Coby CX-CD314 User Manual

PORTABLE CD PLAYER
CX-CD314
The CD mechanism and the sensitive circuitry may cause interference
to a radio tuner nearby. Do not operate this unit while operating other
radio devices.
Danger This product utilizes invisible laser
radiation. Avoid direct exposure to
the beam.
Caution Use of controls, adjustments or procedures not listed in
this manual may result in hazardous radiation exposure.
General
Maximum Output (Stereo Headphone..15mW+15mW(32ohm)
Only compact discs identified with this mark can
be used with this player.
DC.................................................. 3V with 2 size "AA" Batteries
5.1"x 1.1"x 5.9"(WHD)
(1)Press PLAY/PAUSE (
the power on.
(2)LCD screen will display " 60 SEC "
and then change to "
Once the player is powered it goes to
the anti-shock mode automatically and the
anti-shock symbol "
Press ESP button to quit the anti-shock mode and
anti-shock symbol disappears.
(3)LCD screen will display "diSC" if CD is not
in the unit.
PRG BUTTON
MODE BUTTON
FF BUTTON
REW
PLAY/PAUSE BUTTON
OPEN BUTTON
STOP BUTTON
ESP BUTTON
LCD Display
(4)LCD screen will display "Er" if the unit cannot
read CD track data.
(5)When CD track data has been read, LCD
screen will display the last track number
with the total play time.
(6)Unit will start play from track No.1
automatically.
C OM PA C T
Press STOP( )button to stop play,
DIGITAL AUDIO
and the last track Number will display.
Press PLAY/PAUSE( )button to pause
on/off alternately.
Time display will flash on pause mode.
)button to turn
"
" appears on the screen.
BATTERY OPERATION (BATTERIES NOT INCLUDED)
Your unit operates on two(2)AA size alkaline batteries. Open the
CD cover and insert the batteries in the battery compartment
following the polarity diagram located inside.
DC IN JACK
HOLD SWITCH
DBBS SWITCH
314
PHONE JACK
VOLUME CONTROL
BUTTON
During play, press and hold FF
REW ) button to fast forward (or
fast reverse) the current track.
(1) Press FF (or REW )button to set the
desired track# . Press PLAY/PAUSE REPEAT ONE TRACK
button to play. Press FF (or REW ) (1) Press MODE button once to repeat current
Press FF button
track.
button to change the track # during the play
(2) Repeat one indicatior appears.
mode.
REPEAT ALL TRACKS
(1) Press MODE button twice to repeat all
tracks.
(2) Repeat all indicatior appears.
(2) During play, press REW button to play
INTRO FUNCTION
previous track.
Press REW button at the head of NO.4
The player will play each track for a few seconds.
(1) Press MODE button the third time,
INTRO indicator appears flashing.
(2) Press PLAY/PAUSE button to start INTRO
play and INTRO indicator turns still.
RANDOM FUNCTION
(3) During pause mode, press FF (or REW )
The player will start playback in an random
button to play the next track (or previous track).
order.
The unit will keep in pause mode and time (1) Press MODE button the fourth time,
RAND indicator appears flashing.
display will flash.
(2) Press PLAY/PAUSE button to start
RANDOM play . RAND indicator turns still.
NOTE: To quit REPEAT/INTRO/RAN mode, just keep pressing MODE
button till funnction indicator disappears from the screen.
Hearing experts advise against the constant use of personal stereos played
at high volume. Constant high volume use can lead to hearing loss. If you
experience ringing in the ears or hearing loss, discontinue use and seek
medical advice.
. T o remove the disc from its storage case, press down on the center of
the case and lift the disc out. Hold it carefully by the edges as shown
below.
Insert the disc into the unit with the label of the disc facing UP .
Gently wipe the disc using a soft cloth from the center to the outer
direction to remove dust, fingerprints or any other particles on the
disc surface. Never use chemicals, such as record sprays , anti-static
sprays, benzene or thinners to clean the CD. These chemicals can
damage the disc surface permanently.
To avoid serious scratches on CD, keep them in the cases after each
use. Scratches can cause the laser pick-up skip in the future play.
Do not place stickers or write anything on the disc.
PROGRAM PLAY
(or
1. Press PROG button, the screen is read as:
2. Press FF/REW button to get the desired track.
3. Press PROG to confirm, 01turns to 02.
it is ready to make next selection.
1
4. Repeat the above steps to edit up to 20 tracks.
Press PROG button to check program list.
ALL
5. Press PLAY/PAUSE button to start playback.
6. To stop program playback, press STOP button.
7.To erase memory, open the CD door or cut off power.
NOTE: Repeat/Intro function works also under the program play mode.
INTRO
(1) is displayed when the battery voltage
reaches low.
(2) When the voltage is too low, the unit will
RAND
automatically turn off.
ANTI SHOCK PLAY
Press ESP button to prevent disruption or stopping of the CD player for
60 seconds. LCD will show an anti-shock symbol " ".
Read the instruction manual before operating this unit.
Do not expose the unit to high temperature or humidity.
Use dampened soft cloth to clean the unit. Do not use strong
detergent or solvent to clean the unit.
Consult your dealer if you are ever in doubt about the
installation, operation or safety of your equipment
DBBS FUNCTION
DBBS FUNCTION
The Dynamic Bass Boost System(DBBS) enhances the
low frequency(Bass) response of the output.
Set the Volume to low listening level and set DBBS switch to ON .
Note: Some CD'S with DBBS may exceed the bass response
capacity and can cause distortion.
To avoid this , do not play DBBS in high volume.
Playing DBBS in high volume may cause damage to the
headphone and more importantly, to your hearing.
