and functions prior to usage is essential to ensure that chair was not damaged in transit.

  • Page 6: Applying The Brakes

    APPLYING THE BRAKES The central braking system locks all four wheels. T o engage the brakes, go to any corner of the chassis and press the red side of pedal down approximately 45° to lock. After applying the brakes, try to lightly push the chair, it should not roll. If it does, remove the patient and discontinue using the chair until maintenance can be performed.

  • Page 7: Handset Operation

    T o either raise or lower the chair it must be in the prone position. The backrest must be all the way down and both legrest must be all the way up. The bottom row of buttons provide this feature with pushing one button. The IV sockets are located on each side of the head end.

  • Page 8: Diagnostics & Repair

    DIAGNOSTICS & REPAIR PROBLEM CAUSE SOLUTION No functions operate No power to unit Check power cord Is it plugged into receptacle? Green Power-on light Electrical power cord not does not glow properly plugged into Check cord for breaks. control module Power cord plugged Check for power to receptacle in but no functions...

  • Page 9: Specifications

    SPECIFICATIONS Product name: ConvaQuip EC TRANS. CHAIR Model: 900EC 850 LB. Capacity Dimensions: Overall Width 33 1/2” Overall Length chair position 49 1/2” stretcher position 75 1/2” Seat Width 28 1/2” Seat Depth 22” Back Angle 60 Degrees Chair Weight 280 LB...

  • Page 10: Limited Warranty

    LIMITED WARRANTY ConvaQuip will warrant your chair to be free from defects in material and workmanship under normal use and service for a period of two (2) years on parts & labor from date of the delivery to the original purchaser, except: the effective time period of this warranty is limited to one (1) year for cushions, wheels, tires, IV pole and accessories.
