PORTABLE CD PLAYER
CX-CD331
General
Read the instruction manual before operating this unit.
Maximum Output (Stereo Headphone..15mW+15mW(32ohm)
Do not expose the unit to high temperature or humidity.
Radio Frequecy
Use dampened soft cloth to clean the unit. Do not use strong
FM..................................................88-108MHz
detergent or solvent to clean the unit.
DC.................................................. 3V with 2 size "AA" Batteries
Consult your dealer if you are ever in doubt about the
installation, operation or safety of your equipment
Tuning Control
LCD Display
The CD mechanism and the sensitive circuitry may cause interference
to a radio tuner nearby. Do not operate this unit while operating other
radio devices.
Danger
This product utilizes invisible laser
radiation. Avoid direct exposure to
the beam.
Caution
Use of controls, adjustments or procedures not listed in
this manual may result in hazardous radiation exposure.
Only compact discs identified with this mark can
be used with this player.
RADIO OPERATION
5.1"x 1.1"x 5.9"(WHD)
RADIO OPERATION
(1)Slide the FUNCTION switch to FM position to turn
the power on.
(2)Get to the desired station by tuning knob.
(3)Set a proper listening level by volume control.
(4)To turn off the radio, slide the FUNCTION switch to CD.
BATTERY OPERATION (BATTERIES NOT INCLUDED)
Your unit operates on two(2)AA size alkaline batteries. Open the
CD cover and insert the batteries in the battery compartment
following the polarity diagram located inside.
Headphone
jack
Volume
control
Function
Switch
Open door lock
FF
button
REW
button
Stop button
Play/Pause button
CD OPERATION
(1)Press PLAY/PAUSE (
)button to turn
the power on.
(2)LCD screen will display"
".
(3)LCD screen will display " no diSC" if CD is not
in the unit.
(4)LCD screen will display "Er" if the unit cannot
read CD track data.
(5)When CD track data has been read, LCD
screen will display the last track number
C OM PA C T
with the total play time.
(6)Unit will start playing from track No.1
DIGITAL AUDIO
automatically.
Press STOP(
)button to stop play,
and the last track Number will display.
Press PLAY/PAUSE(
)button to pause
on/off alternately.
Time display will flash on pause mode.
Hearing experts advise against the constant use of personal stereos played
at high volume. Constant high volume use can lead to hearing loss. If you
experience ringing in the ears or hearing loss, discontinue use and seek
medical advice.
. T o remove the disc from its storage case, press down on the center of
the case and lift the disc out. Hold it carefully by the edges as shown
below.
Insert the disc into the unit with the label of the disc facing UP .
Gently wipe the disc using a soft cloth from the center to the outer
direction to remove dust, fingerprints or any other particles on the
disc surface. Never use chemicals, such as record sprays , anti-static
sprays, benzene or thinners to clean the CD. These chemicals can
damage the disc surface permanently.
To avoid serious scratches on CD, keep them in the cases after each
use. Scratches can cause the laser pick-up skip in the future play.
Do not place stickers or write anything on the disc.
During play, press and hold FF
REW
) button to fast forward (or
(1) Press FF
(or REW
)button to set the
fast reverse) the current track.
desired track# . Press PLAY/PAUSE
button to play. Press FF
(or REW
)
POWER OFF
Press FF button
button to change the track # during the play
Press STOP button to get to the stop mode.
The player will shut off automatically after a few seconds.
mode.
(2) During play, press REW
button to play
(1)
is displayed when the battery voltage
previous track.
reaches low.
Press REW button at the head of NO.4
(2) When the voltage is too low, the unit will
automatically turn off.
(3) During pause mode, press FF
(or REW
)
button to play the next track (or previous track).
The unit will keep in pause mode and time
display will flash.
(or
