Philips LU Series Specification

LUNW1R
T
HERMOPLASTIC
Features
Illumination: Illumination
of the LU Series edge-lit exit
panel is accomplished with the
use of high-brightness LEDs
offering even illumination.
LEDs offer low maintenance
replacement costs and long life.
Housing: Impact-resistant,
UL 94 V-0, 5 VA thermoplastic
housing/backbox can be used
for both recessed and surface
mount applications. White
housing is standard, with an
optional black housing. The
LU Series exit stencil panel
includes customer-installable
NFPA-compliant directional
chevrons, and is manufactured
from high-impact clear acrylic
and silk-screened computer
generated artwork. All
artworks meet UL and NFPA
standards for exit signage.
All models are supplied with
white and mirrored inserts to
complement the standard clear
panel.
LU Series
E
DGE
Operating Temperature
Range: Standard Location
65°F (19°C) to 85°F (30°C)
Damp Location
50°F (10°C) to 104°F (40°C)
Electronics: AC Only -
120/277 VAC dual voltage
input with surge protection.
Self-Powered - 120/277 VAC
dual voltage input with surge-
protection, solid-state charging
circuitry provides for a reliable
charging system. Charging
system is complete with low
voltage disconnect, brownout
protection, AC indicator LED
and test switch.
Electrical Specifications:
AC Only (120 VAC):
Red - 5.16 W
Green - 4.80 W
Self-Powered (120 VAC):
Red - 8.4 W
Green - 5.4 W
Job Information Type:
Job Name:
Cat. No.:
Notes:
-L LED E
IT XIT
Page 1 of 2
Code Compliance
UL 924 and optional UL damp
location listed. NFPA 101,
NEC, BOCA, OSHA and IBC
illumination standards
Warranty
Three year full electronics
warranty. Five year full plus
five year prorated battery
warranty.
